1.42
SPECIFICATIONS
600 HO RMK
MODEL#S06PK6FS(A,B)
Table 1-264: Engine
Engine type
600 Liberty
Engine displacement
599cc
Bore in/mm
3.04/77.25
Stroke in/mm
2.52/64
Piston to cylinder clearance
in/mm
.0045-.0059/.114-.150
Piston ring end gap
.014-.020/.36-.51
Operating RPM±200
8100
Idle RPM
1500
Clutch engagement
RPM±200
3800
Exhaust valve spring
Pink
Head volume installed
27.5-28.3cc
Head volume bench
35.2 ±.5cc
Table 1-265: Fuel Delivery
Type
TM38
Main Jet
280
Pilot Jet
50
Jet Needle/Clip position
9DGN6-57/1
Needle Jet
P-8
Throttle gap under cutaway
in/mm
.13/3.4
Throttle slide cutaway
2.5
Valve seat
1.5
Starter jet
145
Pilot air jet
.6
Fuel screw setting
1
Air screw setting
N/A
Recommended fuel octane
(R+M/2)
91
Table 1-266: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -25
_
F/<-3
5
_
C
-3
0
_
F to
-10
_
F/-3
4
_
C to
-23
_
C
-1
5
_
F t
o
+5
_
F/-2
6
_
C to
-15
_
C
0
_
F t
o
+
2
0
_
F/-18
_
C to
-7
_
C
+1
5
_
F to
+
3
5
_
F/
-9
_
C t
o
+2
_
C
+30
_
F t
o
+5
0
_
F/
-1
_
C to
+1
0
_
C
+45
_
F to
+6
5
_
F/
+7
_
C to
+1
8
_
C
>+60
_
F/>+1
6
_
C
0-600
(0-2000)
440
#3
430
#3
420
#2
400
#2
390
#2
380
#2
370
#2
360
#1
600-1200 (2000-
4000)
410
#3
400
#3
390
#2
370
#2
360
#2
350
#2
340
#1
330
#1
1200-1800
(4000-6000)
370
#3
360
#2
350
#2
340
#2
330
#2
320
#1
310
#1
300
#1
1800-2400
(6000-8000)
340
#3
320
#2
310
#2
300
#2
280
#1
280
#1
270
#1
260
#1
2400-3000
(8000-10000)
310
#2
300
#2
290
#2
280
#1
270
#1
260
#1
250
#1
240
#1
3000-3700
(10000-12000)
290
#2
280
#2
270
#1
250
#1
240
**
230
**
220
**
210
**
** Denotes clip in position #1 with the washer on top.
When using non oxygenated fuel with an octane number
greater than 93, decrease the main jet number in the above
chart by 10 and insert the E-clip position to **. If already
in position ** no adjustment is needed.
Table 1-267: Clutching
Altitude meters
(feet)
Drive Clutch (P-85)
Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-62
Black/
Green
Red/
Black
56/42-36
20:41-76
600-1200
(2000-4000)
10-60
Black/
Green
Red/
Black
56/42-36
20:41-76
1200-1800
(4000-6000)
10-58
Black/
Green
Red/
Black
56/42-36
20:41-76
1800-2400
(6000-8000)
10-56
Black/
Green
Red/
Black
56/42-36
20:41-76
2400-3000
(8000-10000)
10-54
Black/
Green
Red/
Black
56/42-36
20:41-76
3000-3700
(10000-12000)
10AL
Black/
Green
Red/
Black
56/42-36
20:41-76
Drive clutch bolt torque 50 ft-lbs
Table 1-268: Belt
Belt part number
3211080
Belt width in/cm
1.438/3.65
Belt side angle
28_
Outside diameter in/cm
46.625/118.4
Clutch center distance in/cm
11.5/29.2
