1. Check Velcro fasteners on wing and cover for wing flange and replace if necessary. See: Additional assembly instructions for replacing Velcro fasteners Installing cover for wing flange 2. Insert cover for wing flange -2- sideways into the trim panel for the lock support -1- ( -arrows A- ). 3. Slide cover for wing flange -2- with the soft lip under the luggage compartment seal and press on Locking cover for wing flange into place 4. Lock cover for wing flange into place in plenum panel. Securing trim panel 5. Insert locking lug for trim panel for lock support -1- into the wing at the side -2- . 6. Close front lid. Diagnostic system: reading out fault memory and activating systems Installing cover for wing flange 2945 |
