Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not 8J0-043200409 253 254 255 256 257 258 259 260 261 262 263 264 265 266 J 285 410 Y 24 F 66 br/bl 0,35 2 T32/21 br/ge 0,35 1 F 22 T32/15 sw 0,35 1 sw 0,5 T 14/1 K 28 K 3 410 T32/30 or/br 0,35 • T20d/8 J 533 T32/29 or/bl 0,35 • T20d/18 J 533 T32/8 gr/ge 0,5 T 6a/6 T 6a/4 G 266 3 2/31 1 sw/ro 0,5 br 0,5 T 6a/5 38 B278 gr/ge 0,5 sw/ro 0,5 br 0,5 sw/ro 0,5 34 34 38 ws = white sw = black ro = red br = brown gn = green bl = blue gr = grey li = purple ge = yellow or = orange rs = pink Control unit in dash panel insert, oil pressure switch, coolant shortage indicator switch, oil level and oil temperature sender, oil pressure warning lamp, coolant temperature and coolant shortage warning lamp F22 Oil pressure switch F66 Coolant shortage indicator switch G266 Oil level and oil temperature sender J285 Control unit in dash panel insert J533 Data bus diagnostic interface K3 Oil pressure warning lamp K28 Coolant temperature and coolant shortage warning lamp T6a 6-pin connector, black, in front left engine compartment T14 14-pin connector, black, on front left in engine compartment T20d 20-pin connector, black, on data bus diagnostic interface T32 32-pin connector, blue, on control unit in dash panel insert Y24 Display in dash panel insert 410 Earth connection 1 (sender earth), in main wiring harness B278 Positive connection 2 (15a), in main wiring harness • CAN bus (data wire) Audi TT Current Flow Diagram No. 43 / 20 Edition 04.2009 |
