Snowmobile Polaris 2006 - 2007 FS / FST. Manual - part 9

2.7

General Information

Rev. 1 07/2006

Conversion Table

°C to °F: 9 (°C + 40)+ 5 - 40 = °F
°F to °C: 5 (°F + 40) + 9 - 40 = °C

Unit of Measure

Multiplied by

Converts to

ft. lbs.

x12

= in. lbs.

in. lbs.

x .0833

= ft. lbs.

ft. lbs.

x 1.356

= Nm

in. lbs.

x.0115

= kg-m

x .7376

= ft. lbs.

kg-m

x 7.233

= ft. lbs.

kg-m

x 86.796

= in. lbs.

kg-m

x 9.807

= Nm

in.

x25.4

=mm

x .03937

= in.

in.

x2.54

= cm

mile (mi.)

x1.6

= km

x.6214

= mile (mi.)

Ounces (oz)

x 28.35

= Grams (g)

Fluid Ounces (fl. oz.)

x 29.57

= Cubic Centimeters (cc)

Cubic Centimeters (cc)

x .03381

= Fluid Ounces (fl. oz.)

Grams (g)

x 0.035

= Ounces (oz)

lb.

x.454

= kg

x 2.2046

= lb.

Cubic inches (cu in)

x 16.387

= Cubic centimeters (cc)

Cubic centimeters (cc)

x 0.061

= Cubic inches (cu in)

Imperial pints (Imp pt)

x 0.568

= Liters (l)

Liters (l)

x1.76

= Imperial pints (Imp pt)

Imperial quarts (Imp qt)

x 1.137

= Liters (l)

Liters (l)

x0.88

= Imperial quarts (Imp qt)

Imperial quarts (Imp qt)

x 1.201

= US quarts (US qt)

US quarts (US qt)

x 0.833

= Imperial quarts (Imp qt)

US quarts (US qt)

x 0.946

= Liters (l)

Liters (l)

x 1.057

= US quarts (US qt)

US gallons (US gal)

x 3.785

=Liters (l)

Liters (l)

x 0.264

= US gallons (US gal)

Pounds - force per square inch (psi)

x 6.895

= Kilopascals (kPa)

Kilopascals (kPa)

x 0.145

= Pounds - force per square inch (psi)

Kilopascals (kPa)

x0.01

= Kilograms - force per square cm

Kilograms - force per square cm

x98.1

= Kilopascals (kPa)

ð(3.14)xR

xH (height)

= Cylinder Volume

2.8

General Information

Rev. 1 07/2006

FASTENER INFORMATION

Standard Bolt Specifications

The following torque specifications are to be used as a general
guideline when torque value is not specified. There are
exceptions in the steering, suspension, and engine areas. Always

consult the torque chart and the specific manual section for
torque values of fasteners.

Grade 2

Grade 5

Grade 8

Standard Bolt Specifications

Bolt

Size

Threads/

Grade 2

ft-lb(Nm)

Grade 5

ft-lb(Nm)

Grade 8

ft-lb(Nm)

1/4

5 (7)

8 (11)

12 (16)

1/4

6 (8)

10 (14)

14 (19)

5/16

11 (15)

17 (23)

25 (35)

5/16

12 (16)

19 (26)

29 (40)

3/8

20 (27)

30 (40)

45 (62)

3/8

23 (32)

35 (48)

50 (69)

7/16

30 (40)

50 (69)

70 (97)

7/16

35 (48)

55 (76)

80 (110)

1/2

50 (69)

75 (104)

110 (152)

1/2

55 (76)

90 (124)

120 (166)

ft-lb X 1.356 = Nm

Nm X.7376 = ft-lb

2.9

General Information

Rev. 1 07/2006

GASOLINE INFORMATION

GASOLINE VOLATILITY

One of the misunderstood properties of gasoline is its volatility,
or ability to vaporize at different ambient temperatures and
altitudes during the year.

When gasoline is blended, it is given a Reid Vapor Pressure
(RVP) number which reflects its ability to vaporize or mix with
air at a given temperature range. Gasoline vapor pressure is
measured by putting a sample of fuel inside a closed container
and applying a specified amount of heat to the container for a
certain amount of time. RVP will vary from about 7.0 PSI during
the summer to approximately 13.5 PSI during the colder
months. Service stations selling a large volume of fuel will
normally have the correct blend to work well at all times
throughout the year in their local area.

When the weather is very cold, gasoline must be able to vaporize
very quickly in order for an engine to start and warm up
properly. If summer blend fuel is being used in the winter, little
or no vaporization will occur. Droplets will form causing
flooding and very hard starting.

If winter blend fuel is being used during the summer months, it
may cause vapor lock (boiling fuel) inside the fuel lines, fuel
pump, or carburetor. This will cause warm engine drive ability
problems and hard starting when warm. Some states are limiting
the Reid Vapor number to 9.0 PSI year around to help meet

evaporative emissions standards.

Gasoline Volatility

AXIMUM

EID

APOR

MBIENT

EMP

ANGE

CLASS

PRESSURE

LOW

HIGH

7.0 psi (0.5 bar)

60_F
(16_C)

110F+
(43_C+)

9.0 psi (0.6 bar)

50_F
(10_C)

110F
(43_C)

10.5psi (0.7 bar)

40_F
(4_C)

97F (36_C)

12.0psi (0.8 bar)

30_F
(-1_C)

85F (29_C)

13.5psi (0.9 bar)

20_F
(-7_C)

69F (21_C)

Add 2.45_F for each 1000 ft (305m) above sea level

2.10

General Information

Rev. 1 07/2006
