57

OPERATION

Emergency Stopping

The following chart lists methods for stopping the snowmobile in the
event of an emergency. Refer to page 55 for more information about the
engine stop switch and throttle safety switch.

Emergency Starting

Your snowmobile is equipped with a tool kit containing essential tools
for emergency use. Snowmobiles equipped with electric start have a
recoil for emergency starting. If the recoil starter system fails, an
emergency start strap is provided in the kit.

SYSTEM

WHAT IT DOES

THROTTLE

CONDITION

Ignition Switch

Interrupts ignition circuit

All

Brake

Slows jackshaft

All

Choke

Floods engine

Half throttle or less

Engine Stop Switch

Interrupts ignition circuit

All

Throttle Safety Switch

Interrupts ignition circuit

All

58

OPERATION

Reverse Operation

WARNING! Improper reverse operation, even at low speeds, may cause loss of
control, resulting in serious injury or death. Damage will occur to the gearcase or
transmission if shifting is attempted when the engine is operating above idle
speed.

• Shift to or from reverse only when the snowmobile is stopped and when

engine speed is at idle.

• Look behind the vehicle before and while backing.

• Avoid sharp turns.

• Apply throttle slowly.

Mechanical Reverse

Make sure the shift lever is shifted completely into forward or reverse
position. Some models are equipped with a reverse indicator light that
will help you make that determination.

Do not force the shift lever into
reverse if resistance is felt. The
gears may not always be
aligned for shifting into
reverse, and forcing the lever
may cause damage. If
resistance is felt, gently apply
the throttle to move the gears to
a different position and try to
shift again.

The transmission may not
always be in the gear indicated
by the shift lever. Apply the throttle slowly until you're sure which gear
is engaged.

Sometimes the drive belt will drag in the drive clutch, causing slight
tension in the transmission and making it hard to shift. Shutting the
engine off will remove this tension and ease shifting. This should only
happen during the break-in of a new belt or when the drive/driven clutch
center distance is too long. If this is the case, belt tension adjustments
should be made by your dealer.

Shifter

59

OPERATION

Towing

Do not use the front bumper to pull or drag the snowmobile. The front
bumper is not designed for this type of use and may detach from the
vehicle if force is applied.

Whenever towing or operating with a heavy load, place the transmission
in low gear. Towing in high gear can result in belt damage.

NOTICE: When operating in low gear, never exceed 25 MPH (40 km/h). Serious

engine damage may occur.

For your safety, do not attempt to using the tow hitch until you’ve read
the following warnings and understand the proper hitch functions.

WARNING! Objects towed with a rope have no braking power and can easily
collide with the rear of the snowmobile or other objects, resulting in serious
injury or death. DO NOT tow toboggans, sleds, saucers, or any type of vehicle
with a rope. Only a stiff metal pole connecting the towed object and the tow hitch
on the snowmobile should be used. If passengers are to be towed on a
toboggan or sled, make sure the pole is at least four feet (1.2 meters) long to
prevent any possibility of contact between the snowmobile's track and a person
riding in the towed object. Braking distances increase when towing loads. Slow
down to maintain control of the snowmobile.

If the snowmobile becomes inoperable and must be towed, and if it isn’t
possible to use a rigid tow bar, attach the tow rope to the ski spindles
(not to the ski loops) to prevent damage to the steering components.
Place the transmission in neutral, and have a rider on the towed
snowmobile to operate the brake and steering when necessary.

NOTICE: Towing a disabled snowmobile with the transmission in gear can result

in serious damage to the engine and drive system. Always place the
transmission of the disabled snowmobile in neutral before towing.

60

MAINTENANCE

Emission Control Information

Any qualified repair shop or qualified person may maintain, replace, or
repair the emission control devices or systems on your snowmobile.

Emission Control Label

Your snowmobile is equipped at the time of sale with an emission
control information (ECI) label and a factory-installed emissions
information hangtag. These items are required by U.S. Environmental
Protection Agency regulations. The ECI label is permanently affixed to
either the right side of the tunnel or the engine recoil cover. The ECI
label should not be removed, even after you purchase the snowmobile.
You may remove the factory-installed emissions information hangtag,
which is intended solely for your use in making a purchasing decision.

Emission Control Maintenance Requirements

Your snowmobile is certified to operate on gasoline with a minimum
octane level of 87 (R+M)/2. If your snowmobile is equipped with a
check engine light and it comes on, you must take your snowmobile to a
qualified dealer for diagnostic service. Specifications and adjustments
for engine tune-ups are located in the Service Manual, which is
available to your qualified service technician. Reverse (if equipped)
must not be engaged during engine tune-ups.

Owner's Responsibilities

Please read the Snowmobile Engine Emissions Limited Warranty, and
read the maintenance section of your owner's manual. You are
responsible for ensuring that the specified maintenance is performed.
POLARIS recommends that you contact an authorized POLARIS dealer
to perform any service that may be necessary.

Non-ionizing Radiation

This vehicle emits some electromagnetic energy. People with active or
non-active implantable medical devices (such as heart monitoring or
controlling devices) should review the limitations of their device and the
applicable electromagnetic standards and directives that apply to this
vehicle.
