Moonroof Motor Test 1. Remove the right rear pillar trim (see ). 2. Disconnect the moonroof harness 2P connector from the right side wire harness. Terminal side of male terminals 2P CONNECTOR 4. Carefully remove the headliner (see ). 5. Disconnect the 2P connector from the moonroof motor. MOONROOF MOTOR 2P CONNECTOR Terminal side of 6. Test the motor by connecting power and ground according to the table. • If the motor runs smoothly, repair the moonroof wire harness. • If the motor fails to run or does not run smoothly, ). NOTE: See closing force check in for motor clutch test. If the motor fails to run or does not run smoothly, 3. Test the motor by connecting power and ground according to the table. RIGHT SIDE WIRE HARNESS Main Menu Table of Contents |
