31

FEATURES

Adjustable Headlights

Move the adjuster to the left to lower the
headlight beam.

Move the adjuster to the right to raise the
headlight beam.

Radiator Compartment
Access Panel

The access panel is provided for cleaning
debris from the radiator.

Cargo Bag

The cargo bag is secured to the rear
of the tunnel with straps. The cargo
bag and the passenger seat are
removable to provide open storage
for transporting larger items. The
maximum weight capacity for the
cargo area is 30 lbs. (14 kg). Always
secure cargo before operating. Do not
exceed the weight limit. Do not allow
a passenger to sit on the seat back or
the cargo area.

Seat Latch

1. Push down on the seat latch lever, which is located at the lower rear

of the passenger seat.

2. Lift up the seat and remove it from the chassis.

3. Reverse the procedure to reinstall the seat. Press down firmly on

both sides of the seat to engage the latch. Verify that the latch is
engaged by firmly pulling the seat upward.

X

X

Cargo

Bag

Seat Latch

32

FEATURES

Passenger Grab Handle

On some models the position of the passenger grab handles can be
adjusted for rider preference.

1. Unscrew and remove the knob assemblies that secure the grab

handles.

2. Reposition the grab handles to one of the three available positions

on the grab handle tube between the operator seat and the passenger
seat.

3. Reinstall the knob assemblies and tighten securely.

33

FEATURES

RIDER SELECT Adjustable Steering System

The RIDER SELECT adjustable steering system (if equipped) allows
you to adjust the handlebar position to fit your style of riding. Some
models have five (5) adjustment positions. Other models have seven (7)
positions.

WARNING! If your snowmobile has five adjustment positions, do not remove
the RIDER SELECT lockout. Your POLARIS snowmobile has been engineered
for this range of adjustability. Removing this lockout and using RIDER SELECT
position 6 or 7 will result in the handlebars and brake lever contacting other
components and interfering with steering and braking. This could lead to loss of
control resulting in serious injury or death. Always be sure that the handlebars
and brake lever do not contact any other snowmobile components at any
steering position AND at any RIDER SELECT position.

Do not use RIDER SELECT positions 6 or 7 unless riding conditions require it.
Operation in position 6 or 7 can reduce vehicle handling for other types of riding
and result in serious injury or death.

Choosing the Best RIDER SELECT Position

Position

Riding Style

1
2
3

Relaxed Trail Riding
Rider weight is slightly behind the center
of the snowmobile for comfortable and
relaxed riding.

4
5

General Trail Riding, Boondocking,
Deep Snow Riding
Rider weight is centered on the snowmo-
bile, providing balance, comfort and con-
trol for both novice and experienced
riders. This is the recommended position
for most riding situations.

6
7

Snowcross/Steep Hill Climbing Only
Rider weight is ahead of the center of the
snowmobile, adding weight to the skis and
making the snowmobile heavier in the
front. These positions are ONLY for snow-
cross and severe hill climbing.

34

FEATURES

RIDER SELECT Adjustable Steering System

WARNING! Attempting to adjust the handlebar position while the snowmobile is
moving could result in loss of control and serious injury or death. Always stop
the snowmobile before attempting to adjust the steering system.

1. Stop the snowmobile.

2. Press the release button

and move the handlebar
forward or rearward to
the desired position.

WARNING! Do not lubricate the RIDER SELECT mechanism. Doing so could
cause loss of control and result in serious injury or death. The RIDER SELECT
mechanism is lubricated for life at the factory.

WARNING! Some aftermarket accessories (including windshields and cargo
bags) may interfere with the handlebar. Such accessories could limit your ability
to steer the vehicle and/or may contact the brake lever. This could lead to loss of
control resulting in serious injury or death. Always be sure that accessories do
not contact the handlebar or brake lever at any steering position and at any
RIDER SELECT position.
