REAR DOOR (Cont’d) Removal And Installation (One Piece Door) Remove the light assembly from the door (See Page Secure the chain hooks (Item 1) [A] to the door as shown. Connect a chain hoist (Item 2) [A] to the lifting chain. Disconnect the light harness connector (Item 1) [B] (if so Remove the top and bottom door hinge mounting bolts Installation: Tighten the mounting bolts and nuts to Lift the door away from the loader frame and put the door Reverse the removal procedure to install the rear door. NOTE: Install the door stop (Item 3) [B] in the top hinge as shown. Revised May 98 B N–15860 3 2 1 A N–15410 1 2 –5–28– 773 BICS Loader Service Manual |
