77

MAINTENANCE

Brakes

The front and rear brakes are hydraulic disc type brakes activated by

the brake pedal. See page 38.
Always check brake pedal travel and the brake fluid reservoir level

before each use of the vehicle. When applied, the brake pedal should

feel firm. Any sponginess would indicate a possible fluid leak or low

brake fluid level, which must be corrected before riding. See page 79

for brake fluid information.
If you discover any irregularities in brake system operation, including

excessive pedal travel, contact your dealer for proper diagnosis and

repairs.

Operating the vehicle with a spongy brake pedal can result in loss of

braking, which could cause an accident resulting in severe injury or

death. Never operate the vehicle with a spongy-feeling brake pedal.

78

MAINTENANCE

Brakes

Brake Inspection

1. Check the brake system for fluid

leaks.

2. Check the brake pedal for excessive

travel or a spongy feel.

3. Check the brake pads for wear,

damage and looseness.

4. Inspect the brake pad wear surface

for excessive wear.

5. Change pads when the friction

material is worn to .04" (1 mm).

6. Check the surface condition of the

brake discs. Measure the thickness of

the front and rear discs. Replace a

disc if the thickness is less than 0.1” (2.5 mm).

7. Check brake system hoses and fittings for cracks, deterioration,

abrasion and leaks. Tighten any loose fittings and replace any

worn or damaged parts.

Brake Pad

Rear Disc

Front Disc

79

MAINTENANCE

Brakes

Brake Fluid

Inspect the level of the brake fluid before each operation. If the fluid

level is low add DOT 4 brake fluid only. See page 102 for the part

numbers of POLARIS products.

After opening a bottle of brake fluid, always discard any unused portion.

Never store or use a partial bottle. Brake fluid is hygroscopic, meaning it

rapidly absorbs moisture from the air. The moisture causes the boiling

temperature of the brake fluid to drop, which can lead to early brake

fade and the possibility of accident or severe injury.

Change the brake fluid every two years and

any time the fluid becomes contaminated, the

fluid level is below the minimum, or if the type

and brand of the fluid in the reservoir are

unknown. Access the brake fluid reservoir

through the left front wheel well.
1. Position the vehicle on a level surface.
2. Place the transmission in neutral. Set the

parking brake.

3. View the brake fluid level in the reservoir.

The level should be between the maximum

and minimum level lines. Add brake fluid

as needed.

4. Apply the brake forcefully for a few

seconds and check for fluid leakage around

the fittings.

Brake Fluid

Reservoir

80

MAINTENANCE

Steering Wheel Inspection

Check the steering wheel for specified freeplay and smooth operation

at the intervals outlined in the Periodic Maintenance Chart beginning

on page 57.
1. Position the vehicle on level ground.
2. Lightly turn the steering wheel left and right.
3. If there is excessive freeplay or strange noises, or the steering

feels rough or "catchy," have the steering system inspected by an

authorized POLARIS dealer or other qualified service facility

before operating the vehicle.

Shock Spring Adjustment

The front and rear shock absorber springs are adjustable to increase or

decrease spring tension. There are five (5) adjustable positions on each

shock.
Use a round nut wrench to rotate the

adjuster. The tension of the shock spring

will increase when rotated left and

decrease when rotated right.

WARNING! Uneven adjustment may cause

poor handling of the vehicle, which could

result in an accident. Always adjust both the

left and right spring preloads equally or have

your POLARIS dealer perform the

adjustments.

Adjuster
