Snowmobile Polaris Widetrak LX (2014 year). Manual - part 10

41

PRE-RIDE INSPECTIONS

Before Starting the Engine

Hydraulic Brakes

Always check the following items for proper operation before starting
the engine.

Brake Lever Travel

Squeeze the brake lever. It should
move no closer to the handgrip
than 1/2 inch (1.3 cm). A smaller
distance indicates low brake fluid
level or air in the hydraulic
system. See page 77 or see your
dealer for service.

Lever Feel

If the brake lever feels “spongy” when squeezed, check the brake fluid
level and condition. Add fluid as needed.

Check for the presence of air in the fluid system. See page 77 or see
your dealer for service.

WARNING! Continued use of “spongy” brakes may cause a complete loss of
brakes, which could result in serious injury or death. Always have the brakes
serviced at the first sign of sponginess.

1/2 inch (1.3 cm)

42

PRE-RIDE INSPECTIONS

Before Starting the Engine

Parking Brake Lever Lock

Your snowmobile may have a
parking brake lever lock located
over the brake lever. Use the
brake lever lock only when you
want the snowmobile to remain
stationary; for example, when
parked on an incline for a period
of five minutes or less.

1.

Brake Lever

2.

Parking Brake Lever Lock

3.

Master Cylinder Reservoir/
Cover

4.

Fluid Level Indicator

Lock Engagement

To engage the lock, squeeze the brake lever tightly and push forward on
the lock. Hold the lock forward while releasing the brake lever.

NOTICE: If the brake lever is squeezed tightly enough, the lock will move freely

into place. Do not force the lock or it may break.

The brake light will illuminate if the parking brake lever lock is set
while the engine is running. It will also illuminate when the service
brake is in use. If the parking brake light does not come on when the
parking brake or service brake is in use, have it serviced by your dealer.

Lock Release

To release the lock, squeeze the brake lever tightly. The lock will return
to the unlocked position.

WARNING! If the parking brake lever lock is partially or entirely engaged while
riding, the brakes may overheat, resulting in brake damage. In extreme cases it
could cause a fire, which could result in serious injury or death. Always ensure
that the lever lock is completely disengaged before operating the snowmobile.

1

2

3

4

43

PRE-RIDE INSPECTIONS

Before Starting the Engine

Steering System

Manually turn the skis completely to the right and to the left. If any
difficulty is encountered, check for ice and snow build-up that may be
obstructing the steering linkage. Make sure all greasable components
are properly lubricated.

Track

WARNING! Operating the snowmobile with a damaged track increases the
possibility of track failure, which could cause loss of control resulting in serious
injury or death. Always inspect the track for damage before using the vehicle.

WARNING! Use of traction products such as studs increases the possibility of
track damage and/or failure. Driving at high speeds for extended periods of time
with marginal lubrication could severely damage track rods, break track edges,
and cause other track damage. Examples of marginal lubrication would include
frozen bodies of water without snow cover, icy trails, and no-snow conditions.

Track damage or failure caused by operation on ice or under poor
lubrication conditions voids the track warranty.

44

PRE-RIDE INSPECTIONS

Before Starting the Engine

Hood Latches

The hood of the snowmobile protects the operator from moving parts as
well as aiding in sound emission control and other functions. Under no
circumstances should your snowmobile be operated with the hood open
or removed. Always ensure that the hood straps are in good condition
and that the latches are securely in place before operating the
snowmobile.

Seat Latches

If your snowmobile is equipped with a removable seat, ensure that the
seat latches are securely in place before every use of the snowmobile.

Recoil Rope

Inspect the recoil rope and handle for excessive wear, and make sure the
knot securing the rope inside the handle is secure. If excessive wear is
found, see your POLARIS dealer for replacement.

Transmission

Make sure the transmission is not in reverse before starting the engine
(if equipped with reverse).
