Acura RL (1996-2004 year). Manual - part 144

2004 American Honda Motor Co., Inc.

111. Above Right Kick Panel

ABS
CONTROL
UNIT
(’96-’99)

BLOWER
MOTOR

C448
(20-BLK)
JUNCTION
CONNECTOR

2004 American Honda Motor Co., Inc.

112. Below Right Side of Dash

A/T REVERSE
DIODE (TAPED
TO HARNESS)

C201
(18-GRY)
C202
(8-GRY)
(ABOVE)

2004 American Honda Motor Co., Inc.

113. At Left Sunvisor (Right Similar)

C542 (LEFT)
C544 (RIGHT)
(1-CLR) (’96-’98)
(2-GRY) (’99-’04)

2004 American Honda Motor Co., Inc.

114. Center Front of Roof

C543
(4-GRY)

C546
(3-GRY)
(LOCATION)
(EXCEPT
’02-’04
(USA))
