- Preliminary work
- Removing rubber seal for door
- Installing rubber seal for door
- Subsequent work

Preliminary work

Preliminary work

1. Remove A-pillar trim. → 705719 Removing and installing A-pillar trim - chapter on "Removing"

2. Remove inner sill. → 680519 Removing and installing inner sill - chapter on "Removing"

Removing rubber seal for door

Removing cover of three-point seat belt

Installation Location:

2041

Installation position for side trim panel

Removing cover of three-point seat belt

1. Pull cover of three-point seat belt -1- forwards out of the clips -2- .

Removing rubber seal for door

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing cover of three-point seat belt

2042

Installation position of rubber seal for door

Removing rubber seal for door

1. Unscrew fastening screw -2- and pull out rubber seal for door -1- under the cover strip -3- -Arrow

A-

 .

2. Remove rubber seal for door -1- from around the sheetmetal flange.

Installing rubber seal for door

Installing rubber seal for door

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing rubber seal for door

2043

Installation position of rubber seal for door

Note

The rubber seal for the door must be fitted by hand.

•

Pay particular attention to the areas near the tight roundings for correct installation; there must be
no deformation or stretching.

•

Check the air vents; they must not be closed or covered.

•

Installing rubber seal for door

1. Push rubber seal for door -1- all around the sheetmetal flange.

2. Push rubber seal for door -1- under the cover strip -3- -Arrow A- and screw down with the

fastening screw -2- . Tightening torque → Tightening torque : 6 (4.5 ftlb.) Nm

Diagnostic system: reading out fault memory and activating systems

Installing rubber seal for door

2044
