Replacing the Carrera model logo 1. Find the middle of the lid. Logo Carrera 2. Position logo -Carrera- with the dimensions -A und C- → dimension: 129.6 mm +/-1 mm and -B- → dimension: 45 mm -1 mm and stick on lid. 997110, 997111, 997310, 997311 WARNUNG Gefahr des Verlusts der Text-Bild-Zuordnung beim Ausdruck. Aus technischen Gründen kann derzeit nicht ausgeschlossen werden, dass trotz • Wird der Fehler nicht bemerkt, besteht die Gefahr, daß Arbeiten nicht korrekt • → Vergleichen Sie deshalb nach dem Druckvorgang unbedingt die Ausdrucke mit der WARNING Danger of losing text-figure correspondence when printing out. For technical reasons, it can currently not be ruled out that the correspondence • Diagnostic system: reading out fault memory and activating systems Replacing the Carrera model logo 2645 |
