Acura RL (1996-2004 year). Manual - part 441
SNAP RING
THRUST WASHER
THRUST NEEDLE BEARING
MAINSHAFT 1ST GEAR
NEEDLE BEARINGS
THRUST NEEDLE BEARING
MAINSHAFT 1ST GEAR DISTANCE COLLAR
MAINSHAFT 1ST GEAR COLLAR
1ST/4TH CLUTCH ASSEMBLY
O-RINGS Replace.
THRUST WASHER, 43 x 74 mm Selective part
THRUST NEEDLE BEARING
MAINSHAFT 4TH GEAR
NEEDLE BEARING
THRUST NEEDLE BEARING
MAINSHAFT 3RD GEAR
MAINSHAFT
SEALING RINGS, 37 mm Replace.
NEEDLE BEARING
SET RING
TORQUE CONVERTER HOUSING
COUNTERSHAFT 2ND GEAR COLLAR
THRUST NEEDLE BEARING
SET PLATE
1ST GEAR ONE-WAY CLUTCH
COUNTERSHAFT 1ST GEAR
NEEDLE BEARING
THRUST NEEDLE BEARING
COUNTERSHAFT 1ST GEAR COLLAR
1ST-HOLD CLUTCH ASSEMBLY
O-RINGS Replace.
1ST-HOLD CLUTCH DISTANCE COLLAR Selective part
COUNTERSHAFT 4TH GEAR
THRUST NEEDLE BEARING
COUNTERSHAFT 3RD GEAR
NEEDLE BEARING
THRUST NEEDLE BEARING
COUNTERSHAFT 3RD GEAR COLLAR
3RD CLUTCH ASSEMBLY
O-RINGS Replace.
COUNTERSHAFT
SEALING RINGS, 42 mm
SET RING Replace.
TAPERED ROLLER BEARING
SECONDARY DRIVEN GEAR SHAFT
TAPERED ROLLER BEARING
SECONDARY DRIVEN GEAR SHAFT OIL SEAL
Replace.
EXTENSION SHAFT
PARK ROD
LOCK WASHER Replace.
DETENT LEVER
TRANSMISSION HOUSING
TRANSMISSION HOUSING OIL SEAL Replace.
CONTROL SHAFT
SPEED SENSOR CONNECTOR BRACKET
TRANSMISSION HANGER
O-RINGS Replace.
HARNESS CLAMP BRACKET
MAINSHAFT SPEED SENSOR WASHER
MAINSHAFT SPEED SENSOR
SNAP RING
MAINSHAFT TRANSMISSION HOUSING BEARING
TRANSMISSION HOUSING OIL SEAL Replace.
COUNTERSHAFT SPEED SENSOR WASHER
COUNTERSHAFT SPEED SENSOR
THRUST SHIM, 75 mm Selective part
TAPERED ROLLER BEARING OUTER RACE
DOWEL PINS
TRANSMISSION HOUSING GASKET Replace.
TAPERED ROLLER BEARING OUTER RACE
TORQUE CONVERTER HOUSING OIL SEAL Replace.
TORQUE SPECIFICATIONS
