FRONT SIDE DOOR OUTSIDE HANDLE REPLACEMENT Fig. 14: View Of Front Side Door Outside Handle Assembly & Components 1 1. Rotate the front side door Inside release handle to full open position. 2. Use a small pair of 45 degree needle nose pliers to remove the foam seal at the handle to expose the retaining clip. 3. Use a small pair of 45 degree needle nose pliers to release the clip inside the handle. 4. Remove the pin after the clip is released. 2 Front Side Door Inside Handle Callout Component Name Preliminary Procedures 1. Position the door window as needed for service. 2. Remove the front door trim panel. Refer to Front Side Door Trim Panel Replacement (YE9) or Front Side Door Trim Panel Replacement (SLT) .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Vehicle Access - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
REAR SIDE DOOR INSIDE HANDLE REPLACEMENT (WITH SLT) 3. Remove the water deflector. Refer to Front Side Door Water Deflector Replacement . 1 Front Side Door Lock Rod Retaining Clip 1. Remove the rubber grommet to access the bolts. 2. Plug in the window switch and raise the window. 3. Release the handle lock rod from the door lock. 4. Release the door handle lock cylinder rod. 2 Front Side Door Outside Handle Lock Rod 3 Front Side Door Outside Handle Bolt (Qty: 2) Tighten: 9 N.m (80 lb in) NOTE: Refer to Fastener Notice . 4 Front Side Door Outside Handle
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Vehicle Access - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 15: View Of Rear Side Inside Door Handle Assembly & Bolts Callout Component Name Preliminary Procedures 1. Remove door window control switch. Refer to Rear Side Door Window Switch Replacement (Crew Cab) or Rear Side Door Window Switch Replacement 2. Remove door trim panel. Refer to Rear Side Door Trim Panel Replacement (YE9) or Rear Side Door Trim Panel Replacement (SLT) . 1 Rear Side Door Inside Handle Bolt (Qty: 2) Tighten: 2 N.m (18 lb in) NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Vehicle Access - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
REAR SIDE DOOR INSIDE HANDLE REPLACEMENT (WITHOUT SLT) Fig. 16: View Of Side Door Inside Handle & Seal 2 Rear Side Door Inside Handle Assembly Callout Component Name
