25–
77
25
c. Remove 4 fixing screws (arrow) and the front wheel
house protector assembly (1) of rear left wheel.
d. Detach the attachment parts (arrow) between rear left
wheel speed sensor wire harness and fixing bracket,
and detach the wire harness cover (1).
e. Disconnect the rear left wheel speed sensor wire
harness connector (arrow).
f. Remove the rear left wheel speed sensor.
Inspection
1. Check the rear wheel speed sensor.
a. Check rear wheel speed sensor surface for breakage, dents or notch.
b. Check rear wheel speed sensor connector or wire harness for scratches, breakage or damage.
c. If any of the above conditions occurs, replace the rear wheel speed sensor with a new one.
Installation
Installation is in the reverse order of removal.
1
RT21250160
1
RT21250170
RT21250180
CAUTION
When installing coupling bolts, be sure to tighten them to specified torque.
