06–

210

06

Difficult to start with cold engine

Water in fuel

06-218

Fuel pump

Coolant temperature sensor

Injector

Ignition coil

Throttle

Engine mechanical

Engine speed is normal, but it is difficult to
start at anytime

Water in fuel

06-220

Fuel pump

Coolant temperature sensor

Injector

Ignition coil

Throttle

Intake pipe

Ignition timing

Spark plug

Engine mechanical

Engine starts normally, but idles roughly at
anytime

Water in fuel

06-223

Injector

Spark plug

Throttle

Intake pipe

Ignition timing

Engine mechanical

Engine starts normally, but idles roughly
during warming up

Water in fuel

06-225

Coolant temperature sensor

Spark plug

Throttle

Intake pipe

Engine mechanical

Engine starts normally, but idles roughly
after warming up

Water in fuel

06-227

Coolant temperature sensor

Spark plug

Throttle body

Intake pipe

Engine mechanical

Symptom

Suspected Area

See page

06–

211

06

Engine starts normally, but idles roughly or
stalls with part load (for example, A/C is
ON)

Air conditioning system

06-229

Injector

Engine starts normally, but idle speed is too
high

Throttle

06-231

Vacuum pipe

Coolant temperature sensor

Ignition timing

Low engine speed or stalls when
accelerating

Water in fuel

06-233

Air flow meter and throttle position sensor

Spark plug

Throttle

Intake pipe

Injector

Ignition timing

Exhaust pipe

Slow response when accelerating

Water in fuel

06-236

Air flow meter and throttle position sensor

Spark plug

Throttle inlet pipe

Injector

Ignition timing

Exhaust pipe

Lack of power and poor performance when
accelerating

Water in fuel

06-239

Air flow meter and throttle position sensor

Spark plug

Ignition coil

Throttle

Intake pipe

Injector

Ignition timing

Exhaust pipe

Symptom

Suspected Area

See page

06–

212

06

Diagnosis Procedure

OK: Voltage is 8 to 12 V.

a. The ignition switch remains in START position and check voltage of positive post of starter motor.

OK: Voltage is 8 to 12 V.

a. Remove starter motor.
b. Check if there is an open circuit or if it is stuck due to poor lubrication.

a. If malfunction only occurs in winter, Check if starter motor resistance is too strong because of improper

engine lubricant and gear oil selection.

a. Check if engine internal mechanical resistance is too strong, causing starter motor not to run or run slowly.

Engine does not crank or cranks slowly while starting

1

Check voltage between two battery posts when engine starts

Replace battery

NG

2

Check voltage of positive post of starter motor

OK

Repair or replace wire harness

NG

3

Check operation of starter motor

OK

Repair or replace starter

NG

4

Check engine lubricant and gear oil

OK

Replace lubricant with appropriate
number

NG

5

Check engine internal mechanical resistance

OK

Check and repair engine internal
resistance

NG

06–

213

06

Go to Diagnostic Help

OK
