Audio Glossary
Item
Definition
23-169
Track
A sound recording on a CD, tape, or PC Card.
Treble
An adjustment to control the volume of the high frequency sounds.
Tuner
A component (or part of a component) that receives radio signals and selects
one broadcast from many.
Tweeter
A speaker designed to reproduce the higher frequencies (treble) only.
USB
Universal Serial Bus. The USB is used for playing the compressed audio files
(MP3, WMA, and AAC) on the external device through the audio unit.
Voice coil
A coil of wire wrapped around a tube and then attached to the speaker cone or
diaphragm. When an audio signal is applied, the coil becomes an
electromagnet and interacts with the permanent magnet causing the come or
diaphragm to vibrate. We interpret this vibrations as sound.
Volume control
Allows you to control the loudness of the music.
WMA music file
Windows Media Audio File. This is an accepted format for music files to be
played on either a CD-R, a CD-RW or a PC Card.
Woofer
A speaker that is designed to reproduce low (bass) frequencies only.
XM radio
Satellite based radio transmission, which also uses a ground based repeater
network to ensure seamless reception. The channels originate from XM’s
broadcast center, in Washington, DC, and uplink to two satellites. These
satellites transmit the signal across the entire continental United States.
XM receiver
The external component that receives and processes the XM signals from the
XM satellites, and terrestrial (land) stations. The audio unit communicates to
the XM receiver over the GA-Net bus.
