32. Accelerator Pedal Information Outputted via CAN P1770 without effective signal acceptability without effective data During the engine running, the gearshift is subject to limitation, incapable of shifting to gear 2 Automatic exit from automatic mode
33. Accelerator Pedal Malfunction P1768 without effective signal acceptability there will be error occurrence in the event of following conditions: Oil pump is opened Temperature above 35 and oil temperature above 75 Pressure above 37 and transmission oil temperature below 55 Voltage above 13V but below 14.5V Lacking of effective oil pressure data Excessive accelerator pedal voltage Without restore strategy
34. Leakage of Hydraulic Control Unit P1771 without effective signal acceptability when the friction plate electromagnetic valve is on and off, the system pressure drop exceeds the limit value under following testing conditions. Without the occurrence of the error; Pressure above the limit value; Hydraulic temperature within certain scope; Gearshift failure or automatic setup failure during forwarding; Electric pump off. The gearshift is subject to the limitation of electric pump temperature.
35. Insufficient hydraulic system capacity or pressure P1773 Insufficient system pressure damage of oil pump Measure the system hydraulic pressure under the condition shown below. There will be occurrence of error if the measurement is less than the limit value:
No error within the hydraulic control circuit; No gearshift control; Hydraulic pump under normal function; Hydraulic oil temperature above limit value; The system is not activated after use. Hydraulic pump overheating damage of oil pump When the hydraulic pump temperature exceeds the critical temperature (150ºC), It’s not allowed for gearshift When the system pressure is less than the min limit value, the system will maintain the idling running. PDF created with pdfFactory Pro trial version |
