Snowmobile Polaris Rush (2010 year). Manual - part 25

101

MAINTENANCE

Track Maintenance

Track Tension

5. Check for specified slack between the wear surface of the track clip

and the plastic slider. Refer to the Track Tension Data Chart on page

100.

If the track needs adjustment:
6. Loosen the rear idler shaft bolt.
7. Loosen the locknuts.

8. Tighten or loosen the track adjusting screws to provide equal adjust-

ment on both sides of the track.

9. Repeat the measurement on the other side of the track.

TIP: Check more frequently when the snowmobile is new.

10. Start the engine and slowly rotate the track at least five revolutions.

Let the track come to a stop (do not apply brakes).

11. Check track alignment (see page 102) and adjust as necessary.
12. Tighten the locknuts.
13. Tighten the idler shaft bolts.
14. (

n

) Torque idler shaft bolts to 35 ft. lbs. (47.5 Nm).

S

Slack Measurement

Lock Nut

Adjusting Screw

Track

10 lbs. (4.54 kg)

Shaft

Bolt

16

I

(40 cm)

102

MAINTENANCE

Track Maintenance

n

Track Alignment

Periodically check that the track is centered and running evenly on the

slide rails. Misalignment will cause excessive wear to the track and slide

rail.
1. Safely support the rear of the snowmobile with the track off the

ground.

2. Start the engine and apply a small amount of throttle until the track

turns slowly at least five complete revolutions. Stop the engine and

let the track come to a stop (do not apply brakes).

3. Inspect track alignment by

looking through the track

window to make sure the

rails (+) are evenly spaced

on each side. If the track

runs to the left, loosen the

idler shaft bolts, then

loosen the left locknut and

tighten the left adjusting

bolt. If the track runs to the

right, loosen the idler shaft

bolts, then loosen the right

locknut and tighten the

right adjusting bolt.

4. After adjustments are com-

plete, tighten the locknuts

and torque idler shaft bolts

to 35 ft. lbs. (47.5 Nm).

5. Repeat steps 2 and 3 to verify proper alignment.

+

103

MAINTENANCE

Steering System

Steering Inspection

Each week, or before a long ride, check all steering system fasteners and

tighten if necessary.

+

+

+

+

104

MAINTENANCE

Steering System

Ski Alignment

WARNING! Improper ski alignment or adjustment may cause loss of steering

control, resulting in serious injury or death. Do not attempt to change the ski

alignment or camber adjustment. See your Polaris dealer.

With the handlebars in a straight ahead position, and with vehicle

weight compressing the suspension, measure from the straight edge of

the skis at the center of the ski mounting bolt. The measurement

between the skis at point X should be 1/8I to 1/4I (3-6 mm) greater

than the measurement at point Y.

TIP: If the skis are misaligned, we recommend that your dealer correct the align-

ment, since camber adjustment may also be affected.

10

I

X

10

I

Y
