Section MP Colour Code B = Black G = Green K = Pink LG = Light Green N = Brown O = Orange P = Purple R = Red S = Slate U = Blue W = White Y = Yellow Abbreviations ABS Anti-lock Brake System ACCM Air Conditioning Control Module ACHC Air Conditioning Harness Connector ACIS
Acoustic Control Induction System CDL Central Door Locking CHMSL Centre High Mounted Stop Lamp CVCV Canister Vent Close Valve DDHC Driver's Door Harness Connector DI Direction Indicator ECU Electronic Control Unit EHC Engine Harness Connector FL Fog Lamp FSM Front Side Marker FTC Fuel Tank Connector GND Ground IP
Instrument Pack LF Left Front LIHC Left Inner Harness Connector LOHC Left Outer Harness Connector LR Left Rear MB Main Beam NPL Number Plate Lamp O2 Oxygen (sensor) PDHC Passenger's Door Harness Connector RF Right Front RIHC Right Inner Harness Connector RIL Rear Outer Lamp RMC Rear Module Connector ROHC Right Outer Harness Connector ROL Rear Outer Lamp RR Right Rear RSM Rear Side Marker SL Side Lamp SPL Splice SPMC Switch Pack Module Connector SSWHC Starter Switch Harness Connector TMAF Temperature & Mass Air Flow VSV Vacuum Solenoid Valve VVT Variable Valve Timing VVTLi Variable Valve Timing & Lift - intelligent WSS Wheel Speed Sensor YMC Yazaki Module Connector sn_mp_ cyclone.indd 40 02/01/2008 04:42:19 |
