97

MAINTENANCE

Cleaning and Storage

Storage Tips

Inspect and Lubricate
Inspect all cables and lubricate all areas of the vehicle as

recommended in the Periodic Maintenance Chart beginning on page

57.
Fog the Engine
1. Treat the fuel system with POLARIS Carbon Clean or other

equivalent fuel treatment. Follow the instructions on the container.

Start the engine. Allow it to idle for several minutes so the Carbon

Clean reaches the injectors. Stop the engine.

2. Remove the spark plug and add 2-3 tablespoons of engine oil. To

access the plug hole, use a section of clear 1/4” hose and a small

plastic squeeze bottle filled with the pre-measured amount of oil.

3. Reinstall the spark plug. Torque to specification. See page 71.
4. Apply dielectric grease to the inside of the spark plug cap. Do not

reinstall the cap onto the plug at this step.

5. Turn the engine over several times. Oil will be forced in and

around the piston rings and ring lands, coating the cylinder with a

protective film of fresh oil.

6. If fuel system additive is not used, fuel tank, fuel lines, and

injectors should be completely drained of gasoline.

7. Reinstall the spark plug cap to the spark plug.

98

MAINTENANCE

Cleaning and Storage

Removal from Storage

1. Check the battery and charge if necessary. Install it in the vehicle.
2. Make sure the spark plug is tight.
3. Fill the fuel tank with fuel.
4. Check all the points listed in the Daily Pre-Ride Inspection section

on page 43. Tightness of the bolts, nuts and other fasteners should

be checked by an authorized POLARIS dealer or other qualified

service facility.

5. Lubricate at the intervals outlined in the Periodic Maintenance

Chart beginning on page 57.

Battery Maintenance
See pages 90-92 for storage and charging procedures.
Storage Area/Covers
Be sure the storage area is well ventilated. Cover the vehicle with a

genuine POLARIS cover. Do not use plastic or coated materials. They

do not allow enough ventilation to prevent condensation, and may

promote corrosion and oxidation.

99

MAINTENANCE

Transporting the Vehicle

Follow these procedures when transporting the vehicle.
1. Place the transmission in neutral. Set the

parking brake.

2. Stop the engine.
3. Remove the key to prevent loss during

transporting.

4. Secure the fuel cap and seat. Ensure that

the seat is attached correctly and is not

loose.

NOTICE: Always tie the frame of the POLARIS

vehicle to the transporting unit securely

with suitable straps or rope. Do not attach

tie straps to the front control arm bolt

pockets.

5. Wrap the front tie strap through the frame

tubes, or attach a tie-down hook around

each of the tubes.

6. Wrap the rear tie strap around the swing

arm.

Step 5

Step 5

Step 6

Tubes

100

SPECIFICATIONS

ACE 150 EFI

Maximum Rider Weight

180 lbs. (81 kg)

Maximum Weight Capacity

230 lbs. (104 kg)

Gross Vehicle Weight

802 lbs. (364 kg)

Dry Weight

572 lbs. (260 kg)

Fuel Capacity

2.5 gal. (9.5 ltr)

Engine Oil Capacity

35.5 oz. (1050 ml)

Transmission Oil Capacity

25 oz. (750 ml)

Overall Length

85 in. (216 cm)

Overall Width

48 in. (122 cm)

Overall Height

58 in. (147.3 cm)

Wheelbase

65 in. (165 cm)

Ground Clearance

9 in. (22.9 cm)

Engine Type

4-Stroke

Displacement

149 cc

Cooling

Air + Oil

Bore x Stroke

57.4 mm x 57.8 mm

Alternator Output

180 watts

Compression Ratio

9.5:1

Starting System

Electric

Fuel System

Electronic fuel injection
