LEXUS RC F (2019 year). Instruction - part 12




3-5. Opening, closing the windows and moon roof






4-1. Before


Driving the vehicle...................... 192
Cargo and luggage....................201
Vehicle load limits......................204
Trailer towing.............................. 205
Dinghy towing ............................ 206

4-2. Driving procedures

Engine (ignition) switch ...........207
Automatic transmission............ 213
Turn signal lever........................... 221
Parking brake ..............................222

(Active Sound Control)


(Active Sound Control)
(RC F)...........................................224

4-3.  Operating the lights and


Headlight switch.........................225
Automatic High Beam.............228
Fog light switch ...........................232
Windshield wipers and


4-4. Refueling

Opening the fuel tank cap .......241

4-5.  Using the driving support


Lexus Safety System+..............245

(Pre-Collision System) .........250


(Lane Departure Alert
with steering control) ..............261

Dynamic radar cruise

control .........................................268

Intuitive parking assist..............280

(Blind Spot Monitor)..............290
• BSM function.........................293
• RCTA function...................... 297

Driving mode select

switch ............................................ 301

Active rear wing.........................307

(Torque Vectoring
Differential)................................. 310

Driving assist systems ............... 312

4-6. Driving tips

Winter driving tips.....................320



4-1. Before driving

P. 207

With the brake pedal depressed, shift the shift lever to D. (

P. 213)

Release the parking brake. (

P. 222)

Gradually release the brake pedal and gently depress the accelerator pedal
to accelerate the vehicle.

With the shift lever in D, depress the brake pedal.
If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift lever to P or

N. (

P. 213)

With the shift lever in D, depress the brake pedal.
Set the parking brake (

P. 222), and shift the shift lever to P (P. 213).

Press the engine switch to stop the engine.
Lock the door, making sure that you have the electronic key on your person.

If parking on a hill, block the wheels as needed.

Make sure that the parking brake is set and shift the shift lever to D.
Gently depress the accelerator pedal.
Release the parking brake.

Driving the vehicle

The following procedures should be observed to ensure safe driving:

Starting the engine



Parking the vehicle

Starting off on a steep uphill










4-1. Before driving





When starting off on an uphill
The hill-start assist control will activate. (

P. 312)

Driving in the rain

Drive carefully when it is raining, because visibility will be reduced, the windows may

become fogged-up, and the road will be slippery.

Drive carefully when it starts to rain, because the road surface will be especially slip-


Refrain from high speeds when driving on an expressway in the rain, because there may

be a layer of water between the tires and the road surface, preventing the steering and

brakes from operating properly.

Engine speed while driving
In the following conditions, the engine speed may become high while driving. This is due

to automatic up-shifting control or down-shifting implementation to meet driving condi-

tions. It does not indicate sudden acceleration.

The vehicle is judged to be driving uphill or downhill

When the accelerator pedal is released

When the brake pedal is depressed while sport mode is selected

Restraining the engine output (Brake Override System)

When the accelerator and brake pedals are depressed at the same time, the engine

output may be restrained.

A warning message is displayed on the multi-information display while the system is

operating. (

P. 477)

Restraining sudden start (Drive-Start Control)

When the following unusual operation is performed, the engine output may be

• When the shift lever is shifted from R to D, D to R, N to R, P to D, or P to R (D

includes M) with the accelerator pedal depressed, a warning message appears on

the multi-information display. (

P. 465)

• When the accelerator pedal is depressed too much while the vehicle is in reverse.

While Drive-Start Control is being activated, your vehicle may have trouble escaping

from the mud or fresh snow. In such case, deactivate TRC (

P. 314) to cancel Drive-

Start Control so that the vehicle may become able to escape from the mud or fresh


Breaking in your new Lexus
To extend the life of the vehicle, observing the following precautions is recommended:

For the first 186 miles (300 km):

Avoid sudden stops.

For the first 621 miles (1000 km):
• Do not drive at extremely high speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low gears.

• Do not drive at a constant speed for extended periods.


4-1. Before driving


Drum-in-disc type parking brake system
Your vehicle has a drum-in-disc type parking brake system. This type of brake system

needs bedding-down of the brake shoes periodically or whenever the parking brake

shoes and/or drum are replaced. Have your Lexus dealer perform the bedding down


Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability of the cor-

rect fuel. (

P. 554)

Brake pads and discs (RC F)
The brake pads and discs are designed for use under high load conditions. Therefore,

brake noise may be generated depending on the vehicle speed, braking force and vehi-

cle environment (temperature, humidity, etc.).

Idling time before engine stop (RC300)
To prevent damage to the turbocharger, allow the engine to idle immediately after high-

load driving.

Driving condition

Idling time

Normal city driving or high-speed driving (at the highway speed

limit or recommended speed)

Not necessary

Steep hill driving, continuous driving (race track driving etc.)


1 minute


4-1. Before driving






Observe the following precautions.

Failure to do so may result in death or serious injury.

When starting the vehicle
Always keep your foot on the brake pedal while stopped with the engine running. This

prevents the vehicle from creeping.

When driving the vehicle

Do not drive if you are unfamiliar with the location of the brake and accelerator ped-

als to avoid depressing the wrong pedal.
• Accidentally depressing the accelerator pedal instead of the brake pedal will

result in sudden acceleration that may lead to an accident.

• When backing up, you may twist your body around, leading to a difficulty in oper-

ating the pedals. Make sure to operate the pedals properly.

• Make sure to keep a correct driving posture even when moving the vehicle only

slightly. This allows you to depress the brake and accelerator pedals properly.

• Depress the brake pedal using your right foot. Depressing the brake pedal using

your left foot may delay response in an emergency, resulting in an accident.

Do not drive the vehicle over or stop the vehicle near flammable materials.

The exhaust system and exhaust gases can be extremely hot. These hot parts may

cause a fire if there is any flammable material nearby.

During normal driving, do not turn off the engine. Turning the engine off while driving

will not cause loss of steering or braking control, but the power assist to these systems

will be lost. This will make it more difficult to steer and brake, so you should pull over

and stop the vehicle as soon as it is safe to do so.

However, in the event of an emergency, such as if it becomes impossible to stop the

vehicle in the normal way:

P. 443

Use engine braking (downshift) to maintain a safe speed when driving down a steep


Using the brakes continuously may cause the brakes to overheat and lose effective-

ness. (

P. 213)

Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear

view mirrors while driving.

Doing so may result in a loss of vehicle control.

Always check that all passengers’ arms, heads or other parts of their body are not

outside the vehicle.

Do not drive in excess of the speed limit. Even if the legal speed limit permits it, do not

drive over 85 mph (140 km/h) unless your vehicle has high-speed capability tires.

Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible

injury. Be sure to consult a tire dealer to determine whether the tires on your vehicle

are high-speed capability tires or not before driving at such speeds.


4-1. Before driving



Observe the following precautions.

Failure to do so may result in death or serious injury.

When driving on slippery road surfaces

Sudden braking, acceleration and steering may cause tire slippage and reduce your

ability to control the vehicle.

Sudden acceleration, engine braking due to shifting, or changes in engine speed

could cause the vehicle to skid.

After driving through a puddle, lightly depress the brake pedal to make sure that the

brakes are functioning properly. Wet brake pads may prevent the brakes from func-

tioning properly. If the brakes on only one side are wet and not functioning properly,

steering control may be affected.

When shifting the shift lever

Do not let the vehicle roll backward while the shift lever is in a driving position, or roll

forward while the shift lever is in R.

Doing so may cause the engine to stall or lead to poor brake and steering perfor-

mance, resulting in an accident or damage to the vehicle.

Do not shift the shift lever to P while the vehicle is moving.

Doing so can damage the transmission and may result in a loss of vehicle control.

Do not shift the shift lever to R while the vehicle is moving forward.

Doing so can damage the transmission and may result in a loss of vehicle control.

Do not shift the shift lever to a driving position while the vehicle is moving backward.

Doing so can damage the transmission and may result in a loss of vehicle control.

Moving the shift lever to N while the vehicle is moving will disengage the engine from

the transmission. Engine braking is not available when N is selected.

Be careful not to shift the shift lever with the accelerator pedal depressed. Shifting the

shift lever to a gear other than P or N may lead to unexpected rapid acceleration of

the vehicle that may cause an accident and result in death or serious injury.

If you hear a squealing or scraping noise (brake pad wear limit indicators) (RC350/

Have the brake pads checked and replaced by your Lexus dealer as soon as possible.

Rotor damage may result if the pads are not replaced when needed.
Front brakes on F SPORT models (RC350 [2WD]/RC300 [2WD] only): Moderate

levels of brake pad and disc wear allow enhanced front braking power. As a result, the

discs may wear more quickly than conventional brake discs. Therefore, when replacing

the brake pads, Lexus recommends that you also have the thickness of the discs mea-


It is dangerous to drive the vehicle when the wear limits of the brake pads and/or those

of the brake discs are exceeded.


4-1. Before driving






Observe the following precautions.

Failure to do so may result in death or serious injury.

If a brake pad wear warning message is displayed (RC F)
Have the brake pads visually checked and replaced by your Lexus dealer as soon as


Rotor damage may result if the pads are not replaced when needed.
Moderate levels of the brake pad and disc wear allow enhanced braking power. As a

result, the discs may wear more quickly than conventional brake discs. Therefore, when

replacing the brake pads, Lexus recommends that you also have the thickness of the

discs measured.

It is dangerous to drive the vehicle when the wear limits of the brake pads and/or those

of the brake discs are exceeded.

When the vehicle is stopped

Do not race the engine.

If the vehicle is in any gear other than P or N, the vehicle may accelerate suddenly

and unexpectedly, causing an accident.

In order to prevent accidents due to the vehicle rolling away, always keep depressing

the brake pedal while the engine is running, and apply the parking brake as neces-


If the vehicle is stopped on an incline, in order to prevent accidents caused by the

vehicle rolling forward or backward, always depress the brake pedal and securely

apply the parking brake as needed.

Avoid revving or racing the engine.

Running the engine at high speed while the vehicle is stopped may cause the exhaust

system to overheat, which could result in a fire if combustible material is nearby.


4-1. Before driving



Observe the following precautions.

Failure to do so may result in death or serious injury.

When the vehicle is parked

Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle

when it is in the sun.

Doing so may result in the following:
• Gas may leak from a cigarette lighter or spray can, and may lead to a fire.

• The temperature inside the vehicle may cause the plastic lenses and plastic mate-

rial of glasses to deform or crack.

• Soft drink cans may fracture, causing the contents to spray over the interior of the

vehicle, and may also cause a short circuit in the vehicle’s electrical components.

Do not leave cigarette lighters in the vehicle. If a cigarette lighter is in a place such as

the glove box or on the floor, it may be lit accidentally when luggage is loaded or the

seat is adjusted, causing a fire.

Do not attach adhesive discs to the windshield or windows. Do not place containers

such as air fresheners on the instrument panel or dashboard. Adhesive discs or con-

tainers may act as lenses, causing a fire in the vehicle.

Do not leave a door or window open if the curved glass is coated with a metallized

film such as a silver-colored one. Reflected sunlight may cause the glass to act as a

lens, causing a fire.

Always apply the parking brake, shift the shift lever to P, stop the engine and lock the


Do not leave the vehicle unattended while the engine is running.

If the vehicle is parked with the shift lever in P but the parking brake is not set, the

vehicle may start to move, possibly leading to an accident.

Do not touch the exhaust pipes while the engine is running or immediately after turn-

ing the engine off.

Doing so may cause burns.

When taking a nap in the vehicle
Always turn the engine off. Otherwise, if you accidentally move the shift lever or

depress the accelerator pedal, this could cause an accident or fire due to engine over-

heating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases

may collect and enter the vehicle, leading to death or a serious health hazard.


4-1. Before driving






Observe the following precautions.

Failure to do so may result in death or serious injury.

When braking

When the brakes are wet, drive more cautiously.

Braking distance increases when the brakes are wet, and this may cause one side of

the vehicle to brake differently than the other side. Also, the parking brake may not

securely hold the vehicle.

If the brake booster device does not operate, do not follow other vehicles closely and

avoid hills or sharp turns that require braking.

In this case, braking is still possible, but the brake pedal should be depressed more

firmly than usual. Also, the braking distance will increase. Have your brakes fixed


Do not pump the brake pedal if the engine stalls.

Each push on the brake pedal uses up the reserve for the power-assisted brakes.

The brake system consists of 2 individual hydraulic systems; if one of the systems fails,

the other will still operate. In this case, the brake pedal should be depressed more

firmly than usual and the braking distance will increase. Have your brakes fixed imme-


If the vehicle becomes stuck
Do not spin the wheels excessively when any of the tires is up in the air, or the vehicle is

stuck in sand, mud, etc. This may damage the driveline components or propel the vehi-

cle forward or backward, causing an accident.


4-1. Before driving



When driving the vehicle

Do not depress the accelerator and brake pedals at the same time while driving, as

this may restrain the engine output.

Do not use the accelerator pedal or depress the accelerator and brake pedals at the

same time to hold the vehicle on a hill.

When parking the vehicle
Always set the parking brake, and shift the shift lever to P. Failure to do so may cause

the vehicle to move or the vehicle may accelerate suddenly if the accelerator pedal is

accidentally depressed.

Avoiding damage to vehicle parts

Do not turn the steering wheel fully in either direction and hold it there for an

extended period of time.

Doing so may damage the power steering motor.

When driving over bumps in the road, drive as slowly as possible to avoid damaging

the wheels, underside of the vehicle, etc.

RC300: Make sure to idle the engine immediately after high-load driving. Stop the

engine only after the turbocharger has cooled down.

Failure to do so may cause damage to the turbocharger.

If you get a flat tire while driving
A flat or damaged tire may cause the following situations. Hold the steering wheel

firmly and gradually depress the brake pedal to slow down the vehicle.

It may be difficult to control your vehicle.

The vehicle will make abnormal sounds or vibrations.

The vehicle will lean abnormally.

Information on what to do in case of a flat tire (

P. 489, 502)

When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may cause the

following serious damage to the vehicle:

Engine stalling

Short in electrical components

Engine damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be sure to have

your Lexus dealer check the following:

Brake function

Changes in quantity and quality of oil and fluid used for the engine, transmission,

transfer (AWD models), differential, etc.

Lubricant condition for the propeller shaft, bearings and suspension joints (where

possible), and the function of all joints, bearings, etc.


4-1. Before driving





Cargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capacity) — (Total weight of occupants)
Steps for Determining Correct Load Limit —

(1) Locate the statement “The combined weight of occupants and cargo should

never exceed XXX kg or XXX lbs.” on your vehicle’s placard.

(2) Determine the combined weight of the driver and passengers that will be rid-

ing in your vehicle.

(3) Subtract the combined weight of the driver and passengers from XXX kg or

XXX lbs.

(4) The resulting figure equals the available amount of cargo and luggage load

For example, if the “XXX” amount equals 1400 lbs. and there will be five 150
lb passengers in your vehicle, the amount of available cargo and luggage load
capacity is 650 lbs. (1400

 750 (5150) = 650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded on the

vehicle. That weight may not safely exceed the available cargo and luggage
load capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be transferred

to your vehicle. Consult this manual to determine how this reduces the avail-
able cargo and luggage load capacity of your vehicle.

P. 204)

Lexus does not recommend towing a trailer with your vehicle. Your vehicle is not

designed for trailer towing.

Cargo and luggage

Take notice of the following information about storage precautions, cargo
capacity and load:

Capacity and distribution


4-1. Before driving


Cargo capacity
Total load capacity (vehicle capacity
weight) (

P. 536)

When 2 people with the combined weight of A lb. (kg) are riding in your vehicle,
which has a total load capacity (vehicle capacity weight) of B lb. (kg), the avail-
able amount of cargo and luggage load capacity will be C lb. (kg) as follows:



 lb. (kg) - A



 lb. (kg) = C



 lb. (kg)



: A =Weight of people



: B =Total load capacity



: C =Available cargo and luggage load

In this condition, if 2 more passengers with the combined weight of D lb. (kg) get on,

the available cargo and luggage load will be reduced E lb. (kg) as follows:

C lb. (kg) - D



 lb. (kg) = E



 lb. (kg)



: D =Additional weight of people



: E =Available cargo and luggage load

As shown in the example above, if the number of occupants increases, the cargo
and luggage load will be reduced by an amount that equals the increased weight
due to the additional occupants. In other words, if an increase in the number of
occupants causes an excess of the total load capacity (combined weight of occu-
pants plus cargo and luggage load), you must reduce the cargo and luggage on
your vehicle.

Calculation formula for your vehicle




4-1. Before driving






Things that must not be carried in the trunk
The following things may cause a fire if loaded in the trunk:

Receptacles containing gasoline

Aerosol cans

Storage precautions
Observe the following precautions.

Failure to do so may prevent the pedals from being depressed properly, may block the

driver’s vision, or may result in items hitting the driver or passengers, possibly causing

an accident.

Stow cargo and luggage in the trunk whenever possible.

RC350/RC300: To prevent cargo and luggage from sliding forward during braking,

do not stack anything in the enlarged trunk. Keep cargo and luggage low, as close to

the floor as possible.

RC350/RC300:  When  you  fold  down  the  rear  seats,  long  items  should  not  be

placed directly behind the front seats.

RC350/RC300: Never allow anyone to ride in the enlarged trunk. It is not designed

for passengers. They should ride in their seats with their seat belts properly fastened.

Do not place cargo or luggage in or on the following locations.
• At the feet of the driver

• On the front passenger or rear seats (when stacking items)

• On the package tray

• On the instrument panel

• On  the  dashboard

• In front of the Center Display

Secure all items in the occupant compartment.

Capacity and distribution

Do not exceed the maximum axle weight rating or the total vehicle weight rating.

Even if the total load of occupant’s weight and the cargo load is less than the total load

capacity, do not apply the load unevenly. Improper loading may cause deterioration

of steering or braking control which may cause death or serious injury.


4-1. Before driving


Total load capacity (vehicle capacity weight): (

P. 536)

Total load capacity means the combined weight of occupants, cargo and lug-

Seating capacity: 4 occupants (Front 2, Rear 2)

Seating capacity means the maximum number of occupants whose estimated
average weight is 150 lb. (68 kg) per person.

Towing capacity

Lexus does not recommend towing a trailer with your vehicle.

Cargo capacity

Cargo capacity may increase or decrease depending on the weight and the
number of occupants.

Total load capacity and seating capacity
These details are also described on the tire and loading information label. (

P. 420)

Vehicle load limits

Vehicle load limits include total load capacity, seating capacity, towing capac-
ity and cargo capacity.


Overloading the vehicle
Do not overload the vehicle.

It may not only cause damage to the tires, but also degrade steering and braking ability,

resulting in an accident.


4-1. Before driving





Trailer towing

Lexus does not recommend towing a trailer with your vehicle. Lexus also does
not recommend the installation of a tow hitch or the use of a tow hitch carrier
for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer
towing or for the use of tow hitch mounted carriers.








Content   ..  10  11  12  13   ..
