81

MAINTENANCE

Intake Filters

The intake foam filter limits
snow ingestion into the intake
system. When operating in loose
powder snow, check the top of
the foam filter periodically to
remove any accumulation of
snow.

CAUTION

Operating the snowmobile with the intake filters removed may cause intake

icing. The result will be poor fuel economy or intake malfunction. Always rein-

stall the intake filters before operating the snowmobile.

Intake Foam Filters/Pre-filter

82

MAINTENANCE

Fuel Injectors (Fuel Injected Models)

All fuel injector service must be performed by an authorized Polaris
dealer. Do not attempt to clean or service the fuel injectors.

Fuel Pump

All fuel pump service must be performed by an authorized Polaris
dealer. Do not attempt to service the fuel pump.

Fuel Filter

See your Polaris dealer for replacement of the fuel filter at the intervals
outlined in the Periodic Maintenance Table beginning on page 72.

Fuel Lines

Inspect the fuel lines regularly for signs of deterioration or damage.
Always check fuel line condition after periods of storage. Normal dete-
rioration from weather and fuel compounds may occur. Replace worn or
damaged fuel lines promptly.

Oil Lines

Inspect oil line condition at the intervals outlined in the Periodic Main-
tenance Table beginning on page 72.

Oil Filter

Have your dealer change the oil filter
and bleed the system at the intervals
outlined in the Periodic Maintenance
Table beginning on page 72.

NOTE:

The direction of the arrows indi-

cates the direction of flow

through the filter.

CAUTION

Kinking the fuel lines or using a pliers or similar tools to remove fuel lines

may cause damage to the lines. If a fuel line has been damaged or kinked,

replace it promptly.

83

MAINTENANCE

Carburetor (Carbureted Models)

The number stamped in the end of the main jet indicates the jet size. The
jet installed at the time of manufacture is not necessarily correct for your
elevation. It's your dealer's responsibility to make sure the correct main
jet is installed.

Carburetor Adjustments

The frequency at which the carburetors are synchronized or balanced is
important. Properly adjusted carburetors can greatly improve engine
performance, fuel economy, engine life, and reliability.

If you notice any of the following conditions, the carburetor may need
adjustment:

• Hard starting

• Poor idle

• Overheated pistons and cylinder walls

• Plug fouling

• Poor engine response to various throttle valve openings

CAUTION

Operating the snowmobile with incorrect jetting can result in serious engine

damage.  Have your Polaris dealer perform all carburetor adjustments to

ensure all adjustments are done correctly.

84

MAINTENANCE

Carburetor (Carbureted Models)

Carburetor Water/Sediment Trap

Most Polaris snowmobiles contain patented carburetor bowl water/sedi-
ment traps located at the bottom of each carburetor. The trap, consisting
of a hose with a plug, should be drained about every 1000 miles (1600
km) and inspected for contamination.

Cleaning Procedure
1. Turn the fuel valve off.

2. Place a container or shop

towels below the plug to
catch drained fuel.

3. Slide the clamp away from

the drain plug and remove
the drain plug from the sedi-
ment tube.

4. Wipe residue from the plug

and reinstall it. Reposition
and tighten the clamp.

5. Repeat the draining proce-

dure for any remaining traps.

WARNING

When draining the traps, fuel spillage will occur. Always work in a well venti-

lated area away from anything that may cause the fuel to ignite, such as open

flames, sparks, heaters, trouble lights, cigarettes, etc. Review the fuel warn-

ings on page 60.

Clamp

Drain

Plug
