Porshe 911 (997). Manual - part 555

Main illustration, removing and installing front spoiler

Disconnecting electrical plug connection

1. Disconnect wiring harness -1- . Press lug -arrow A- and pull plug connection apart -arrow B- .

Removing hose for headlight cleaning system

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Disconnecting electrical plug connection

2377

Main illustration, removing and installing front spoiler

Note

Only in vehicles with headlight cleaning system!

•

Note

A tight hose can be pulled off more easily if it is heated with a hot-air gun!

•

Collect windscreen washer system fluid with a suitable container.

•

Removing hose for headlight cleaning system

1. Press in lock -2- and pull water feed line for headlight cleaning system -2- apart -direction of arrows- .

Undoing front spoiler at the top

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing hose for headlight cleaning system

2378

Main illustration, removing and installing front spoiler

Undoing front spoiler at the top

1. Open front end fixing devices -1- in  using T10118 assembly tool -2- at the guides -direction of arrow-

of the front spoiler.

Undoing front spoiler at the top

2. Unscrew fastening screws -1- at the top of the front spoiler -2- .

3. Remove front spoiler -2- by pulling it towards the front.

Diagnostic system: reading out fault memory and activating systems

Undoing front spoiler at the top

2379

Installing front apron

Securing front spoiler at the top

Installation Location:

Main illustration, removing and installing front spoiler

Note

Ensure water and electrical lines are laid properly.

•

1. Check retaining strip for front spoiler; replace if necessary. →   Removing and installing front retaining

strip

2. Check sheetmetal nuts -3- ; replace if necessary.

Securing front spoiler at the top

3. Position the front spoiler -2- on the body at the front.

4. Screw in fastening screws -1- on front spoiler -2- and tighten to required tightening torque → : 1.8 ftlb. .

Diagnostic system: reading out fault memory and activating systems

 Installing front apron

2380
