112

MAINTENANCE

Brakes

Brake Fluid

Inspect the level of the brake fluid before each operation. If the fluid

level is low add DOT 4 brake fluid only. See page 134 for the part

numbers of POLARIS products.

WARNING! After opening a bottle of brake fluid, always discard any unused

portion. Never store or use a partial bottle. Brake fluid is hygroscopic, meaning it

rapidly absorbs moisture from the air. The moisture causes the boiling

temperature of the brake fluid to drop, which can lead to early brake fade and

the possibility of accident or severe injury.

Change the brake fluid every two

years and any time the fluid

becomes contaminated, the fluid

level is below the minimum, or if

the type and brand of the fluid in

the reservoir are unknown.

Access the brake fluid reservoir

through the left front wheel well.
1. Position the vehicle on a level

surface.

2. Place the transmission in

PARK.

3. Remove the front box cover

and access panel. See page

27.

4. View the brake fluid level in

the reservoir. The level

should be between the

maximum and minimum

level lines.

5. If the fluid level is lower than

the lower level line, add

brake fluid to the upper line.

6. Apply the brake forcefully for a few seconds and check for fluid

leakage around the fittings.

Brake Fluid

Reservoir

Brake Fluid Reservoir

Maximum

Minimum

113

MAINTENANCE

Brakes

Brake Inspection

1. Check the brake system for fluid

leaks.

2. Check the brake pedal for

excessive travel or a spongy feel.

3. Check the friction pads for wear,

damage and looseness.

4. Check brake discs for signs of

cracks, excessive corrosion,

warping or other damage. Clean

any grease using an approved

brake cleaner or alcohol.

WARNING! Do not apply WD-40 or any

petroleum product to brake discs. These

types of products are flammable and may

also reduce the friction between the brake

pad and caliper.

5. Inspect the brake disc spline and pad wear surface for excessive

wear. Change pads when worn to 0.030” (0.762 mm).

0.030" (0.762mm)

114

MAINTENANCE

Steering Wheel Inspection

Check the steering wheel for specified freeplay and smooth operation at

the intervals outlined in the Periodic Maintenance Chart beginning on

page 85.
1. Position the vehicle on level ground.
2. Lightly turn the steering wheel left and right.
3. There should be 0.8”-1.0” (20-25 mm) of freeplay.
4. If there is excessive freeplay or strange noises, or the steering feels

rough or “catchy,” have the steering system inspected by an

authorized POLARIS dealer.

Rear Spring

The rear shock absorber spring is adjusted

by rotating the adjuster either clockwise

or counter-clockwise to increase or

decrease spring tension.
Accessory springs are available through

your POLARIS dealer.

Adjuster

115

MAINTENANCE

Tires

Operating your vehicle with worn tires will increase the possibility of skidding,

loss of control and an accident, which could result in serious injury or death.

Always replace tires when the tread depth measures 1/8” (3 mm) or less.
Improper tire inflation or the use of non-standard size or type of tires may

adversely affect vehicle handling, which could result in vehicle damage or

personal injury. Always maintain proper tire pressure. Always use POLARIS-

approved size and type of tires for this vehicle when replacing tires.

Tire Tread Depth

Always replace tires

when tread depth is

worn to 1/8” (3 mm) or

less.

Axle and Wheel Nut Torque Specifications

Inspect the following items occasionally for tightness, and if they've

been loosened for maintenance service. Do not lubricate the stud or the

lug nut.

Lug Nut

(Aluminum

Wheels)

Front and Rear

30 ft-lbs (41 Nm)

PLUS 1/4 TURN or

90 degrees

2-Piece Flange

Nut (Steel

Wheels)

Front and Rear

27 ft-lbs (37 Nm)

Hub Retaining Nut

Front and Rear

80 ft-lbs (108 Nm)

WARNING

1/8" (3 mm)
