89

MAINTENANCE

Lights

When servicing a halogen lamp, avoid touching the lamp with bare fin-
gers. Oil from your skin leaves a residue, causing a hot spot that will
shorten the life of the lamp. If fingers do touch a lamp, clean it with
denatured alcohol.

Headlight Lamp Replacement

1. Peel back the foam shield covering the headlight assembly.

2. Remove the wire harness connector from the back of the headlight.

3. Grasp the bulb housing and turn it counter-clockwise to remove the

bulb.

4. Apply dielectric grease to the socket and install the new bulb.

Rotate the bulb 1/4 turn clockwise to secure it.

5. Reinstall the connector to the back of the headlight.

6. Secure the foam shield.

Taillight/Brake Light Replacement

The taillight assembly is not serviceable. If the light fails to operate
properly, replace the entire taillight assembly.

90

MAINTENANCE

Clutch System

Periodically inspect clutch sheaves for damage, wear or belt residue. To
maintain optimum performance, clean with non-oil based cleaners such
as isopropyl alcohol.

WARNING! If you become aware of higher than normal clutch engagement or
an unusual vibration or shift pattern, see your dealer immediately. Do not
operate the snowmobile until repairs have been made.

All clutch maintenance and repairs must be performed by an authorized
POLARIS dealer. Any unauthorized modifications to clutches, such as
adding or removing weights, will void the warranty.

NOTICE: The bushings in the weights and rollers of POLARIS clutches are

made of a material that may be damaged if lubricated. Do not lubri-
cate clutch bushings.

Clutch Alignment Offset

Clutch alignment offset is important for maintaining optimum perfor-
mance. See your dealer for service and adjustments. A special tool is
required to check for proper alignment.

91

MAINTENANCE

Clutch System

Drive Belt Condition

Periodically check the condition and tension of the drive belt. Inspect
the belt for signs of excessive wear: frayed edges, missing cogs, cracks
and excessive looseness. Replace the belt if any of these conditions
exist. See Drive Belt Troubleshooting on page 109.

Always carry a spare drive
belt. Store the spare belt in
the belt clip located under
the left side of the hood.

For improved drive-away during extremely cold temperatures, remove
the belt and warm it to room temperature. Reinstall it before starting the
snowmobile.

92

MAINTENANCE

Clutch System

Drive Belt Deflection

Measure belt deflection with both
clutches at rest and in their full
neutral position.

Place a straight edge (1) on the
belt and apply downward pressure
while measuring at point 2. This
measurement should be 1 1/4
inches (3.2 cm).

Drive Belt Adjustment

1. Loosen the 7/16-inch jam nut on the belt width adjuster.

2. Using a 1/8-inch Allen wrench, turn the set screw inward (clock-

wise) to increase the distance between the sheaves or outward
(counter-clockwise) to decrease the distance.

3. Tighten the jam nut.

1

2
