LEXUS NX 300H (2019 year). Instruction - part 11




4-2. Driving procedures

LEXUS NX300h Owners Manu-


driven on a hill, driven at high speeds, etc.

The temperature of the hybrid system is


The vehicle has been left in temperatures

lower than about 32 °F (0 °C) for a long

period of time, etc.

The gasoline engine is warming up.

The hybrid battery (traction battery) is


The remaining battery level indicated in

the “Energy Monitor” display is low.



Vehicle speed is high.

The accelerator pedal is depressed firmly

or the vehicle is on a hill, etc.

The windshield defogger is in use.

Switching to EV drive mode when the

gasoline engine is cold

If the hybrid system is started while the gas-

oline engine is cold, the gasoline engine will

start automatically after a short period of

time in order to warm up. In this case, you

will become unable to switch to EV drive


After the hybrid system has started and the

“READY” indicator has illuminated, press

the EV drive mode switch before the gaso-

line engine starts to switch to EV drive


Automatic cancelation of EV drive


When driving in EV drive mode, the gaso-

line engine may automatically restart in the

following situations. When EV drive mode

is canceled, a buzzer will sound, the EV

drive mode indicator will go off after flash-

ing, and a message is displayed on the

multi-information display.

The hybrid battery (traction battery)

becomes low.

The remaining battery level indicated in

the “Energy Monitor” display is low.



Vehicle speed is high.

The accelerator pedal is depressed firmly

or the vehicle is on a hill, etc.

Possible driving distance when driving in

EV drive mode

EV drive mode’s possible driving distance

ranges from a few hundred meters to

approximately 0.6 mile (1 km). However,

depending on vehicle conditions, there are

situations when EV drive mode cannot be

used. (The distance that is possible depends

on the hybrid battery [traction battery] level

and driving conditions.)

Fuel economy

The hybrid system is designed to achieve

the best possible fuel economy during nor-

mal driving (using the gasoline engine and

electric motor [traction motor]). Driving in

EV drive mode more than necessary may

lower fuel economy.


Caution while driving

When driving in EV drive mode, pay spe-

cial attention to the area around the vehi-

cle. Because there is no engine noise,

pedestrians, people riding bicycles or

other people and vehicles in the area

may not be aware of the vehicle starting

off or approaching them, so take extra

care while driving.


4-2. Driving procedures

LEXUS NX300h Owners Manu-





: To improve fuel efficiency and reduce

noise, shift the shift lever to D for normal
You can choose gear range suitable for
your driving situation by operating the
paddle shift switches.


: By selecting shift ranges using S mode,

you can control accelerating force and
engine braking force.

S mode

When the shift range is 4 or lower, hold-

ing the shift lever toward “+” sets the shift

range to 6.

Automatically selects a higher shift range

before the engine speed becomes too


When driving with dynamic radar cruise

control with full-speed range activated

Even when performing the following

actions with the intent of enabling engine

braking, engine braking will not activate

because dynamic radar cruise control with

full-speed range will not be canceled.

While driving in S mode, downshifting to

5 or 4. (


When switching the driving mode to

Sport mode while driving in D position.



Restraining sudden start (Drive-Start


When the following unusual operation is

performed, the hybrid system output may

be restrained.

When the shift lever is shifted from R to D,

D to R, N to R, P to D, or P to R (D

includes S) with the accelerator pedal

depressed, a warning message appears

on the multi-information display. If a

warning message is shown on the multi-

information display, read the message

and follow the instructions.

When the accelerator pedal is depressed

too while the vehicle is in reverse.

Hybrid transmission

Select the shift position depending
on your purpose and situation.

Shift position purpose and func-

Shift posi-


Objective or function


Parking the vehicle/starting

the hybrid system






Normal driving



S mode driving





When driving on slippery road sur-


Be careful of downshifting and sudden

acceleration, as this could result in the

vehicle skidding to the side or spinning.


Hybrid battery (traction battery)


If the shift lever is in N, the hybrid battery

(traction battery) will not be charging,

even when the engine is running. There-

fore, if the vehicle is left with the shift

lever in N for a long period of time, the

hybrid battery (traction battery) will dis-

charge, and this may result in the vehicle

not being able to start.


4-2. Driving procedures

LEXUS NX300h Owners Manu-


Shift lock system

The shift lock system is a system to prevent

accidental operation of the shift lever in

The shift lever can be shifted from P only

when the power switch is in ON mode and

the brake pedal is being depressed.

If the shift lever cannot be shifted from P

First, check whether the brake pedal is

being depressed.

If the shift lever cannot be shifted with your

foot on the brake pedal, there may be a

problem with the shift lock system. Have the

vehicle inspected by your Lexus dealer


The following steps may be used as an

emergency measure to ensure that the shift

lever can be shifted.

Releasing the shift lock:


Set the parking brake.


Turn the power switch off.


Depress the brake pedal.


Pry the cover up with a flathead screw-

driver or equivalent tool.

To prevent damage to the cover, cover the

tip of the screwdriver with a rag.


Press the shift lock override button.

The shift lever can be shifted while the but-

ton is pressed


Shifting the shift lever

While the power switch is in ON
mode, move the shift lever with the
brake pedal depressed.
When shifting the shift lever between P
and D, make sure that the vehicle is
completely stopped.


To prevent an accident when releas-

ing the shift lock

Before pressing the shift lock override

button, make sure to set the parking

brake and depress the brake pedal.

If the accelerator pedal is accidentally

depressed instead of the brake pedal

when the shift lock override button is

pressed and the shift lever is shifted out

of P, the vehicle may suddenly start, pos-

sibly leading to an accident resulting in

death or serious injury.

Selecting the driving mode


4-2. Driving procedures

LEXUS NX300h Owners Manu-




To drive using temporary shift range
selection, operate the “-” paddle shift
switch while the shift lever in D. Chang-
ing the shift range enables the level of
engine braking force to be selected.
The shift range can then be selected by
operating the “-” and “+” paddle shift





The selected shift range, from 1 to 6, will be
displayed on the multi-information display.
The initial shift range is 4 when the “-” pad-
dle shift switch is operated.
To return to normal D position driving, the
“+” paddle shift switch must be held down
for a period of time.

Shift ranges and their functions

 You can choose from 6 levels of

engine braking force.

 A lower shift range will provide

greater engine braking force than a
higher shift range, and the engine
revolutions will also increase.

Automatic deactivation of shift range

selection in the D position

Shift range selection in the D position will

be deactivated in the following situations:

When the vehicle comes to a stop

If the accelerator pedal is depressed for

more than a certain period of time

When the shift lever is shifted to a posi-

tion other than D

To enter S mode, shift the shift lever to
S. Shift ranges can be selected by
operating the shift lever or paddle shift
switches, allowing you to drive in the
shift range of your choice. The shift
range can be selected by operating the
shift lever or the “-” and “+” paddle shift





The selected shift range, from 1 to 6, will be
The initial shift range in S mode is 4.

Selecting shift ranges in the D

Selecting shift ranges in the S


4-2. Driving procedures

LEXUS NX300h Owners Manu-


Shift ranges and their functions

 You can choose from 6 levels of

accelerating force and engine brak-
ing force.

 A lower shift range will provide

greater accelerating force and
engine braking force than a higher
shift range, and the engine revolu-
tions will also increase.

Downshifting restriction warning


To help ensure safety and driving perfor-

mance, downshifting operation may some-

times be restricted. In some circumstances,

downshifting may not be possible even

when the shift lever or paddle shift switch is

operated. (A buzzer will sound twice.)


Right turn


Lane change to the right (move the
lever partway and release it)
The right hand signals will flash 3


Lane change to the left (move the
lever partway and release it)
The left hand signals will flash 3


Left turn

Turn signals can be operated when

The power switch is in ON mode.

If the indicator flashes faster than usual

Check that a light bulb in the front or rear

turn signal lights has not burned out.



Turn signal lever

Operating instructions


4-2. Driving procedures

LEXUS NX300h Owners Manu-




Turns automatic mode on

While the vehicle is stopped, pull and
hold the parking brake switch until the
automatic mode lamp turns on.

Parking brake indicator (U.S.A.)
Parking brake indicator (Canada)
Parking brake lamp
Automatic mode lamp

The parking brake is set or released
automatically according to shift lever
 When the shift lever is moved out of

P, the parking brake will be released,
and the parking brake indicator light
and parking brake lamp turn off.

 When the shift lever is moved into P,

the parking brake will be set, and the
parking brake indicator light and
parking brake lamp turn on.

Operate the shift lever with the brake
pedal depressed.

Turns automatic mode off

While the vehicle is stopped, press and
hold the parking brake switch until the
automatic mode lamp turns off.

Parking brake indicator (U.S.A.)
Parking brake indicator (Canada)
Parking brake lamp
Automatic mode lamp

Parking brake

The parking brake can be set or
released automatically or manually.
In automatic mode, the parking
brake can be set or released auto-
matically according to shift lever
operation. Also, even in automatic
mode, the parking brake can be set
or released manually.

Operating instructions




4-2. Driving procedures

LEXUS NX300h Owners Manu-


Using the manual mode

The parking brake can be set and
released manually.

Parking brake indicator (U.S.A.)
Parking brake indicator (Canada)
Parking brake lamp
Automatic mode lamp


Sets the parking brake

The parking brake indicator light and park-
ing brake lamp will turn on.
Pull and hold the parking brake switch if an
emergency occurs and it is necessary to
operate the parking brake while driving.


Releases the parking brake

Operate the parking brake switch while
depressing the brake pedal. Make sure
that the parking brake indicator light and
parking brake lamp turn off.
If the parking brake indicator light and
parking brake lamp flashes, operate the
switch again. (


Parking brake operation

When the power switch is not in ON

mode, the parking brake cannot be

released using the parking brake switch.

When the power switch is not in ON

mode, automatic mode (automatic brake

setting and releasing) is not available.

If “Parking Brake Overheated Parking

Brake Unavailable” is displayed on the

multi-information display

If the parking brake is operated repeatedly

over a short period of time, the system may

restrict operation to prevent overheating. If

this happens, refrain from operating the

parking brake. Normal operation will return

after about 1 minute.

Parking brake operation sound

When the parking brake operates, a motor

sound (whirring sound) may be heard. This

does not indicate a malfunction.

Parking brake indicator light and park-

ing brake lamp

Depending on the power switch mode,

the parking brake indicator light and

parking brake lamp will turn on and stay

on as described below:

ON mode: Comes on until the parking

brake is released.

Not in ON mode: Stays on for approxi-

mately 15 seconds.

When the power switch is turned off with

the parking brake set, the parking brake

indicator light and parking brake lamp

will stay on for about 15 seconds. This

does not indicate a malfunction.

Changing the mode

When changing the automatic mode on/off,

the message will be shown on the multi-

information display and the buzzer sounds.

Parking the vehicle


Parking brake engaged warning buzzer

A buzzer will sound if the vehicle is driven

with the parking brake engaged. “Release

Parking Brake” is displayed on the multi-

information display.



4-2. Driving procedures

LEXUS NX300h Owners Manu-




Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

If the brake system warning light comes



Usage in winter time


Turns the brake hold system on

The brake hold standby indicator


(green) comes on. While the system is
holding the brake, the brake hold operated

 (yellow) comes on.

Brake hold system operating conditions

The brake hold system cannot be turned on

in the following conditions:

The driver’s door is not closed.

The driver is not wearing the seat belt.

If any of the conditions above are detected

when the brake hold system is enabled, the

system will turn off and the brake hold

standby indicator light will go off. In addi-

tion, if any of the conditions are detected

while the system is holding the brake, a

warning buzzer will sound and a message

will be shown on the multi-information dis-


When parking the vehicle

Do not leave a child in the vehicle alone.

The parking brake may be released unin-

tentionally and there is the danger of the

vehicle moving that may lead to an acci-

dent resulting in death or serious injury.

Parking brake switch

Do not set any objects near the parking

brake switch. Objects may interfere with

the switch and may lead the parking

brake to unexpectedly operate.


When parking the vehicle

Before you leave the vehicle, shift the

shift lever to P, set the parking brake and

make sure that the vehicle does not


When the system malfunctions

Stop the vehicle in a safe place and

check the warning messages.

When the parking brake cannot be

released due to a malfunction

Driving the vehicle with the parking

brake set will lead to brake components

overheating, which may affect braking

performance and increase brake wear.

Have the vehicle inspected by contact

your Lexus dealer immediately if this


Brake Hold

The brake hold system keeps the
brake applied when the shift lever is
in D, S or N with the system on and
the brake pedal has been
depressed to stop the vehicle. The
system releases the brake when the
accelerator pedal is depressed with
the shift lever in D or S to allow
smooth start off.

Enabling the system




4-2. Driving procedures

LEXUS NX300h Owners Manu-


play. The parking brake will then be set


Brake hold function

If the brake pedal is left released for a

period of about 3 minutes after the sys-

tem has started holding the brake, the

parking brake will be set automatically. In

this case, a warning buzzer sounds and a

message is shown on the multi-informa-

tion display.

To turn the system off while the system is

holding the brake, firmly depress the

brake pedal and press the button again.

The brake hold function may not hold the

vehicle when the vehicle is on a steep

incline. In this situation, it may be neces-

sary for the driver to apply the brakes. A

warning buzzer will sound and the multi-

information display will inform the driver

of this situation. If a warning message is

shown on the multi-information display,

read the message and follow the instruc-


When the parking brake is set automati-

cally while the system is holding the


With the brake pedal depressed, release

the parking brake by operating the parking

brake switch, making sure that the parking

brake indicator light goes off. (


When an inspection at your Lexus

dealer is necessary

When the brake hold standby indicator

(green) does not illuminate even when the

brake hold switch is pressed with the brake

hold system operating conditions met, the

system may be malfunctioning. Have the

vehicle inspected at your Lexus dealer.

If “Brake Hold Fault Depress Brake to

Deactivate Visit Your Dealer” is dis-

played on the multi-information display

The system may be malfunctioning. Have

the vehicle inspected by your Lexus dealer.

Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

If the brake hold operated indicator




When the vehicle is on a steep incline

When using the brake hold system on a

steep incline, exercise caution. The brake

hold function may not hold the vehicle in

such a situation.

When stopped on a slippery road

The system cannot stop the vehicle when

the gripping ability of the tires has been

exceeded. Do not use the system when

stopped on a slippery road.


When parking the vehicle

The brake hold system is not designed

for use when parking the vehicle for a

long period of time. Turning the power

switch off while the system is holding the

brake may release the brake, which

would cause the vehicle to move. When

operating the power switch, depress the

brake pedal, shift the shift lever to P and

set the parking brake.


4-2. Driving procedures

LEXUS NX300h Owners Manu-





: If  equipped





The indicator comes on when the ASC
system is on.
When the dial is turned to the lowest
volume, the ASC system will be turned
off and the indicator will go off.

Operating conditions

When the driving mode select switch is not

in Eco mode or EV drive mode.

Temporary cancelation of the ASC sys-

tem functions

The ASC system may be temporarily can-

celed depending on the driving conditions,

such as when the tires slip due to sudden


ASC (Active Sound Con-


The ASC system is an electronic
sound system that generates
engine sound, conveying the
kinetic situations of the vehicle’s
acceleration and deceleration to
the driver through the speakers
inside the instrument panel.
The vehicle’s response to the
driver’s acceleration behavior and
shift operations are also conveyed
in sound.
When Sport mode is selected, the
sound conveyed to the driver will be

Controlling volume


4-3. Operating the lights and wipers

LEXUS NX300h Owners Manu-


4-3.Operating the lights and wipers

Turning the

 switch turns on the

lights as follows:

Type A


 The side marker, parking, tail,

license plate, instrument panel
lights, and daytime running lights

P.183) turn on.


 The headlights and all the

lights listed above (except daytime
running lights) turn on.


 The headlights, daytime run-

ning lights (

P.183) and all the

lights listed above turn on and off



 The daytime running lights

turn off.

Type B


 The side marker, parking, tail,

license plate, instrument panel
lights, and daytime running lights

P.183) turn on.


 The headlights and all the

lights listed above (except daytime
running lights) turn on.


 The headlights, daytime run-

ning lights (

P.183) and all the

lights listed above turn on and off
automatically (when the power
switch is in ON mode).


 The daytime running lights

turn on. (


Headlight switch

The headlights can be operated
manually or automatically.

Turning on the headlights


4-3. Operating the lights and wipers

LEXUS NX300h Owners Manu-




AUTO mode can be used when

The power switch is in ON mode.

Daytime running light system

The daytime running lights illuminate

using the same lights as the parking lights

and illuminate brighter than the parking


To make your vehicle more visible to

other drivers during daytime driving, the

daytime running lights turn on automati-

cally when all of the following conditions

are met. (The daytime running lights are

not designed for use at night.)

• The hybrid system is started

• The parking brake is released
• The headlight switch is in the



 or “AUTO”




: When the surroundings are bright

The daytime running lights remain on after

they illuminate, even if the parking brake is

set again.

For the U.S.A.: Daytime running lights

can be turned off by operating the switch.

Compared to turning on the headlights,

the daytime running light system offers

greater durability and consumes less

electricity, so it can help improve fuel

If a turn signal light is in use, the daytime

running light, on the same side, is turned

off. For emergency flashers, both are

turned off.

Headlight control sensor

The sensor may not function properly if an

object is placed on the sensor, or anything

that blocks the sensor is affixed to the wind-


Doing so interferes with the sensor detect-

ing the level of ambient light and may cause

the automatic headlight system to malfunc-


Automatic light off system

When the headlights come on: The head-
lights and tail lights turn off 30 seconds
after a door is opened and closed if the
power switch is turned to ACCESSORY
mode or turned off. (The lights turn off
immediately if

 on the key is

pressed after all the doors are locked.)

When only the tail lights come on: The tail

lights turn off automatically if the power

switch is turned to ACCESSORY mode

or turned off and the driver’s door is


To turn the lights on again, turn the power

switch to ON mode, or turn the light switch
off once and then back to



Light reminder buzzer

A buzzer sounds when the power switch is

turned off or turned to ACCESSORY

mode and the driver’s door is opened while

the lights are turned on.

Automatic headlight leveling system (if


The level of the headlights is automatically

adjusted according to the number of pas-

sengers and the loading condition of the

vehicle to ensure that the headlights do not

interfere with other road users.

12-volt battery-saving function

In order to prevent the 12-volt battery of the

vehicle from discharging, if the headlights

and/or tail lights are on when the power

switch is turned off the 12-volt battery sav-

ing function will operate and automatically

turn off all the lights after approximately 20

minutes. When the power switch is turned

to ON mode, the 12-volt battery-saving

function will be disabled.


4-3. Operating the lights and wipers

LEXUS NX300h Owners Manu-


When any of the following are performed,

the 12-volt battery-saving function is can-

celed once and then reactivated. All the

lights will turn off automatically 20 minutes

after the 12-volt battery-saving function has

been reactivated:

When the headlight switch is operated

When a door is opened or closed


Settings (e.g. light sensor sensitivity) can be

changed. (Customizable features:



With the headlights on, push the
lever away from you to turn on the
high beams.

Pull the lever toward you to the center
position to turn the high beams off.


Pull the lever toward you and
release it to flash the high beams

You can flash the high beams with the
headlights on or off.

When the following conditions are met,
while the headlights (low beam) are on,
the cornering lights will additionally
turn on and light up the direction of
movement for the vehicle. This is to
ensure excellent visibility when either
driving at intersections or parking at
 The steering wheel is operated
 The turn signal lever is operated
 The shift lever is in R

Cornering light control

However, when vehicle speed is 25 mph

(40 km/h) or above, the cornering lights

do not turn on.

After the lights remain illuminated for 30

minutes, they automatically turn off.

AFS (Adaptive Front-lighting System)
secures excellent visibility at intersec-
tions and on curves by automatically
adjusting the direction of the light axis
of the headlights according to vehicle
speed and the degree of the tire’s angle
as controlled by steering input.

AFS operates at speeds of 6 mph (10 km/
h) or higher.


To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

Turning on the high beam head-

Cornering lights (if equipped)

AFS (Adaptive Front-lighting
System) (if equipped)


4-3. Operating the lights and wipers

LEXUS NX300h Owners Manu-





Push the lever away from you with
the headlight switch in




Press the Automatic High Beam

The Automatic High Beam indicator will

come on when the headlights are turned

on automatically to indicate that the system

is active.

Operating conditions

The power switch is in ON mode.

High beam automatic turning on or off


When all of the following conditions are ful-

filled, high beam will be automatically

turned on:

Vehicle speed is above approximately 21

mph (34 km/h).

The area ahead of the vehicle is dark.

There are no oncoming or preceding

vehicles with headlights or tail lights

turned on.

There are few streetlights on the road


If any of the following conditions are ful-
filled, high beam will be automatically
turned off:

Vehicle speed drops below approxi-

mately 17 mph (27 km/h).

The area ahead of the vehicle is not dark.

Oncoming or preceding vehicles have

headlights or tail lights turned on.

There are many streetlights on the road


Camera sensor detection information

High beam may not be automatically

turned off in the following situations:

• When oncoming vehicles suddenly

appear from a curve

• When the vehicle is cut in front of by


• When oncoming or preceding vehicles

are hidden from sight due to repeated

Automatic High Beam

The Automatic High Beam uses an
in-vehicle camera sensor to assess
the brightness of streetlights, the
lights of oncoming and preceding
vehicles, etc., and automatically
turns high beam on or off as neces-


Limitations of the Automatic High


Do not rely on the Automatic High

Beam. Always drive safely, taking care to

observe your surroundings and turning

high beam on or off manually if neces-


Activating the Automatic High
Beam system


4-3. Operating the lights and wipers

LEXUS NX300h Owners Manu-


curves, road dividers or roadside trees

High beam may be turned off if an

oncoming vehicle that is using fog lights

without using the headlights is detected.

House lights, street lights, red traffic sig-

nals, and illuminated billboards or signs

may cause the high beam to turn off.

The following factors may affect the

amount of time taken to turn high beam

on or off:

• The brightness of headlights, fog lights,

and tail lights of oncoming and preceding


• The movement and direction of oncom-

ing and preceding vehicles

• When a oncoming or preceding vehicle

only has operational lights on one side

• When a oncoming or preceding vehicle

is a two-wheeled vehicle

• The condition of the road (gradient,

curve, condition of the road surface, etc.)

• The number of passengers and amount of


High beam may be turned on or off when

unexpected by the driver.

In the situations below, the system may

not be able to correctly detect the sur-

rounding brightness levels, and may flash

or expose nearby pedestrians to the high

beam. Therefore, you should consider

turning the high beams on or off manually

rather than relying on the Automatic

High Beam system.

• In bad weather (rain, snow, fog, sand-

storms, etc.)

• The windshield is obscured by fog, mist,

ice, dirt, etc.

• The windshield is cracked or damaged.

• The camera sensor is deformed or dirty.

• The camera sensor temperature is

extremely high.

• Surrounding brightness levels are equal

to those of headlights, tail lights or fog


• Vehicles ahead have headlights or tail

lights that are either switched off, dirty,

are changing color, or are not aimed


• When driving through an area of inter-

mittently changing brightness and dark-


• When frequently and repeatedly driving

ascending/descending roads, or roads

with rough, bumpy or uneven surfaces

(such as stone-paved roads, gravel

tracks, etc.).

• When frequently and repeatedly taking

curves or driving on a winding road.

• There is a highly reflective object ahead

of the vehicle, such as a sign or a mirror.

• The back of a vehicle ahead is highly

reflective, such as a container on a truck.

• The vehicle’s headlights are damaged or


• The vehicle is listing or titling, due to a flat

tire, a trailer being towed, etc.

• The driver believes that the high beam

may be causing problems or distress to

other drivers or pedestrians nearby.


Notes when using the Automatic

High Beam system

Observe the following to ensure that the

Automatic High Beam functions cor-


Do not touch the camera sensor.

Do not subject the camera sensor to a

strong impact.

Do not disassemble the camera sen-


Do not spill liquids onto the camera


Do not apply window tinting or stickers

to the camera sensor or the area of

windshield near the camera sensor.


4-3. Operating the lights and wipers

LEXUS NX300h Owners Manu-




Switching to low beam

Pull the lever to original position.

The Automatic High Beam indicator will
turn off.
Push the lever away from you to activate
the Automatic High Beam system again.

Switching to high beam

Press the Automatic High Beam

The Automatic High Beam indicator will
turn off and the high beam indicator will
turn on.
Press the switch to activate the Automatic

High Beam system again.


Do not place items on the dashboard.

There is a possibility that the camera

sensor will mistake items reflected in

the windshield for streetlights, the

headlights of other vehicles, etc.

Do not install a parking tag or any

other accessories near or around the

camera sensor.

Do not overload the vehicle.

Do not modify the vehicle.

Do not replace windshield with non-

genuine windshield.

Contact your Lexus dealer.

Changing to manual control








Content   ..  9  10  11  12   ..
