lighting:

see-me-home .......................................

(current page)

lights:

dipped beam headlights .......................

(current page)

lights:

side lights .............................................

(current page)

1.97

ENG_UD65105_2

Éclairages et signalisations extérieures (HJB - Renault)



“See-me-home lighting”

function

This function enables you to briefly

switch on the side lights and dipped

beam headlights (e.g. to provide light

when opening a gate).

With the engine and lights switched

off,

 the

2

 ring in

AUTO

 position (or, de-

pending on the vehicle, in

0

 position)

pull the stalk

1

 towards you: the side

lights and dipped beam headlights will

switch on for approximately 30 seconds
along with the

š

 and

k

 warn-

ing lights on the instrument panel.
To increase this duration, you may pull

the stalk up to four times (total time re-

stricted to approximately two minutes).

On the instrument panel, the message

“lighting on _ _ _” followed by the re-

maining time will appear as confirma-

tion. You can then lock your vehicle.
To switch off the lights before they

switch off automatically, turn the

2

 ring

to any position then return it to

AUTO



position (or, depending on the vehicle,

to

0

 position).

EXTERIOR LIGHTING AND SIGNALS

(5/6)

2

1

lights:

fog lights ..............................................

(current page)

1.98

ENG_UD65105_2

Éclairages et signalisations extérieures (HJB - Renault)



EXTERIOR LIGHTING AND SIGNALS

(6/6)

When driving in fog or snow, or

when transporting objects which are

higher than the roof, the headlights

do not come on automatically.
Switching on the fog lights remains

the responsibility of the driver: the

indicator lights on the instrument

panel inform you whether the fog

lights are lit (indicator light on) or not

(indicator light not on).

Switching off the lights

Turn the centre ring

4

again until the

3



symbol is opposite the symbol for the

fog lights. The corresponding indicator

light on the instrument panel goes out.
The rear fog lights switch off when the

exterior lights are switched off.

2

1

3

4

Rear fog lights

Turn centre ring

4

 on the stalk

until the symbol faces mark

3

, then re-

lease it.
Operation of the fog lights depends on

the exterior lighting selected, and an in-

dicator light will light up on the instru-

ment panel.
Do not forget to switch off the fog lights

when they are no longer needed, to

avoid inconveniencing other road



users.

horn:

flash .....................................................

(up to the end of the DU)

audible and visual signals..........................

(up to the end of the DU)

indicators ...................................................

(up to the end of the DU)

lighting:

exterior .................................................

(up to the end of the DU)

lights:

hazard warning ....................................

(up to the end of the DU)

lights:

direction indicators ...............................

(up to the end of the DU)

indicators:

direction indicators ...............................

(up to the end of the DU)

horn ...........................................................

(up to the end of the DU)

hazard warning lights signal ......................

(up to the end of the DU)

signals and lights .......................................

(up to the end of the DU)

hazard warning lights signal ......................

(up to the end of the DU)

1.99

ENG_UD77149_3

Avertisseurs sonores et lumineux (HJB - Renault)



Audible and visual signals

é

Hazard warning lights

Pressing switch

2

 illuminates

all four direction indicators and the

side-mounted indicator lights simulta-

neously.
It must only be used in an emergency to

warn drivers of other vehicles that you

have had to stop in an area where stop-

ping is prohibited or unexpected, or that

you are obliged to drive under special

conditions.

Direction indicators

Move the stalk

1

 in the same direc-

tion as you want to move the steering

wheel.

One-touch mode

Briefly shift the stalk

1

 upwards or

downwards, not exceeding the point

of resistance, then release it: the stalk

will return to its original position and the

direction indicator light concerned will

flash three times.

Horn

Press the steering wheel boss

A

 to ac-

tivate the horn.

Headlight flasher

Pull stalk

1

 towards you then release it

to flash the headlights.

AUDIBLE AND VISUAL SIGNALS

A

2

1

2

lighting:

exterior .................................................

(up to the end of the DU)

lights:

adjusting ..............................................

(up to the end of the DU)

lights

adjustment ...........................................

(up to the end of the DU)

headlight beam adjustment .......................

(up to the end of the DU)

signals and lights .......................................

(up to the end of the DU)

electric beam height adjustment ................

(up to the end of the DU)

lights:

adjustment of headlight beam height ...

(up to the end of the DU)

1.100

ENG_UD60718_2

Réglage des faisceaux (HJB - Renault)



Switch

A

 is used to adjust the height of

the headlight beams according to the

load.
With the dipped beam headlights lit,

press or lift switch

A

 as many times as

is necessary to select the required posi-

tion on the instrument panel.

Note:

 depending on the vehicle, when

the engine is started, the position se-

lected is displayed on the instrument

panel for approximately 30 seconds

and for 5 seconds each time switch

A



is pressed.

Headlight beam adjustment

HEADLIGHT BEAM ADJUSTMENT

Examples of positions for

adjusting

control



A



according to the load

Driver alone or with front passenger

0

All seats occupied

1

Driver with passengers and luggage

(or load) reaching the maximum

permissible all-up weight

3

Driver without passengers and luggage

(or load) reaching the maximum

permissible all-up weight

4

* depending on the vehicle

The table below gives some examples. In all cases, adjust control

A

 accord-

ing to the vehicle load so that the road can be seen and other drivers are not

dazzled.

A

wipers ........................................................

(up to the end of the DU)

windscreen washer ....................................

(up to the end of the DU)

precautions during use ..............................

(up to the end of the DU)

1.101

ENG_UD79846_2

Essuie-vitre / lave-vitre avant (HJB - Renault)



Washers, wipers

Special note
When driving the vehicle

, the wiping

speed slows down whenever the vehi-

cle stops.
For example, fast wiping speed will

slow to normal wiping speed.
As soon as the vehicle moves off,

wiping will return to the speed originally

selected.
If stalk

1

 is operated, it overrides and

cancels the automatic function.

Vehicle fitted with intermittent

windscreen wipers



A  single sweep

A short push will trigger one sweep

of the wipers.



B stop



C  intermittent wiping

The wipers will pause for several

seconds between sweeps. It is

possible to change the time be-

tween sweeps by turning ring

2

.



D  slow continuous wiping



E  fast continuous wiping

1

A

B
C
D

E

1

2

WINDSCREEN WASH, WIPE

(1/5)

wiper blades ..............................................

(current page)

1.102

ENG_UD79846_2

Essuie-vitre / lave-vitre avant (HJB - Renault)



Vehicle fitted with front

windscreen wiper rain sensor

The rain sensor is located on the winds-

creen, in front of the interior rear-view

mirror.



A  single sweep

A short push will trigger one sweep

of the wipers.



B stop

When activating automatic wiping or

when increasing sensitivity, one sweep

of the blades is performed.

Note:

–   the rain sensor is only intended as a

driving aid. In the event of reduced

visibility, the driver should manually

activate the wipers. In foggy weather

or during snowfalls, wiping is not au-

tomatically triggered and remains

under the driver’s control;

–   in the event of temperatures below

zero, automatic wiping is not acti-

vated when the vehicle is started. It

is automatically activated as soon as

the vehicle exceeds a certain speed

(approximately 5 mph (8 km/h));

–   do not activate automatic wiping in

dry weather;

–  fully de-ice the windscreen before

activating automatic wiping;

–  when washing the vehicle under a

roller type car wash, return the ring

1



to the

B

 position to deactivate auto-

matic wiping.

2

F

1



C   automatic wiper function

When this position is selected, the

system detects water on the wind-

screen and triggers the wipers at a

suitable wiping speed. It is possi-

ble to change the triggering thresh-

old and the time sweeps by turning

ring

2

:

–

F

: minimum sensitivity;

–

G

: maximum sensitivity.

The higher the sensitivity, the quicker

the wipers will react and the faster the

wipe.

1

A

B

C

D

E

G

WINDSCREEN WASH, WIPE

(2/5)

operating faults ..........................................

(current page)

1.103

ENG_UD79846_2

Essuie-vitre / lave-vitre avant (HJB - Renault)





D  slow continuous wiping



E  fast continuous wiping

Operating faults

In the event of a malfunction of the au-

tomatic wiping, the wiper is set to inter-

mittent wiping.
Call an approved Dealer.
The operation of the rain sensor may

be interrupted in the event of:
–   damaged windscreen wipers; a film

of water or traces left by a blade in

the sensor’s detection zone may in-

crease the response time of the au-

tomatic wiper, or increase the wiping

frequency;

–   a windscreen with any chip or crack

level with the sensor, or a windscreen

covered in dust, dirt, insects, ice, the

use of washing wax and water-repel-

lent chemicals; the windscreen wiper

will be less sensitive or may even not

react at all.

Special note
When driving the vehicle

, the wiping

speed slows down whenever the vehi-

cle stops.
For example, fast wiping speed will

slow to normal wiping speed.
As soon as the vehicle moves off,

wiping will return to the speed originally

selected.
If stalk

1

 is operated, it overrides and

cancels the automatic function.

Precautions

–   In the event of ice, check whether the

blades are stuck to the windscreen

before operating the wiping mecha-

nism. If you activate the wipers while

the blades are stuck down with ice,

you may risk damaging both the

blade and the wiper motor.

–   Do not activate the wipers on a dry

screen. This will lead to premature

wear or damage to the blades.

1

A

B

C
D

E

WINDSCREEN WASH, WIPE

(3/5)

screen wash/wipe

replacing blades ...................................

(current page)

1.104

ENG_UD79846_2

Essuie-vitre / lave-vitre avant (HJB - Renault)



Before any action involving

the windscreen (washing

the vehicle, de-icing,



cleaning the windscreen,

etc.) return stalk

1

 to position

B



(stop).

Risk of injury and/or damage.

In the event of obstacles on the

windscreen (dirt, snow, ice etc.),

clean the windscreen (including the

central area located behind the inte-

rior rear view mirror) before starting

the wipers (risk of motor overheat-

ing).
If an object is preventing a blade

from moving, it may stop function-

ing.
Remove the obstacle and reactivate

the wiper using the wiper stalk.

Specific front wiper position

(service position)

This position enables the blades to be

lifted to remove them from the winds-

creen.
It may be useful to:
–  to clean the blades;
–  to release the blades from the wind-

screen in winter;

–  replace the blades

 5.34.

With the ignition on or engine started,

lift the stalk twice

1

 to position

A

 (single

sweep).
The blades stop slightly away from the

bonnet.
To return the blades to low position,

with the ignition on, ensure that the

wipers have folded down onto the wind-

screen, then move the stalk

1

 to posi-

tion

A

 (single sweep).

Before switching on the ignition,



place the wipers on the windscreen.

Otherwise, there may a risk of damage

to the bonnet or the wipers when they

are switched on.

G

1

A

B

C
D

E

WINDSCREEN WASH, WIPE

(4/5)

wiper blades ..............................................

(current page)

screen wash/wipe ......................................

(current page)

windscreen washer ....................................

(current page)

1.105

ENG_UD79846_2

Essuie-vitre / lave-vitre avant (HJB - Renault)



Note:

 in temperatures below zero, the

washer liquid may freeze on the wind-

screen, reducing visibility. Heat the

windscreen using the demister control

before cleaning.

Windscreen washer

With the ignition on

, pull stalk

1

 then

release.
A longer pull will trigger, in addition to

the windscreen washer, two sweeps

of the wipers followed, a few seconds

later, by a third.
On vehicles fitted with a multimedia

screen, you can choose to activate or

disable the third sweep of the blades

 1.83.

When working in the engine

compartment, ensure that

the windscreen wiper stalk

is in position

B

 (stop).

Risk of injury.

G

1

A

B

C

D

E

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:

– it must remain clean: clean the

blade and the screen regularly

with soapy water;

–  do not use it when the screen is

dry;

–  free it from the screen when it has

not been used for a long time.

In all cases, replace it as soon as

it begins to lose efficiency: approxi-

mately once a year.

 5.34.

Precaution for using the

wipers

– In freezing or snowy weather

conditions, clear the screen



before starting the wipers (risk of

motor overheating);

– ensure that no objects are ob-

structing the travel of the blade.

WINDSCREEN WASH, WIPE

(5/5)

wipers ........................................................

(up to the end of the DU)

windscreen washer ....................................

(up to the end of the DU)

1.106

ENG_UD56600_1

Essuie-vitre / Lave-vitre arrière (HJB - Renault)



REAR SCREEN WASHER, WIPER

(1/2)

1

3

Y

Rear screen wiper

With the ignition on, turn ring

3



on stalk

1

 to align the symbol with

mark

2

.



stop;

–  intermittent wiping.

The wipers will pause for several

seconds between sweeps. Wiping

frequency varies with vehicle



speed;



slow continuous wiping.

To stop the operation, pivot ring

3

 again.

Note:

When washing using a roller type car

wash, return the ring

3

 on the stalk

1



to the stop position to deactivate auto-

matic wiping.
Follow usage recommendations.

Before any action involving

the rear screen (washing

the vehicle, de-icing, clean-

ing, etc.) return stalk

1

 to

the stop position.

Risk of injury and/or damage.

2

Do not use the wiper arm to open or

close the tailgate.

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:

– it must remain clean: clean the

blade and the screen regularly

with soapy water;

–  do not use it when the screen is

dry;

–  free it from the screen when it has

not been used for a long time.

In all cases, replace it as soon as

it begins to lose efficiency: approxi-

mately once a year.

 5.34.

Precaution for using the

wipers

– In freezing or snowy weather

conditions, clear the screen



before starting the wipers (risk of

motor overheating);

– ensure that no objects are ob-

structing the travel of the blade.

wipers ........................................................

(up to the end of the DU)

windscreen washer ....................................

(up to the end of the DU)

1.107

ENG_UD56600_1

Essuie-vitre / Lave-vitre arrière (HJB - Renault)



REAR SCREEN WASHER, WIPER

(2/2)

Activation/deactivation of the rear

screen wiper

Engaging reverse gear triggers inter-

mittent wiping (if the front wipers are in

operation). If your vehicle is equipped

with a vehicle settings customisation

menu, you can opt to activate or deacti-

vate this function.

 1.83.

For vehicles not fitted with a settings

customisation menu, you can have this

function deactivated by an authorised

dealer.

p

Rear screen wash/wipe

With the ignition on, push and

hold stalk

1

, then release.

Holding the stalk for longer will trigger

(in addition to the windscreen washer)

two sweeps of the wipers followed,

a few seconds later, by a third (drip

wiping function).
When the stalk is released, it returns to

the rear wipe position.

In the event of obstacles present on the

rear window (dirt, snow, etc.), the wiper

will try to sweep away all the obstacles.

If an obstacle prevents the blade from

moving, it can be stopped. Remove the

obstacle, wait for around 30 seconds

and reactivate the wiper using the wiper

stalk.

Precautions

–  In the event of ice, check that the

blades are not stuck to the wind-

screen before operating the wipers.

If you activate the wiper while the

blade is blocked by ice, you risk dam-

aging both the blade and the wiping

motor.

–   Do not operate the wipers on a dry

screen. This will lead to the prema-

ture wear or damage to the blades.

1

fuel filler cap ..............................................

(up to the end of the DU)

fuel tank capacity .......................................

(up to the end of the DU)

fuel

quality ..................................................

(up to the end of the DU)

fuel

filling .....................................................

(up to the end of the DU)

fuel level ....................................................

(current page)

fuel tank

capacity ................................................

(current page)

1.108

ENG_UD82816_6

Réservoir carburant (HJB - Renault)



Fuel grade

Use a high-grade fuel

 that complies

with the legislation in force in each

country and which

must

 comply with

the specifications given on the label on

the cover

1

 6.6.

Fuel tank (filling with fuel)

FUEL TANK

(1/5)

Filler cap: this is specific.

If you have to replace it,

make sure it is identical to

the original cap. Contact an

approved Dealer.

Never place the cap near a source

of heat or flame.
Do not wash the filler area with a

high-pressure washer.

Useable tank capacity:

– About

11 gallons (50 litres)

 for

petrol versions;

–

46 litres (10.12 gallons)

 approxi-

mately for the Diesel versions.

With the vehicle unlocked, to open

cover

1

, press area

A

 then release. The

cover

1

 opens slightly.

Use the cap holder

2

 on the flap

1



during filling to hold the cap

3

 in place.

For details on filling the fuel tank, refer

to the information on “Filling with fuel”.

To close it, press on the fuel filler flap by

hand, as far as it will go.

1

A

3

2

1

Do not mix even small

amounts of petrol (un-

leaded or E85) with diesel.

Do not use ethanol-based

fuel if your vehicle is not compatible

with this fuel.
Do

not

 add reagent to the fuel – oth-

erwise you risk damaging the engine

 0.8. If you wish to add an additive

to the fuel, use a product approved

by our Technical Department.

Consult an approved dealer.

Fuel types that conform to European

standards with which the engines of

vehicles sold in Europe are compat-

ible: refer to the table

 6.6.

1.109

ENG_UD82816_6

Réservoir carburant (HJB - Renault)



If it is not possible to add at least

1.10 gallons (5 litres) of fuel due to the

fuel level in the tank, drive the vehicle

until the tank has capacity.

Petrol versions

Using leaded petrol will damage the

antipollution system and may lead to a

loss of warranty.
To ensure that the fuel tank is not filled

with leaded petrol, the fuel tank filler

neck contains a restrictor fitted with a

foolproof system which

only allows

the nozzle for unleaded petrol to be

used

(at the pump).

Filling with fuel

With the ignition off, insert the nozzle

and insert it

fully

 before turning it on to

fill the fuel tank (risk of splashing).
Keep the nozzle in this position through-

out the entire filling operation.

When the pump cuts out automatically

at the end of the filling procedure, a

maximum of two further filling attempts

may be made, as there must be suffi-

cient space in the fuel tank to allow for

expansion.

Make sure that no water enters the fuel

tank during filling. The cover

1

 and its

surround must remain clean.

Special case

When the vehicle has been stopped for

around three months,

 you must add

fuel to prevent damage to the fuel

pump

.

To do this, with the ignition off, top-up

at least 1.10 gallons (

5 litres

) then start

the engine to operate the pump and

renew the fuel in the circuit.

FUEL TANK

(2/5)

1

Diesel version

It is

essential

 to use diesel fuel that

conforms with the information given on

the label inside cover

1

.

Petrol version

It is

essential

 to use unleaded petrol.

The octane rating (RON) must comply

with the information given on the label

on the cover

1



 6.6.

After filling, check that the cap and

cover are closed.

To fill up with fuel, the

engine must be stopped

(and not only on standby

in the case of vehicles

equipped with the Stop and Start

function): you must switch off the ig-

nition

 2.4,

 2.6.

Fire hazard.

Stop & Start ...............................................

(current page)

1.110

ENG_UD82816_6

Réservoir carburant (HJB - Renault)



No modifications what-

soever are permitted on

any part of the fuel supply

system (electronic units,

wiring, fuel circuit, injectors, pro-

tective covers, etc.) as this may be

dangerous (unless undertaken by

qualified Network personnel).

Persistent fuel odour

If you notice a persistent

fuel odour you should:

–  stop the vehicle as soon as traf-

fic conditions allow and switch off

the ignition;

– switch on the hazard warning

lights and ask your passengers to

leave the vehicle and stay clear

of the traffic;

–  contact an approved Dealer.

FUEL TANK (3/5)

Vehicles with card

With the card in the passenger com-

partment, press the start button

4

 with-

out pressing any of the pedals. Wait a

few minutes before starting.
This will enable the fuel circuit to be

primed. If the engine does not start,

repeat the procedure.
If the engine does not start after several

attempts, please contact an authorised

dealer.

4

Running out of fuel on diesel

versions

Vehicles with key/remote control

–  Set the ignition key to “On” position

ON 2



 2.3 and wait a few minutes

before starting to enable the fuel cir-

cuit to be primed;

–  turn the key to position

START 3

. If

the engine does not start, repeat the

procedure;

–  If the engine does not start after sev-

eral attempts, contact an approved

dealer.

1.111

ENG_UD82816_6

Réservoir carburant (HJB - Renault)



FUEL TANK (4/5)

Useable capacity of the LPG tank: ap-

proximately 7.04 gallons (32 litres)

.

Filling up with LPG

Apply the parking brake, stop the

engine, switch off the ignition and

switch off the lights.
Always respect the safety instructions

given at filling stations.
Depending on the country, before refill-

ing you must screw the filling adapter

5



onto the LPG filler end piece.

It is always advisable to completely fill

the tank.

When the pump stops delivering LPG,

or when the pump flow reduces signif-

icantly, the maximum LPG level has

been reached.

At this point, do not attempt to carry on

filling.

Filling stations without self-

service

If the service station personnel carry

out the LPG filling procedure, you must

give them the adapter

5

.

IMPORTANT: LPG filling

adapter 5

Depending on the country, the use

of a specific adapter is required for

LPG filling.

The filling adapter

5

 is provided in

a pouch in the glove box. It may or

may not be present in the vehicle,

depending in which country the ve-

hicle was sold.

Before driving the vehicle to another

country, it is essential to consult an

approved dealer to find out the type

of adapter to use if necessary.

5

5

5

1.112

ENG_UD82816_6

Réservoir carburant (HJB - Renault)



FUEL TANK (5/5)

Filling stations with self-

service

We recommend that you wear gloves

when handling the LPG pistol.
Open the tank flap of your vehicle and

unscrew the cap

6

 from the end piece

of the LPG filler

7

.

Carefully follow the instructions shown

on LPG distributors. These explain how

to fill up properly.

Depending on the type of station, it may

be necessary to perform press and hold

the station button before filling will start.
When the pump stops supplying LPG,

or when the pump flow reduces sig-

nificantly, the maximum tank level has

been reached.
The filling will stop as soon as you re-

lease the button. Release the stop

lever (a small amount of gas may be re-

leased), lift the pistol and place it on the

distributor.
After filling, refit the cap

6

 to prevent

any water or foreign bodies from enter-

ing the system.

6

7

To fill up with fuel, the

engine must be stopped

(and not only on standby

in the case of vehicles

equipped with the Stop and Start

function): you must switch off the ig-

nition

 2.4,

 2.6.

Fire hazard.

AdBlue .......................................................

(up to the end of the DU)

reagent tank cap ........................................

(up to the end of the DU)

reagent tank capacity ................................

(up to the end of the DU)

reagent quality ...........................................

(up to the end of the DU)

filling with reagent ......................................

(up to the end of the DU)

reagent (tank) ............................................

(up to the end of the DU)

reagent tank...............................................

(up to the end of the DU)

reagent tank capacity ................................

(up to the end of the DU)

SCR: selective catalytic reduction .............

(up to the end of the DU)

Stop & Start ...............................................

(current page)

1.113

ENG_UD71747_5

Réservoir réactif (HJB - Renault)



Filling

Useable capacity of the tank: 2.86

gal (13 litres)

 approximately.

With the ignition switched off, open the

cover

A

, then unscrew the cap

1

.

Note:

 ammonium hydroxide vapour

may escape from the cap opening

when the tank temperature is high.

Reagent tank

Please ensure that you comply with the

legislation of your country. It is impor-

tant to remember that failure to respect

regulations in force could lead to legal

action being taken against the vehicle

owner.

Operating principle

The reagent is intended for diesel en-

gines fitted with the SCR (selective cat-

alytic reduction) system.

The use of reagents reduces exhaust

emissions by transforming the pollut-

ants into water vapour and nitrogen.

Reagent consumption in real time de-

pends on vehicle usage conditions, the

equipment fitted, and driving style.

Reagent quality

Use

only reagents which conform

to standard ISO 22241

 and in accord-

ance with the mark on the tank filler

cap.

REAGENT TANK

(1/4)

A

1

Fuel filler cap: this is a

specific type.

If you have to replace it,

make sure it is identical

to the original cap. Contact an ap-

proved Dealer. Do not wash the filler

area with a high pressure washer.

To fill up with reagent, the engine

must be stopped (and not on



standby in the case of vehicles

equipped with the STOP and Start

function). You must switch off the ig-

nition

 2.4

 2.6.

If the “XXX MILES (XXX

KM) failure Top up AdBlue”

warning message appears,

fill the reagent tank and

refer to the filling instructions.

Risk of immobilisation of the ve-

hicle.

The reagent must not come into contact with eyes or skin. If it does, wash

the affected area with plenty of cold water. If necessary, consult a doctor.

1.114

ENG_UD71747_5

Réservoir réactif (HJB - Renault)



Filling (continued)

The tank can be filled at the pump. With

the ignition off, insert the nozzle

fully



before activating it to fill the fuel tank

(risk of splashing). Keep the nozzle in

this position throughout the entire filling

operation.
When the pump cuts out automatically

at the end of the filling procedure, a

maximum of two further filling attempts

may be made, as there must be suffi-

cient space in the fuel tank to allow for

expansion.
In other filling cases, it is essential to

read the information shown on the rea-

gent container (e.g. the can or bottle).

Precautions for use

When filling:
–

handle the reagent with care. They

can damage clothes, shoes, body-

work components etc.;

–  make sure that no water enters the

fuel tank.

If the reagent overflows, or contami-

nates any paintwork, clean the affected

area quickly with plenty of cold water

and a soft cloth.

Note:

 if the reagent crystallises, use a

soft sponge.

In extreme cold weather conditions
In frosty weather conditions, the rea-

gent tank should be refilled when the



 indicator and the message “TOP

UP AdBlue before 1200 km” appear on

the instrument panel.

Special cases

The reagent fluid freezes below about

-10°C.
In these conditions, do not attempt filling

when the fluid is frozen. In the event of

needing to top up or fill the tank with re-
agent (

 on), park the vehicle in a

hotter location if possible so that the re-

agent becomes liquid again. Otherwise,

have a qualified professional top up or

fill up with reagent fluid.

REAGENT TANK

(2/4)

No work whatsoever is



permitted on any part of

the system. To prevent



damage, only qualified per-

sonnel from our network may work

on the system.

After filling the reagent tank, check

that the cap and cover are closed,

start the engine and

WAIT 10 sec-

onds with the vehicle stationary,

engine running

 before setting off

again.

If this operation is not carried out,

the filling of the tank will not be

taken into account automatically

until after several dozens of minutes

of driving.

The “--- Fill AdBlue” and/or the warn-

ing lights will continue to appear

until the filling has been registered

by the system.

operating faults ..........................................

(up to the end of the DU)

vehicle range .............................................

(current page)

maintenance ..............................................

(current page)

faults

operating faults ....................................

(up to the end of the DU)

indicators:

instrument panel ..................................

(up to the end of the DU)

instrument panel messages.......................

(up to the end of the DU)

1.115

ENG_UD71747_5

Réservoir réactif (HJB - Renault)



REAGENT TANK

(3/4)

Maintenance/Range

The information displayed on the instrument panel may be accompanied by a beep.

Indicator

lights

Message

What to do?

“Top Up AdBlue before 2400 km”

When the message is displayed when the ignition is switched

on, you have

less than 1,488 miles (2,400 km) range.

Plan to refill, or have an Approved Dealer

refill the reagent

 in

the tank.

 comes on.

“TOP UP AdBlue before 1200 km”

When the message is displayed when the ignition is switched

on, you have

between 744 miles (1,200 km) and 496 miles

(800 km) range.

Plan to refill, or have an Approved Dealer

refill the reagent

 in

the tank.

 comes on.

“XXX KM failure Top up AdBlue”

The message is displayed when the ignition is switched on and

is repeated:

–  Approximately every 62 miles (100 km), you have

between

about 496 miles (800 km) and 124 miles (200 km) range

;

–  approximately every 31 miles (50 km), you have

a range of

less than 124 miles (200 km)

.

In any event, fill or have an Approved Dealer

fill the reagent

tank as soon as possible.

 flashes.

“0 KM failure Top up AdBlue”

The engine will not start.

To restart, you must fill the reagent tank yourself.

1.116

ENG_UD71747_5

Réservoir réactif (HJB - Renault)



REAGENT TANK

(4/4)

System faults

When the indicator lights light up, this may be accompanied by a beep.

Indicator lights

Message

Readings

 and

©

 come on.

“Check Anti- Pollution System”
“AdBlue quality to check”
“AdBlue injection to check”

Indicates a fault in the system. Contact your approved

Dealer as soon as possible.

 and

©

 come on.

“XXX KM failure antipollution”

Indicates a system fault and that in

less than 496

miles (800 km) it will become impossible to re-

start the vehicle

.

These warnings are repeated:

– every 62 miles (100 km) until there is

around

500 miles (800 km) and 124 miles (200 km) left



before the vehicle cannot be restarted;

–  Every 31 miles (50 km) when there is

less than

124 miles (200 km) left

 before the vehicle cannot

be restarted.

Contact your approved Dealer as soon as possible.

 and

©

 come on.

“0 KM failure antipollution”

Indicates that after the ignition is switched off

the ve-

hicle will not restart

. Call an approved Dealer.

2.1

ENG_UD82510_11

Sommaire 2 (HJB - Renault)



Section 2: Driving

Running in  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.2

Ignition switch  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.3

Starting, stopping the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.4

Stop and start function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.12

Special features of petrol and diesel versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.16

Special features of LPG versions   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.20

Gear lever, Handbrake   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.24

Electronic parking brake  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.25

“AUTOHOLD” function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.29

Eco-driving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.30

Maintenance and antipollution advice  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.38

Environment   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.39

Tyre pressure loss warning  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.40

Driver correction devices and aids   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.46

Lane departure warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.51

Lane keeping assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.56

Blind spot warning  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.62

Safe distance alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.69

360° camera   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.73

Active emergency braking  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.82

Detection of road signs  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.90

Speed limiter, cruise control   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.94

Stop and Go adaptive cruise control  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.103

Highway and Traffic Jam Companion  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.117

Parking distance control   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.133

Reversing camera  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.140

Parking exit warning   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.143

Assisted parking   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.147

Automatic gearbox, electronic lever, manual lever  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.152

Emergency call  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  2.162

driving ........................................................

(up to the end of the DU)

running in ...................................................

(current page)

2.2

ENG_UD79858_2

Rodage (HJB - Renault)



Running in

RUNNING IN

Petrol version

For the first

600 miles

(1,000 km), do

not exceed 78 mph (130 km/h) in the

highest gear, or 3,000 to 3,500 rpm.
You may only expect top performance

from your vehicle after approximately

1,800 miles (3,000 km)

.

Note:

 for a new vehicle in the running-in

phase: the coolant level may be higher

than the “

MAXI

” mark on the tank, then

drop to between the levels “

MINI

” and

MAXI

”. This does not present a risk.

Service intervals:

refer to the

Maintenance Document for your vehi-

cle.

Diesel version

For the first

930 miles (1,500 km),

 do

not exceed 80 mph (130 km/h) in the

highest gear, or 2,500 rpm.
After completing this mileage you may

drive faster, although you may only

expect top performance after approxi-

mately 3,600 miles (6,000 km).
During the running in period, do not ac-

celerate hard while the engine is still

cold and do not let the engine over-rev.

Note:

 for a new vehicle in the running-in

phase: the coolant level may be higher

than the “

MAXI

” mark on the tank, then

drop to between the levels “

MINI

” and

MAXI

”. This does not present a risk.

Service intervals:

refer to the

Maintenance Document for your vehi-

cle.

ignition switch ............................................

(current page)

starting the engine .....................................

(current page)

starting the engine .....................................

(current page)

switching on the vehicle ignition ................

(current page)

2.3

ENG_UD56606_1

Contacteur de démarrage : véhicule avec clé (HJB - Renault)



Ignition switch

IGNITION SWITCH: vehicle with key

“Ignition” position ON 2

The ignition is switched on: Any acces-

sories (radio etc.) can be used.

“Start” position START 3

If the engine fails to start at the first

attempt, the key must be turned back

before the starter can be activated

again. Release the key as soon as the

engine starts.

Note:

on diesel versions, several sec-

onds may pass between turning the

key and the engine starting to allow for

engine preheating.

Ignition switch

Off position LOCK 0 (steering lock

applied)

To lock: remove the key and turn the

steering wheel until the steering column

locks.
To unlock: turn the key and the steering

wheel slightly.

stopping the engine ...................................

(up to the end of the DU)

driving ........................................................

(up to the end of the DU)

starting the engine .....................................

(up to the end of the DU)

starting the engine .....................................

(current page)

switching on the vehicle ignition ................

(current page)

2.4

ENG_UD80090_4

Démarrage, arrêt moteur : véhicule avec clé (HJB - Renault)



Note:

 on vehicles equipped with a

manual gearbox, in the event of engine

stalling the message “Press Clutch” will

be displayed on the instrument panel.

Fully press the clutch pedal to restart

the engine.

Starting, stopping the engine

STARTING, STOPPING THE ENGINE: vehicle with key (1/2)

Starting the engine

To start:

On vehicles equipped with automatic

gearboxes with a mechanical lever, set

the lever to position

P

.

Petrol versions

–   Activate the starter

without acceler-

ating

;

–  release the key as soon as the

engine starts.

É

Diesel versions





–

Turn the ignition key to the

ON

”position

2

 and hold this position

until the engine preheating light goes

off;

–  turn the key to the start position

START

”

3



without pressing the

accelerator

;

–  release the key as soon as the

engine starts.

Special note:

 when starting the engine

in very low exterior temperatures (below

-10°C): hold down the clutch pedal until

the engine starts.

Stopping the engine

With the engine idling, turn the key to

the “

LOCK

” position

0

.

Never start your vehicle

while freewheeling on a gra-

dient. Risk of non-activation

of power-assisted steering.

There is a risk of accidents.

Driver’s responsibility



when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing etc., and the passive safety de-

vices such as the airbags and pre-

tensioners will no longer operate.

2.5

ENG_UD80090_4

Démarrage, arrêt moteur : véhicule avec clé (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with key (2/2)

Driver’s responsibility



when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY

.

Do not park the vehicle or

run the engine in locations

where combustible sub-

stances or materials such

as grass or leaves can come into

contact with the hot exhaust system.

Never switch off the igni-

tion before the vehicle has

stopped completely

. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing etc. and the passive safety de-

vices such as the airbags and pre-

tensioners will no longer operate.

LPG versions

The engine is always started using

petrol.

While the fuel tank is empty, the

vehicle cannot start or drive in

LPG mode only.

Operation using LPG/petrol bi-fuel

requires the presence of petrol (for

starting, high accelerations, cold

temperatures, etc.).

If the orange warning light



appears on the instrument panel

and a beep sounds, fill the tank with

fuel as soon as possible.

For more information on LPG ver-

sions

 2.20.

engine start/stop button .............................

(up to the end of the DU)

driving ........................................................

(up to the end of the DU)

starting the engine .....................................

(up to the end of the DU)

switching on the vehicle ignition ................

(up to the end of the DU)

2.6

ENG_UD80091_8

Démarrage, arrêt moteur : véhicule avec carte (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with card

(1/6)

The card must be inserted in detection

zone

1

.

To start:
–  vehicles with an automatic gearbox,

in the

P

 position, press the brake

pedal, press the

2

 button, then re-

lease the brake pedal once the

engine has started;

– vehicles with a manual gearbox,

press the brake pedal and press

the

2

 button, then release the brake

pedal once the engine has started.

If a gear is engaged, also press the

clutch pedal.

Note:

 on vehicles equipped with a

manual gearbox, in the event of engine

stalling the message “Press Clutch” will

be displayed on the instrument panel.

Fully press the clutch pedal to restart

the engine.

2

1

Special features

–  If one of the starting conditions is

not met, either the “Press Brake +

START” or “Press Clutch + START”

or “Select Gearbox Position P”

message is displayed on the instru-

ment panel;

–  in some cases, it will be necessary

to move the steering wheel whilst

pressing the start button

2

 to help

unlock the steering column; the

message “Turn Steering Wheel +

START” will warn you of this;

Driver’s responsibility



when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY

.

2.7

ENG_UD80091_8

Démarrage, arrêt moteur : véhicule avec carte (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with card

(2/6)

Driver’s responsibility



when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY

.

Do not park the vehicle or

run the engine in locations

where combustible sub-

stances or materials such

as grass or leaves can come into

contact with the hot exhaust system.

Never switch off the igni-

tion before the vehicle has

stopped completely

. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing etc. and the passive safety de-

vices such as the airbags and pre-

tensioners will no longer operate.

LPG versions

The engine is always started using

petrol.

While the fuel tank is empty, the

vehicle cannot start or drive in

LPG mode only.

Operation using LPG/petrol bi-fuel

requires the presence of petrol (for

starting, high accelerations, cold

temperatures, etc.).

If the orange warning light



appears on the instrument panel

and a beep sounds, fill the tank with

fuel as soon as possible.

For more information on LPG ver-

sions

 2.20.

accessories................................................

(current page)

operating faults ..........................................

(current page)

2.8

ENG_UD80091_8

Démarrage, arrêt moteur : véhicule avec carte (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with card

(3/6)

The message “Place card on zone +

START” appears on the instrument

panel.
Press the brake or clutch pedal, then

place the card

5

 (button side) on the

placement area

4

. Press the

2

 button

to start the vehicle. The message goes

out.

2

4

Operating faults

In certain cases, the hands-free card

may not work:
–  card battery flat, etc.;
–  near to appliances operating on the

same frequency as the card (moni-

tor, mobile phone, video game, etc.);

–  vehicle located in a high electromag-

netic radiation zone.

“Hands-free” starting with

the tailgate open

In this case, the card should not be lo-

cated in the luggage compartment, to

prevent the risk of loss.

Accessories function

(switching on the ignition)
Once you have gained access to your

vehicle, you may use some of its func-

tions (radio, navigation, wipers, etc.).
To use the other functions, with the

card in the passenger compartment,

press the

2

 button without pressing the

pedals.

4

5

stopping the engine ...................................

(current page)

2.9

ENG_UD80091_8

Démarrage, arrêt moteur : véhicule avec carte (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with card

(4/6)

Conditions for stopping the

engine

The vehicle must be stationary, lever

in position

P

 on vehicles with an auto-

matic gearbox.
With the card in the vehicle, press

button

2

: the engine stops. The steer-

ing column is locked when a door is

opened or the vehicle is locked.

When you leave your vehi-

cle, especially if you have

your card with you, check

that the engine is com-

pletely switched off.

2

If the card is no longer in the passen-

ger compartment or if the card’s bat-

tery is flat, when the vehicle is station-

ary and you try to switch the engine off,

the message “Keycard absent : press/

hold START” appears on the instrument

panel: press the

2

 button for longer than

three seconds.
If the card is no longer in the passenger

compartment, make sure you can re-

trieve it before pressing and holding the

button. Without the card, you will not be

able to restart the vehicle.
With the engine switched off, any ac-

cessories being used (radio, etc.) will

continue to function for approximately

10 minutes.
When the driver’s door is opened, the

accessories stop working.

Driver’s responsibility



when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY

.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing etc., and the passive safety de-

vices such as the airbags and pre-

tensioners will no longer operate.

2.10

ENG_UD80091_8

Démarrage, arrêt moteur : véhicule avec carte (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with card

(5/6)

Remote engine start-up

This function allows remote starting of

the engine.

Initialisation

If the vehicle is so equipped, press

the unlocking button

7

 then press the

remote start button twice in succession

for about 2 seconds each time

6

. The

time between the two presses must be

less than 5 seconds. The hazard warn-

ing lights will come on continuously for

3 seconds to confirm the system reset.

Note:

 once the function has been acti-

vated, it cannot be deactivated.
We advise you to contact an Approved

Dealer.

Operation

To start the engine remotely, press

the locking button

8

 then within an-

other 2 seconds, press the remote start

button

6

 for approximately 2 seconds.

The hazard lights come on continu-

ously for approximately 3 seconds and

the engine starts.
The engine will run for 5 minutes. Once

the engine is running, you can add an-

other 5 minutes by pressing the

8

 lock-

ing button again, then the remote start

button

6

. The hazard lights come on

continuously for 3 seconds to confirm

that the function has been prolonged.

9

6

7

8

This function also lets you programme

the engine to start, in order to heat or

ventilate the passenger compartment

up to 24 hours before using the vehicle.
Depending on the vehicle, configuration

and programming are carried out using

the multimedia display

9

, for more infor-

mation please refer to the multimedia

instructions.

2.11

ENG_UD80091_8

Démarrage, arrêt moteur : véhicule avec carte (HJB - Renault)



STARTING, STOPPING THE ENGINE: vehicle with card

(6/6)

Do not use the engine



remote start-up function or

its programming when:
– the vehicle is in a garage

or in a confined space.

Risk of poisoning or suffoca-

tion by exhaust gas emissions

.

–  the vehicle is covered with a pro-

tective cover.

Fire hazard

.

–  the bonnet is open or before it

opens.

Risk of burns or serious injury

.

Depending on the country, the

remote start function or its pro-

gramming may be prohibited by

law and/or by the regulations in

force.
Before using this function, check

the legislation and/or the regula-

tions in force for the country

.

In the event that the func-

tion is used, please ensure

that power-consuming de-

vices (such as the wipers,

exterior lights, radio, heated seats,

heated steering wheel, etc.) are de-

activated and all accessories are

disconnected before leaving the ve-

hicle.

Fire hazard

.

The remote engine start-up operates if:
–  the gearbox is in

 or

N

 position

on vehicles fitted with an automatic

gearbox;

–  the ignition is switched off;
–  the bonnet is closed;
–  all of the opening elements (doors

and luggage compartment) are



closed and locked when you leave

the vehicle;

–  in extreme weather conditions, the

remote engine start-up by program-

ming may not work.

If one of these conditions is not met, the

lights will flash for approximately 3 sec-

onds.

Remote engine start performance



varies according to surroundings such

as:
–  Obstacles, buildings, walls, other ve-

hicles, etc.;

–  radio frequency interference (tele-

vision, radio, mobile phone, other

remote controls, etc.);

–  Condition of the key/card battery.

starting the engine .....................................

(up to the end of the DU)

Stop & Start function..................................

(up to the end of the DU)

indicators:

instrument panel ..................................

(up to the end of the DU)

instrument panel messages.......................

(up to the end of the DU)

engine standby ..........................................

(up to the end of the DU)

instrument panel ........................................

(up to the end of the DU)

2.12

ENG_UD82506_6

Fonction Stop and Start (HJB - Renault)



The vehicle equipment remain opera-

tional while the engine is stopped.
When the engine switches to standby,

the steering assistance may no longer

be operational.
In this case it becomes operational

again when the engine is no longer on

standby or the speed exceeds approxi-

mately 1 mph (1 km/h) (downhill, slope

etc.).

stop and start function

STOP AND START FUNCTION

(1/4)

The engine MUST be



stopped (not put in standby)

before leaving the vehicle.

 2.4

 2.6.

If the engine is put in



standby, the electronic



parking brake (depending

on the vehicle) is not ap-

plied automatically.

This system enables a reduced fuel

consumption and lower greenhouse

gas emissions. The system is acti-

vated automatically when the vehicle

is started. During driving, the system

stops the engine (standby) when the

vehicle comes to a stop or is moving

at a slow speed (depending on the ve-
hicle). The

 warning light is dis-

played on the instrument panel.

Conditions of standby at low

speed

The vehicle has set off from where it

was parked;

For vehicles equipped with auto-

matic gearboxes:

–  the gearbox is in position D, M or N;

and

–  the brake pedal is depressed (suffi-

ciently hard);

  If the

 warning light flashes,

this means that the brake pedal is

not sufficiently pressed;

and

– the accelerator pedal is not de-

pressed;

and

–  the speed is zero or, depending on

the vehicle, as soon as the speed is

lower than a threshold specific to the

vehicle.

The engine remains on standby if posi-

tion P is selected, or if position N is se-

lected with the handbrake engaged and

the brake pedal released.

For vehicles equipped with manual

gearboxes:

–  the gearbox is in neutral;

and

–  the clutch pedal is released. If the

 warning light flashes, this

means that the clutch pedal must be

released completely;

and

–  the vehicle speed is lower than a

threshold specific to the vehicle.

For all vehicles:

Warning light

 on the instru-

ment panel is lit when the engine is on

standby.

Keep your vehicle station-

ary when the engine is

on standby (shown by the
warning light

 on the

instrument panel).















Content      ..     2      3      4      5     ..
