25

SAFETY

Safety Decals and Locations

Operation Warning

An operation warning decal is present on the console of all Polaris

snowmobiles:

WARNING

• To avoid serious injury or death, read and understand all warnings

and the Owner’s Manual before operation. If manual is missing, con-

tact a Polaris dealer for a replacement.

• This vehicle is capable of high speeds. Buried objects or uneven

terrain can cause loss of control. Reduce speed and use extreme

caution when operating in unfamiliar terrain.

• Excessive speed, especially at night or with limited visibility, can

result in insufficient time for you to react to terrain changes, to

avoid unexpected obstacles, or to stop safely.

• Never consume alcohol or drugs before or while operating this vehi-

cle.

• In an emergency, push down the Auxiliary Shut-Off Switch, located

on the top of the throttle control assembly, to stop the engine. Then

pull the brake lever to stop.

• Always wear an approved helmet, eye protection, and adequate

clothing while operating this vehicle.

• This vehicle is designed for adult use only. Check local laws for age

requirements.

• When operating with a passenger (on approved models only),

reduce speed and allow extra space for steering and stopping. A

passenger reduces your ability to control the vehicle.

• When operating on hard-packed snow, ice, or when crossing roads,

steering and braking ability are greatly reduced. Reduce speed and

allow extra space to turn or stop.

• To maintain vehicle control on ice or hard-packed surfaces, you

should have a proper balance of ski carbides to track studs. See

Owner’s Manual for proper use of traction products.

• Repeated stops from high speed may cause fading or sudden loss

of braking ability.

• Parking brake may relax when used for long periods. Do not leave

brake engaged for more than five minutes.

• Before starting the engine, check throttle, brake, and steering for

proper operation. Make sure hood is latched. Be seated and in posi-

tion to control the vehicle.

Oil injection system: Use unmixed fuel only. Check oil level when

refueling.

26

FEATURES AND CONTROLS

1. Fuel Filler Cap (may include a fuel gauge)
2. Ignition Switch
3. Brake Lever
4. Speedometer (may include indicator/warning lights)
5. Reverse Indicator
6. Mountain Bar (accessory)
7. Engine Stop Switch (see page 58)
8. Throttle Control
9. Choke
10. Recoil Starter Handle

5

4

3

2

1

10

9

7

8

6

27

FEATURES AND CONTROLS

Some Polaris snowmobiles are equipped with special features. Controls

for these features are illustrated on this page. Not all models come with

these features. See your Owner’s Manual Supplement.

Tip: Accessories are available from your Polaris dealer.

1. Headlight Dimmer

Switch

2. Parking Brake

Lock

3. Handlebar Grip

Warmer Switch

4. Thumbwarmer

Switch

5. Electronic Reverse

Button

Fuel Valve

The fuel valve is located under the

hood. Turn the fuel valve off when-

ever the snowmobile is stored or

parked.
1. Turn the valve clockwise to

turn off the fuel supply.

2. Turn the valve counter-clock-

wise to turn on the fuel supply.

2

5

4

3

1

ON

OFF

28

FEATURES AND CONTROLS

1. Hood

2. Headlight
3. Windshield
4. Handlebar
5. Operator Seat
6. Storage Compartment
7. Taillights
8. Snow Flap
9. Track
10. Suspension
11. Trailing Arm
12. Nosepan
13. Front Bumper (do not use for pulling or dragging the snowmobile)
14. Skis

13

1

2

3

4

5

6

7

8

10

9

11

14

12
