Snowmobile Polaris 600 IQ LXT (2015 year). Manual - part 12

51

THE PERFECT FIT

IQ Front Suspension Adjustments

Front Shock Spring Preload

Increasing spring preload will increase
ski-to-ground pressure. Decreasing spring
preload will decrease ski-to-ground
pressure. When adjusting, be sure the
springs on both the left and right sides of
the machine are at the same adjustment.

To change front shock spring preload,
grasp the spring and rotate it.

Increasing the spring preload too much
may adversely affect the handling of the
snowmobile and the performance of the
suspension. Never exceed one inch of
preload beyond the factory settings, and
ensure that both sides are adjusted the
same. When decreasing preload, make
sure at least two turns of preload are
holding the spring between the retainer on
the top of the shock and the threaded
spring preload adjuster nut on the shock
body. Failure to do so could cause the retainer to fall off when the
suspension is fully extended.

Tip: Not all models have shocks with thread-adjustable spring preload. See your

dealer for more information.

NOTICE: On some models equipped with a plastic adjuster nut, the nut will

break if it is unscrewed from the threaded body. Do not force the nut if
resistance suddenly increases while you’re turning it.

Low

Preload

High

Preload

52

THE PERFECT FIT

IQ Front Suspension Adjustments

Shock Valving

The shocks can be revalved if spring preload alone isn't sufficient and
further adjustment is desired to control suspension stiffness.

WARNING! Changing shock valving requires special tools and a sound
knowledge of mechanical theory, tool use, and shop procedures to perform the
work safely and correctly. Shocks contain high-pressure nitrogen gas. Use
extreme caution when handling high-pressure service equipment. We
recommend that this work be performed by a POLARIS dealer.

53

THE PERFECT FIT

Rear Suspension Adjustments

Rider weight, riding style, trail conditions, and vehicle speed all affect
suspension action.

Each rear suspension can be adjusted to suit rider preference and deliver
excellent performance for a given set of conditions. However, all
suspension designs and adjustments involve a compromise, or trade-off.
For example, a suspension set up for snow-cross racing would provide a
very stiff ride on the trail. A suspension set up for trail riding would
bottom out harshly on a snow-cross course.

Refer to the suspension setup label on your snowmobile, or see your
POLARIS dealer for initial suspension setup information. Additional
adjustments can be made after initial setup. Make adjustments to one
area at a time so you can evaluate the change. For further assistance, see
your dealer.

Suspension Performance Tips

• Rider weight usually determines the position at which the spring

preload should be set. However, this may vary with riding style. With
a little experimentation, each rider can find a preferred set-up. These
adjustments are easy to make, involve very little time or effort, and
greatly affect the ride.

• In deep snow, a new rail slide will offer improved performance over a

worn slide. It can also improve top speed.

• When riding on ice or hard-packed snow, adding a set of bogie wheels

to the rail may enhance the machine's performance. Bogie wheel kits
are available from your dealer.

• POLARIS offers track kits for improved flotation in deep snow. See

your dealer for assistance.

Tip: Keep the suspension pivot points lubricated. This will reduce moisture and

rust build-up and ensure proper function of the suspension components.
Grease rear suspension pivots before adjusting the rear suspension. Refer
to the suspension lubrication information beginning on page 89.

54

THE PERFECT FIT

IQ Rear Suspension Adjustments

Initial Spring Preload Setting (Sag Method)

To set up the rear suspension torsion
spring preload, measure the distance
between the ground and rear bumper.
This is measurement X.

Take the first measurement with no
rider and with the rear suspension at
full extension.

Tip: The rear bumper may need to be

lifted upward slightly to fully extend
the rear suspension.

Next, have the rider drop down hard
on the seat and bounce up and down
several times, collapsing the rear
suspension. With the rider seated,
measure the distance between the
ground and the rear bumper at the
exact location used for measurement
X. This is measurement Y.

To determine sag, commonly referred to as ride-in, subtract
measurement Y from X (sag=X-Y). If the measured sag is incorrect,
adjust the FRA position and/or rear torsion spring preload.

Tip: This is only an initial setup, and final spring preload may vary based on rider

preference and riding conditions. Accessory springs with a higher load rat-
ing are available for some models. Please see your dealer for availability.

Suspension

Recommended Sag

Adjustment

See

Page

IQ Comfort

(136)

4-5 inches (10-13 cm)

Torsion Spring

Preload

55

X

Y

With Rider

No Rider
