Chery Tiggo 5 (T21). Manual - part 389

35–

31

35

LIGHTING SYSTEM

DTC

B100111

Left Side Turn Lamp Control Circuit Circuit Short to
Ground

DTC

B100113 Left Side Turn Lamp Control Circuit Circuit Open

DTC

B100119

Left Side Turn Lamp Control Circuit Circuit Current
Above Threshold

35–

32

35

ET21350150

R

E1

BATTERY

60A

MF03

ENGINE
COMPARTMENT
FUSE AND
RELAY BOX

COMBINATION
LIGHT SWITCH

3

E1

BCM

3

WL

WL

WL

C16

10

3

1

9

11

TURN
SIGNAL
LIGHT

TURN
SIGNAL
LIGHT

REAR
LEFT
COMBI-
NATION
LIGHT

B

B

A32

A27

B

10

2

330

150

RIGHT

LEFT

W

A17

1

YR

A1

3

4

2

5

GrB

B

1

2

3

4

5

11

12

13

14

15

6

7

8

9

10

22 21 20 19 18 17

16

C1

C10 C11 C12 C13 C14 C15 C16 C17 C18

C2 C3 C4 C5

C6 C7 C8 C9

C20

C19

E-061

E-061

I-011

HAZARD SWITCH

I-001

E-072

I-005

B-043

B-021

FRONT
LEFT
HEADLIGHT

E-056

B-048
E-070

B-022

WL

WL

13

4

TURN
SIGNAL
LIGHT

BB

B-036

E-058

W

E-072

A32

A31

A30

A29

A28

A16

A15

A14

A13

A12

A11

A10

A9

A8

A7

A6

A5

A4

A3

A2

A1

A27

A26

A25

A24

A23

A22

A21

A20

A19

A18

A17

L

I-005

1

2

3

4

5

6

7

8

9

10

B

I-011

W

B-043

1

2

3

4

5

6

B

B-021

W

B-048

B

E-056

9

7

5

3

1

10 8

6

4

2

7

POWER
REAR VIEW
MIRROR
MOTOR

F-005

B-041
F-007

3

B-040

F-007

1

4

7 10 13 16

2

5

8 11 14 17

3

6

9 12 15 18

1

4

7

10

13

16

2

5

8

11

14

17

3

6

9

12

15

18

Gr

B-041

W

B-040

1

2

3

8

9

10

11

12

13

14

15

16

4

5

6

7

W

F-005

I-003

1
2
3

4
5
6

B

I-001

Lg

ILLUMINATION

35–

33

35

Self-diagnosis Detection Logic

HINT:
While performing the electrical diagnosis and testing, always refer to the relevant circuit diagram for the
special circuit and component information.

Diagnosis Procedure

a. Remove the turn signal light bulb, and check if the turn signal light bulb filament is blown.

Use the circuit diagram as a guide to perform the following procedures:
a. Turn ignition switch to LOCK, and disconnect the negative battery cable.
b. Disconnect the Body Control Module (BCM) connectors B-043 and E-072.
c. Disconnect the left turn signal light wire harness connectors F-005, E-056 and B-021.
d. Disconnect the body wire harness connectors B-048 and B-041, front left door wire harness connector



F-007 and engine compartment wire harness connector E-070.

e. Check if wire harnesses are worn, pierced, pinched or partially broken.
f. Look for broken, bent, protruded or corroded terminals.
g. Check if the related connector terminal contact pins are in good condition.

DTC Code

DTC Definitions

DTC Detection

Conditions

DTC Setting Conditions

B100111

Left Side Turn Lamp
Control Circuit Circuit
Short to Ground

Ignition switch ON

 Turn signal light bulb
 Wire harness or connector
 Body Control Module (BCM)

B100113

Left Side Turn Lamp
Control Circuit Circuit
Open

B100119

Left Side Turn Lamp
Control Circuit Circuit
Current Above
Threshold

1

Check turn signal light bulb

Replace turn signal light bulb

NG

2

Check wire harness and connector

OK

Repair or replace related wire harness and
connector

NG

OK

35–

34

35

a. Turn ignition switch to LOCK.
b. Disconnect the negative battery cable.
c. Disconnect the Body Control Module (BCM) connectors

B-043 and E-072.

d. Using a digital multimeter, check for continuity between

terminal C16 of BCM connector B-043 and terminal E1 of
BCM connector E-072 to check if it is short to power
supply according to the table below.
Standard Condition

e. Using a digital multimeter, check for continuity between

terminal C16 of BCM connector B-043 and body ground
to check if it is short to ground according to the table
below.
Standard Condition

3

Check left turn signal light control circuit

-

+

RT21350460

C1

C10 C11 C12 C13 C14 C15 C16 C17 C18

C2 C3 C4 C5

C6 C7 C8 C9

C20

C19

B-043

E-072

E1

Multimeter

Connection

Condition

Specified

Condition

B-043 (C16) -

E-072 (E1)

Always

No continuity

-

+

RT21350470

C1

C10 C11 C12 C13 C14 C15 C16 C17 C18

C2 C3 C4 C5

C6 C7 C8 C9

C20

C19

B-043

Multimeter

Connection

Condition

Specified

Condition

B-043 (C16) -

Body ground

Always

No continuity

Repair or replace related wire harness and
connector

NG

OK
