STEERING LINKAGE (Cont’d) Steering Neutral Adjustment The following tool listed will be needed to do the follwoing MEL1429A – Remote Start Switch Connect the remote start switch to the engine harness. Put jackstands under the front axles and rear W–2017–0286 Loosen the nut (Item 1) [A] a couple of turns, then loosen The bolt (Item 2) [A] must be loose enough to allow the Loosen the four bolts (Item 1) [B] holding the two NOTE: Bolt holes (Item 2) [B] are slotted for pintle arm centering adjustment. Adjust the left hand centering block first [C]. Start the engine and run at high RPM. Move the traction lock override switch (Item 1) [D] to the Move the left hand steering lever until the tires do not turn Move the left hand centering block to the left until it Tighten the bolts to 25–28 ft.–lbs. (34–38 Nm) torque. NOTE: If the centering blocks are worn, they can be removed and rotated 180 degrees and Revised May 98 D P–04714 1 A P–03726 3 2 1 4 C P–03725 –3–12– 773 BICS Loader Service Manual B P–03731 1 1 2 2 |
