Snowmobile Polaris 700 XC, 800 XC (2003 year). Manual - part 17
E9
TOOL KIT
700 XC SP EDGE S03NP7CSA and 700 XC SP EDGE S03NP7CSB and 700 XC EDGE S03NP7CS and 700 XC SP EDGE X F/0 S03NA7CS and 700 XC SP EDGE M-10 F/O
S03NE7CS and 700 XC SP EDGE X M-10 F/O S03NF7CS and 800 XC EDGE F/O S03NP8CS and 800 XC SP EDGE S03NP8CSA and 800 XC SP EDGE S03NP8CSB and
800 XC SP EDGE X F/0 S03NA8CS and 800 XC SP EDGE M-10 F/O S03NE8CS and 800 XC SP EDGE X M-10 F/O S03NF8CS
1
2
3
9
7
6
4
5
8
Part numbers may have changed since this microfiche was issued. To ensure that correct parts are received, refer to PartSmart, which is updated monthly.
Ref. Part No.
Qty. Description
Ref. Part No.
Qty. Description
2873520
1 Kit, Tool (Incl. 1-4)
1 --------------
1 Screwdriver
2 --------------
1 Wrench, 9/16” x 1/2” Open End
3 --------------
1 Box Wrench, Special
4 --------------
1 Wrench, Box End, 9/16” x 5/8”
5 9916913
1 Video, Suspension Setup (Edge)
6 2872012
1 Tool, Scissor Stop Wrench (Edge)
7 9917436
9917476
9917462
9917477
9917482
9917588
9917594
9917580
9917591
1
1
1
1
1
1
1
1
1
Manual, Owner’s, ’03 Snowmobile
Supplement, Owner’s Manual, ’03 700
XC SP M-10 F/O
Supplement, Owner’s Manual, ’03 700
XC F/O
Supplement, Owner’s Manual, ’03 700
XC SP X F/O
Supplement, Owner’s Manual, ’03 700
XC SP X M-10 F/O
Supplement, Owner’s Manual, ’03 800
XC SP M-10 F/O
Supplement, Owner’s Manual, ’03 800
XC F/O
Supplement, Owner’s Manual, ’03 800
XC SP X F/O
Supplement, Owner’s Manual, ’03 800
XC SP X M-10 F/O
8 5246657
2 Wrench, Adjuster, M-10
9 7080287
1 Strap, Emergency Starter
(Manual Start)
3/02
