CONTROL HANDLE (ADVANCED HAND CONTROL) AHC Steering Lever Removal And Installation Remove the handle control unit. (See Page 10–19.) Remove the switch handle from the steering lever. (See Remove the handle from the steering lever. (See Page Loosen the two u–clamps (Item 1) [A] nuts. Remove the steering lever from the cross shaft and The steering lever (Item 1) [B] must be replace as a The connector clip (Item 2) [B] can be replaced AHC Steering Lever Boot Disconnect the switch handle harness connectors from Remove the connectors from the switch handle wiring Loosen the two u–clamps (Item 1) [A] and remove the Remove the four pop rivets from the boot retainer (Item Remove the steering lever boot. A N–17773 1 C N–17775 1 –10–28– Service Manual 773 BICS Loader Revised Nov. 01 B P–13734 1 2 |
