Snowmobile Polaris 600 IQ Racer (2015 year). Manual - part 5

23

SAFETY

Safety Labels and Locations

Competition ONLY Warning

This warning label is located under the hood on the upper left console.

WARNING

This snowmobile is a competition model only and is not manufactured for, nor
should it be used on public land or trails. The use of this snowmobile should be
limited to participation in sanctioned competition events upon a closed course.
This snowmobile should NOT be used for general off-trail recreational riding.
This snowmobile is intended for experienced racers only, and NOT for
beginners.

7178397

Operation

Warning

“No Passenger”

Warning

Track

Warning

Competition ONLY

Warning

(under hood)

24

FEATURES

9

2

5

6

7

11

10

3

1

8

14

13

12

1.

Headlight Dimmer Switch

2.

Ignition Switch/Tether Switch

3.

Master Cylinder

4.

Handlebar Pad

5.

Engine Stop Switch

6.

Throttle Control

7.

Recoil Starter Handle

8.

Hold Down Straps

9.

Fuel Filler Cap

10. Choke Control
11. Hand/Thumbwarmer Switch
12. Brake Lever
13. Parking Brake Lock
14. DRAGON Ignition System

Switch

15. Tachometer
16. Temperature Light

15

16

4

25

FEATURES

POLARIS DRAGON Ignition System

Your snowmobile is equipped with an ignition system feature that
improves competition performance by increasing exhaust system
temperature. The DRAGON Ignition System provides maximum
“holeshot” performance for racing applications.

WARNING! DRAGON mode increases the exhaust system temperature and
causes engine misfire and backfire. Flammable materials and vapors may ignite
and result in fire and explosion, which may cause serious injury, death or
property damage. Read the Owner's Manual. Always follow all instructions and
warnings.

DRAGON Mode Facts

• The DRAGON Ignition System is intended for competition use on

closed courses by experienced riders only.

• There is no benefit to using DRAGON mode for normal trail riding.
• Unnecessary, extended or excessive use of DRAGON mode can

result in severe engine damage, which is excluded from POLARIS
warranty coverage.

• DRAGON mode usually heats up the exhaust system within 5 to 20

seconds, depending upon the initial temperature of the exhaust
system.

• Two different sounds may be heard when using DRAGON mode. One

sound is an erratic misfire that may be heard when the exhaust system
is heating up. The other sound is a consistent misfire (with a slight
rise in engine RPM) when the exhaust system is at target operating
temperature.

• DRAGON mode maintains the engine speed between 4500 and 5100

RPM.

• Be sure that the clutch engages at 5300 RPM or above to prevent

forward creep of the vehicle. See your dealer if the clutch needs
adjustment.

• Please refer to the POLARIS jetting chart and use the recommended

jet for current temperatures as this system is sensitive to jet changes.

26

FEATURES

POLARIS DRAGON Ignition System

1. Warm up the engine and

track.

2. When staged at the starting

line, depress and hold the
DRAGON button on the left
handlebar (1).

3. Slowly advance the throttle

to the wide-open position
while keeping the button
depressed.

4. Release the button when the

start flag drops.

TIP: The vehicle will launch forward

at wide-open throttle.

1
