Harley Davidson competition Sportster XLRTT and KR-KRTT Models 1958-1968. Parts catalog (september 1967)

ISSUED: SEPTEMBER 1967 No. 99451-68R

ENGINE MOUNTINGS, HEADS AND CYLINDERS
4666R BOLT, cylinder head, short (6)................................... 52 to * - KR, KRTT

4718R HEAD BOLT. 7/16-24 x 3-5/16 (4)................................ 52 to * - KR, KRTT

16045—67R ENGINE ASSEMBLY, complete......................................................................52 to * - KR, KRTT

16046—67R ENGINE ASSEMBLY, complete......................................................................58 to * - XLRTT

16201-58A REAR MOUNTING, engine....................................... 52 to * - KR, KRTT, XLRTT

16212-59R FRONT MOUNTING PLATE (aluminum) (2)......................... 52 to * - KR, KRTT, XLRTT

16230-59R SPACER, front engine mounting plate (aluminum) (2)................. 52 to * — KR, KRTT, XLRTT

16471-59R FRONT CYLINDER ............................................. 52 to * - KR, KRTT

16473—59R REAR CYLINDER............................................... 52 to * - KR, KRTT

16560-66R FRONT CYLINDER..........................................................................................58 to * - XLRTT

16580-66R REAR CYLINDER ............................................................................................58 to *-XLRTT

16682-66R FRONT CYLINDER HEAD....................................... 58 to‘-XLRTT

16684—66R REAR CYLINDER HEAD......................................... 58 to * - XLRTT

16690-60R FRONT CYLINDER HEAD, ................................... 52 to * - KR, KRTT

16693—60R REAR CYLINDER HEAD, ..................................... 52 to * - KR, KRTT

16822-39R WASHER, cylinder head bolt (8)....................................................................52 to * - KR, KRTT

16835-55R NUT, cylinder base (2).......................................... 52 to * - KR, KRTT

16855-52R BRACKET, upper motor support, steel ........................................................52 to * - KR, KRTT

16860-59R SPACER, head bolt (aluminum) (4) ................................ 52 to * - KR, KRTT

16775-52R BASE GASKET (pkg. 10) ................................................................................52 to * - KR, KRTT

17027-52R GASKET SET, motor........................................................................................52 to ♦ - KR, KRTT

///////////////////////////////////////
