LOW FREQUENCY
ANTENNA 1

I-043

LOW FREQUENCY
ANTENNA 2

B-024

LOW FREQUENCY
ANTENNA 3

B-035

G

G

J208

1

13

Y

Y

J207

2

14

B-059

I-035

BG

BG

J216

1

16

RY

RY

J215

2

15

B-003

I-006

PEPS (J2)

I-030

1

2

B

I-043

1

2

B

B-035

1

2

B

B-024

18 17 16 15 14 13 12 11 10

9

8

7

6

5

4

3

2

1

W

I-035

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

W

I-006

J201

J202

J203

J204

J205

J206

J207

J208

J209

J210

J211

J212

J213

J214

J215

J216

B

I-030

15–

32

15

DTC Confirmation Procedure

Confirm that battery voltage is normal before performing the following procedures.
 Turn ignition switch to LOCK.
 Connect X-431 3G diagnostic tester (the latest software) to Data Link Connector (DLC).
 Turn ignition switch ON.
 Use X-431 3G diagnostic tester to record and clear the DTCs stored in the PEPS system.
 Turn ignition switch to LOCK and wait for a few seconds.
 Use X-431 3G diagnostic tester to select "Read Code".
 If DTC is detected, the malfunction indicated by the DTC is current. Go to the diagnosis procedure - Step 1.
 If DTC is not detected, the malfunction indicated by the DTC is intermittent (

See page 15-19

).

Diagnosis Procedure

a. Turn off all the electrical equipment and ignition switch.
b. Disconnect the negative battery cable.
c. Disconnect the PEPS controller connector I-030.
d. Disconnect the front internal low frequency antenna connector I-043, middle internal low frequency

antenna connector B-024 and rear internal low frequency antenna connector B-035.

e. Disconnect the instrument panel wire harness connectors I-035 and I-006, and body wire harness

connectors B-059 and B-003.

f. Check if wire harnesses are worn, pierced, pinched or partially broken.
g. Look for broken, bent, protruded or corroded terminals.
h. Check that the related connector pins are in good condition.

DTC  Code

DTC Definition

DTC Detection

Condition

Possible Cause

B1502-13

Front Internal LF
Antenna Circuit Open

Engine switch ON

 Wire harness or connector damaged
 Front internal low frequency antenna
 Middle internal low frequency antenna
 Rear internal low frequency antenna
 Passive Entry & Passive Start (PEPS)

controller

B1503-13

Middle Internal LF
Antenna Circuit Open

B1504-13

Rear Internal LF
Antenna Circuit Open

CAUTION

 When performing electrical equipment diagnosis and test, always refer to the circuit diagram for related

circuit and component information.

1

Check wire harness and connector

Repair or replace related wire harness and
connector

NG

OK

15–

33

15

a. Check the instrument panel wire harness and connector

(front internal low frequency antenna).
Check for Open

 Check for Short

b. Check the instrument panel wire harness and connector

(middle internal low frequency antenna).
Check for Open

 Check for Short

2

Check instrument panel wire harness and connector

-

+

RT21150250

J201

J202

J203

J204

J205

J206

J207

J208

J209

J210

J211

J212

J213

J214

J215

J216

I-030

1

2

I-043

Multimeter

Connection

Condition

Specified

Condition

I-030 (J214) -

I-043 (1)

Always

Continuity

I-030 (J206) -

I-043 (2)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-030 (J214) or

I-043 (1) - Body

ground

Always

No continuity

I-030 (J206) or

 I-043 (2) - Body

ground

Always

No continuity

I-030 (J214) or

I-043 (1)  -

Battery positive

Always

No continuity

I-030 (J206) or

 I-043 (2) - Battery

positive

Always

No continuity

-

+

RT21150260

J201

J202

J203

J204

J205

J206

J207

J208

J209

J210

J211

J212

J213

J214

J215

J216

I-030

18 17 16 15 14 13 12 11 10

9

8

7

6

5

4

3

2

1

I-035

Multimeter

Connection

Condition

Specified

Condition

I-030 (J208) -

 I-035 (13)

Always

Continuity

I-030 (J207) -

I-035 (14)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-030 (J208) or

I-035 (13) - Body

ground

Always

No continuity

I-030 (J207) or

I-035 (14) - Body

ground

Always

No continuity

15–

34

15

c. Check the instrument panel wire harness and connector

(rear internal low frequency antenna).
Check for Open

 Check for Short

I-030 (J208) or

I-035 (13)  -

Battery positive

Always

No continuity

I-030 (J207) or

I-035 (14) -

Battery positive

Always

No continuity

Multimeter

Connection

Condition

Specified

Condition

-

+

RT21150270

J201

J202

J203

J204

J205

J206

J207

J208

J209

J210

J211

J212

J213

J214

J215

J216

I-030

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

I-006

Multimeter

Connection

Condition

Specified

Condition

I-030 (J216) -

 I-006 (16)

Always

Continuity

I-030 (J215) -

I-006 (15)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-030 (J216) or

 I-006 (16) - Body

ground

Always

No continuity

I-030 (J215) or

I-006 (15) - Body

ground

Always

No continuity

I-030 (J216) or

 I-006 (16)  -

Battery positive

Always

No continuity

I-030 (J215) or I

-006 (15) - Battery

positive

Always

No continuity

Repair or replace instrument panel wire
harness and connector

NG

OK
