Symptom
Probable cause(s)
Notes
14-17
Symptom Troubleshooting Index
When you turn the
ignition switch ON
(II), the D indicator
comes on and
stays on in all shift
lever positions, or
it never comes on
at all
Communication line between
multiplex control unit and gauge
assembly defective
Check if the MIL indicates the code for the
communication line between the multiplex control unit
and gauge assembly (see page 22-189).
D3 or M indicator
does not work
Communication line between
multiplex control unit and gauge
assembly defective
Check if the MIL indicates the code for the
communication line between the multiplex control unit
and gauge assembly (see page 22-189).
Shift lever cannot
be moved from P
while you’re
pressing on the
brake pedal
A problem in the shift lock system
(interlock system)
Check the interlock system-shift lock system circuit
(see page 14-313).
Shift lever cannot
pass through R
from N
A problem in the reverse lock
system (interlock system)
Check the interlock system-reverse lock system circuit
(see page 14-321).
Ignition switch
cannot be moved
from ACC (I) to
LOCK (0) (key is
pushed in, shift
lever in P)
A problem in the key interlock
system (interlock system)
Check the interlock system-key interlock system circuit
(see page 14-323).
(cont’d)
