When "Succeeded to add old key!" is displayed,
click "OK".
Key match is completed.
d. The vehicle security has 6 modes (w/ passive entry & passive start):
Locking mode
Enter lock mode when the following conditions are met:
- All doors, engine hood and back door are closed.
- All doors are locked by operating the lock button on PEPS controller.
- All doors are locked by operating the front door handle button (REK of PEPS in the detecting
range of this door handle antenna).
When vehicle is in lock mode, following features will occur:
- Turn signal lights blink once, anti-theft horn sounds once and anti-theft indicator on the front left
door protector blinks normally to indicate that vehicle is in lock state.
- In lock state, if no door is opened within 30 seconds after unlocking the doors by wireless key, the
doors will lock again automatically.
Locking failure mode
System will enter lock failure mode under the following conditions and will show the following
features:
- When any door is not closed fully, turn signal lights blink twice anti-theft and horn does not
sound.
- When engine hood is not closed fully, turn signal lights blink twice, doors are locked and horn
does not sound.
- When back door is not closed fully, turn signal lights blink twice, doors are locked and horn does
not sound.
Lock deactivation mode
In lock mode, the locking mode of entire vehicle will be deactivated if the following condition occurs:
- Press the unlock button on PEPS controller.
- Press the front door handle button (REK of PEPS in the detecting range of this door handle
antenna).
When vehicle is in lock deactivation mode (by PEPS controller and front door handle button (REK of
PEPS in the detecting range of this door handle antenna)), following conditions will occur:
- All doors are unlocked.
- Turn signal lights blink twice, anti-theft horn does not sound and anti-theft indicator stops
blinking.
- Within 30 s after the doors are unlocked by wireless key, when no further operation is performed
(opening a door, opening engine hood and back door), the vehicle will return to the lock state.
If the following conditions occur within 30 s after the doors are unlocked by wireless key, the vehicle
will not return to the locking state, also not lock automatically:
- PEPS switch is in a position other than OFF.
- Any door is opened.
- Engine hood is opened.
Key match
Succeeded to add old key!
OK
