DTC

Detection Item

ABS

Indicator

Brake

System

Indicator

VSA

Indicator

VSA

Activation

Indicator

Note

19-101

25

Yaw Rate Sensor Internal Circuit Malfunction
(Initial)

OFF

OFF

ON

ON

(see page 19-126)

-12

Yaw Rate Sensor Internal Circuit Malfunction
(Open, Short)

OFF

OFF

ON

ON

(see page 19-126)

-13

Yaw Rate Sensor Communication Error

OFF

OFF

ON

ON

(see page 19-126)

Yaw Rate/Lateral Acceleration Sensor Circuit High
Voltage

OFF

OFF

ON

ON

(see page 19-127)

Yaw Rate/Lateral Acceleration Sensor Circuit Low
Voltage

OFF

OFF

ON

ON

(see page 19-127)

Yaw Rate/Lateral Acceleration Sensor Internal
Circuit Malfunction (Keep Alive Memory (KAM)
Error)

OFF

OFF

ON

ON

(see page 19-126)

Yaw Rate/Lateral Acceleration Sensor Power
Source Voltage Malfunction

OFF

OFF

ON

ON

(see page 19-127)

Yaw Rate/Lateral Acceleration Sensor Internal
Circuit Malfunction

OFF

OFF

ON

ON

(see page 19-126)

Yaw Rate/Lateral Acceleration Sensor Startup Time
Malfunction

OFF

OFF

ON

ON

(see page 19-127)

-21

Yaw Rate Sensor Neutral Position Malfunction

OFF

OFF

ON

ON

(see page 19-126)

-22

Yaw Rate Sensor Stuck

OFF

OFF

ON

ON

(see page 19-128)

-23

Yaw Rate Sensor Circuit Intermittent Interruption

OFF

OFF

ON

ON

(see page 19-127)

-24

Yaw Rate Sensor Gain Low

OFF

OFF

ON

ON

(see page 19-128)

-25

Yaw Rate Sensor Gain High

OFF

OFF

ON

ON

(see page 19-128)

26

Lateral Acceleration Sensor Internal Circuit
Malfunction (Initial)

OFF

OFF

ON

ON

(see page 19-126)

-12

Lateral Acceleration Sensor Internal Circuit
Malfunction (Open, Short)

OFF

OFF

ON

ON

(see page 19-126)

-13

Lateral Acceleration Sensor Communication Error

OFF

OFF

ON

ON

(see page 19-126)

-21

Lateral Acceleration Sensor Neutral Position
Malfunction

OFF

OFF

ON

ON

(see page 19-129)

-22

Lateral Acceleration Sensor Stuck

OFF

OFF

ON

ON

(see page 19-129)

-23

Lateral Acceleration Sensor Circuit Intermittent
Interruption

OFF

OFF

ON

ON

(see page 19-129)

-24

Lateral Acceleration Sensor Gain Low

OFF

OFF

ON

ON

(see page 19-128)

-25

Lateral Acceleration Sensor Gain High

OFF

OFF

ON

ON

(see page 19-128)

27

-11

Steering Angle Sensor DIAG Signal Error (Initial)

OFF

OFF

ON

ON

(see page 19-130)

-21

Steering Angle Sensor Stuck Neutral Position

OFF

OFF

ON

ON

(see page 19-132)

-22

Steering Angle Sensor Stuck Offset Position

OFF

OFF

ON

ON

(see page 19-132)

-23

Steering Angle Sensor Counter Malfunction

OFF

OFF

ON

ON

(see page 19-135)

-24

Steering Angle Sensor Exchange Malfunction

OFF

OFF

ON

ON

(see page 19-135)

-26

Steering Angle Sensor DIAG Signal Error (Main)

OFF

OFF

ON

ON

(see page 19-130)

31

-01

ABS Right-front Inlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Right-front Inlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Right-front Inlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Right-front Inlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

32

-01

ABS Right-front Outlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Right-front Outlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Right-front Outlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Right-front Outlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

2: ’07-08 models
3: ’09 model

-11

-14

-15

-16

-17

-18

-19

-11

2

2

2

2

3

3

3

2

08/08/21 15:04:51 61SNR030_190_0101

DTC

Detection Item

ABS

Indicator

Brake

System

Indicator

VSA

Indicator

VSA

Activation

Indicator

Note

19-102

VSA System Components

33

-01

ABS Left-front Inlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Left-front Inlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Left-front Inlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Left-front Inlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

34

-01

ABS Left-front Outlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Left-front Outlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Left-front Outlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Left-front Outlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

35

-01

ABS Right-rear Inlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Right-rear Inlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Right-rear Inlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Right-rear Inlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

36

-01

ABS Right-rear Outlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Right-rear Outlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Right-rear Outlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Right-rear Outlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

37

-01

ABS Left-rear Inlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Left-rear Inlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Left-rear Inlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Left-rear Inlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

38

-01

ABS Left-rear Outlet Solenoid Valve Malfunction
(Solenoid Initial Pulse)

ON

ON

ON

ON

(see page 19-136)

-21

ABS Left-rear Outlet Solenoid Valve Malfunction
(Solenoid Pulse)

ON

ON

ON

ON

(see page 19-136)

-22

ABS Left-rear Outlet Solenoid Valve Malfunction
(Solenoid Speculative)

ON

ON

ON

ON

(see page 19-136)

-23

ABS Left-rear Outlet Solenoid Valve Malfunction
(Solenoid Stuck ON)

ON

ON

ON

ON

(see page 19-136)

41

-21

Right-front Wheel Lock

ON

ON/OFF

ON

ON

(see page 19-137)

42

-21

Left-front Wheel Lock

ON

ON/OFF

ON

ON

(see page 19-137)

43

-21

Right-rear Wheel Lock

ON

ON/OFF

ON

ON

(see page 19-137)

44

-21

Left-rear Wheel Lock

ON

ON/OFF

ON

ON

(see page 19-137)

51

-11

Motor Lock

ON

OFF

ON

ON

(see page 19-138)

-12

Motor Lock Circuit Malfunction

ON

OFF

ON

ON

(see page 19-138)

-13

Motor Relay OFF Malfunction

ON

OFF

ON

ON

(see page 19-138)

52

-12

Motor Stuck OFF

ON

OFF

ON

ON

(see page 19-140)

53

-01

Motor Relay Stuck ON 1

ON

OFF

ON

ON

(see page 19-141)

-12

Motor Relay Stuck ON 2

ON

OFF

ON

ON

(see page 19-141)

54

-03

Fail-safe Relay 1 Stuck ON

ON

ON

ON

ON

(see page 19-142)

-04

Fail-safe Relay 1 Stuck OFF (Initial)

ON

ON

ON

ON

(see page 19-142)

-21

Fail-safe Relay 1 Stuck OFF (Main)

ON

ON

ON

ON

(see page 19-142)

56

-01

Initial VIG FET Stuck OFF

ON

ON

ON

ON

(see page 19-142)

-02

Initial VIG FET Stuck ON

ON

ON

ON

ON

(see page 19-142)

-11

VIG FET Stuck OFF

ON

ON

ON

ON

(see page 19-142)

1: Brake system indicator turns ON when two or more wheels fail.

1

1

1

1

08/08/21 15:04:51 61SNR030_190_0102

DTC

Detection Item

ABS

Indicator

Brake

System

Indicator

VSA

Indicator

VSA

Activation

Indicator

Note

19-103

61

-01

VSA Modulator-control Unit Initial IG Low Voltage

ON

ON

ON

ON

(see page 19-143)

-21

VSA Modulator-control Unit Power Source Low
Voltage 1

ON

ON

ON

ON

(see page 19-143)

-22

VSA Modulator-control Unit Power Source Low
Voltage 2

ON

OFF

ON

ON

(see page 19-143)

-23

VSA Modulator-control Unit Power Source Low
Voltage 3

ON

ON

ON

ON

(see page 19-143)

62

-21

VSA Modulator-control Unit IG High Voltage

ON

ON

ON

ON

(see page 19-144)

64

-11

Steering Angle Sensor Power Circuit Short

OFF

OFF

ON

ON

(see page 19-144)

-12

Steering Angle Sensor Power Circuit Open

OFF

OFF

ON

ON

(see page 19-145)

65

-21

Brake Fluid Level Stuck ON

OFF

OFF

ON

ON

(see page 19-147)

66

-11

Pressure Sensor (Inside of VSA Modulator-control
Unit) Malfunction

OFF

OFF

ON

ON

(see page 19-148)

-12

Pressure Sensor (Inside of VSA Modulator-control
Unit) Malfunction

OFF

OFF

ON

ON

(see page 19-148)

-13

Pressure Sensor (Inside of VSA Modulator-control
Unit) Malfunction

OFF

OFF

ON

ON

(see page 19-148)

-14

Pressure Sensor (Inside of VSA Modulator-control
Unit) Malfunction

OFF

OFF

ON

ON

(see page 19-148)

-15

Pressure Sensor (Inside of VSA Modulator-control
Unit) Malfunction

OFF

OFF

ON

ON

(see page 19-149)

-16

Pressure Sensor (Inside of VSA Modulator-control
Unit) Malfunction

OFF

OFF

ON

ON

(see page 19-148)

68

-21

Brake Pedal Position Switch Stuck OFF

OFF

OFF

ON

ON

(see page 19-149)

-22

Brake Pedal Position Switch Stuck ON

OFF

OFF

ON

ON

(see page 19-151)

71

-21

Right-front or Left-rear Different Diameter Tire
Malfunction

ON

ON

ON

ON

(see page 19-152)

-22

Left-front or Right-rear Different Diameter Tire
Malfunction

ON

ON

ON

ON

(see page 19-152)

-23

Right-front and Right-rear Different Diameter Tire
Malfunction

ON

ON

ON

ON

(see page 19-152)

-24

Left-front and Left-rear Different Diameter Tire
Malfunction

ON

ON

ON

ON

(see page 19-152)

-25

Right-front and Left-front Different Diameter Tire
Malfunction

ON

ON

ON

ON

(see page 19-152)

-26

Right-rear and Left-rear Different Diameter Tire
Malfunction

ON

ON

ON

ON

(see page 19-152)

-27

Right-front or Left-rear Different Diameter Tire
Malfunction

OFF

OFF

ON

ON

(see page 19-152)

-28

Left-front or Right-rear Different Diameter Tire
Malfunction

OFF

OFF

ON

ON

(see page 19-152)

-29

Right-front and Right-rear Different Diameter Tire
Malfunction

OFF

OFF

ON

ON

(see page 19-152)

-2A

Left-front and Left-rear Different Diameter Tire
Malfunction

OFF

OFF

ON

ON

(see page 19-152)

-2B

Right-front and Left-front Different Diameter Tire
Malfunction

OFF

OFF

ON

ON

(see page 19-152)

-2C

Right-rear and Left-rear Different Diameter Tire
Malfunction

OFF

OFF

ON

ON

(see page 19-152)

81

-01

ON

ON

ON

ON

(see page 19-153)

-02

ON

ON

ON

ON

(see page 19-153)

-03

ON

ON

ON

ON

(see page 19-153)

-05

ON

ON

ON

ON

(see page 19-153)

-06

ON

ON

ON

ON

(see page 19-153)

-07

ON

ON

ON

ON

(see page 19-153)

-08

ON

ON

ON

ON

(see page 19-153)

-11

ON

ON

ON

ON

(see page 19-153)

-12

ON

ON

ON

ON

(see page 19-153)

-13

ON

ON

ON

ON

(see page 19-153)

-14

ON

ON

ON

ON

(see page 19-153)

-21

ON

ON

ON

ON

(see page 19-153)

-22

ON

ON

ON

ON

(see page 19-153)

-23

ON

ON

ON

ON

(see page 19-153)

Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction

08/08/21 15:04:52 61SNR030_190_0103

DTC

Detection Item

ABS

Indicator

Brake

System

Indicator

VSA

Indicator

VSA

Activation

Indicator

Note

19-104

VSA System Components

81

-31

ON

ON

ON

ON

(see page 19-153)

-32

ON

ON

ON

ON

(see page 19-153)

-33

ON

ON

ON

ON

(see page 19-153)

-35

ON

ON

ON

ON

(see page 19-153)

-36

ON

ON

ON

ON

(see page 19-153)

-37

ON

ON

ON

ON

(see page 19-153)

-38

ON

ON

ON

ON

(see page 19-153)

-39

ON

ON

ON

ON

(see page 19-153)

-3A

ON

ON

ON

ON

(see page 19-153)

-3C

ON

ON

ON

ON

(see page 19-153)

-3D

ON

ON

ON

ON

(see page 19-155)

-3E

ON

ON

ON

ON

(see page 19-155)

-40

ON

ON

ON

ON

(see page 19-153)

-41

ON

ON

ON

ON

(see page 19-153)

-42

ON

ON

ON

ON

(see page 19-153)

-51

ON

ON

ON

ON

(see page 19-154)

-52

ON

ON

ON

ON

(see page 19-153)

-53

ON

ON

ON

ON

(see page 19-154)

-54

ON

ON

ON

ON

(see page 19-153)

-55

ON

ON

ON

ON

(see page 19-154)

-56

ON

ON

ON

ON

(see page 19-153)

-57

ON

ON

ON

ON

(see page 19-154)

-58

ON

ON

ON

ON

(see page 19-153)

-59

ON

ON

ON

ON

(see page 19-155)

-61

ON

ON

ON

ON

(see page 19-153)

-71

ON

OFF

ON

ON

(see page 19-153)

-80

ON

ON

ON

ON

(see page 19-153)

83

-13

ECM/PCM Communication Error

OFF

OFF

ON

ON

(see page 19-155)

-14

ECM/PCM Communication Error

OFF

OFF

ON

ON

(see page 19-155)

84

-21

VSA Sensor Neutral Position Not Writing

OFF

OFF

ON

ON

(see page 19-156)

86

-01

F-CAN Bus-off Malfunction

OFF

OFF

ON

ON

(see page 19-156)

-11

F-CAN Communication with ECM/PCM Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-21

F-CAN Communication with Engine Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-22

F-CAN Communication with Engine Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-23

F-CAN Communication with Engine Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-24

F-CAN Communication with Engine Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-25

F-CAN Communication with Engine Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-31

F-CAN Communication with Gauge Control Module
Malfunction

OFF

OFF

ON

ON

(see page 19-159)

F-CAN Communication with EAT Malfunction

OFF

OFF

ON

ON

(see page 19-157)

-71

F-CAN Communication with Yaw Rate-Lateral
Acceleration Sensor Malfunction

OFF

OFF

ON

ON

(see page 19-160)

107

-22

Central Processing Unit (CPU) Internal Circuit
Malfunction

OFF

OFF

OFF

ON

(see page 19-162)

108

-21

Steering Angle Sensor Malfunction

OFF

OFF

OFF

ON

(see page 19-162)

112

-01

Central Processing Unit (CPU) Internal Circuit
Malfunction

ON

ON

ON

ON

(see page 19-163)

121

-01

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-02

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-11

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-21

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-24

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

122

-01

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-21

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-22

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-23

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

123

-01

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-02

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-11

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-21

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-24

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

124

-01

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-21

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-22

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

-23

VSA Solenoid Valve Malfunction

ON

ON

ON

ON

(see page 19-164)

4: A/T

Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction
Central Processing Unit (CPU) Internal Circuit Malfunction

-41

4

08/08/21 15:04:52 61SNR030_190_0104
