AIR CONDITIONING
05 - Units and Parts Checks





SG05-2

TC070-15-01H


Blower relay

Check continuities Step 1 and 2.


Continuity Step 1: OK / NG



Continuity Step 2: OK / NG



Blower motor

Inspect by directly applying battery voltage.


Operation: OK / NG


Resistor

Measure the resistances.

A – D:                       ohm, Condition OK / NG



A – B:                       ohm, Condition OK / NG



A – C:                       ohm, Condition OK / NG



Air intake actuator

Check the air intake actuator for its function by directly applying the battery voltage.



C (B+) – G (Ground): Operation OK / NG



G (B+) – E (Ground): Operation OK / NG



Evaporator temperature sensor

Measure the resistance between the evaporator temperature sensor terminals.


Resistance:                  ohm at               ºC



Resistance:                  ohm at               ºC



A/C relay

Check continuities Step 1 and 2.


Continuity Step 1: OK / NG, Continuity Step 2: OK / NG



AIR CONDITIONING
05 - Units and Parts Checks





SG05-3

TC070-15-01H


Magnetic clutch

Connect battery positive voltage to magnetic clutch terminal A and the A/C
compressor body to ground.



Operation: OK / NG





Refrigerant pressure switch

1. Install the manifold gauge.
2. Disconnect the refrigerant pressure switch connector.
3. Verify the high-pressure side reading of the manifold gauge and continuity

between the refrigerant pressure switch terminals.




Continuity: OK / NG at               psi




Fan switch

Remove the climate control unit. Verify that the continuity between the fan switch
terminals is as indicated in the table.


Continuity (switch position OFF): OK / NG



Continuity (switch position 1): OK / NG



Continuity (switch position 2): OK / NG



Continuity (switch position 3): OK / NG



Continuity (switch position 4): OK / NG





Note

Refer to the workshop manual to remove the fan switch.


AIR CONDITIONING
05 - Units and Parts Checks





SG05-4

TC070-15-01H


Climate control unit inspection


Terminal Signal

name

Connected

to

Measurement

condition

Voltage

(V)

Remark



B+

ROOM 15 A
fuse

Under any condition





IG SW ON







IG2

A/C 10 A fuse


IG SW LOCK








GND

Body ground

Under any condition







Sensor GND

Evaporator
temperature
sensor

Under any condition





A/C switch ON, fan
switch at 1st







A/C PJB



A/C switch OFF







Evaporator
temperature
sensor input


Evaporator
temperature
sensor


Compared with
temperature detected
by evaporator
temperature sensor





Rear window
defroster
switch ON








Rear
window
defroster
switch
indicator
light

PJB

Rear window
defroster
switch OFF





Rear window
defroster
switch ON





Rear
window
defroster
switch


PJB


Rear window
defroster
switch OFF





FAN signal

FAN switch ON









Fan switch


FAN switch OFF






Headlight switch OFF



TNS signal

Panel light
control
switch

Headlight switch






Headlight switch OFF



TNS signal

PJB

Headlight switch ON





AIR CONDITIONING
05 - Units and Parts Checks





SG05-5

TC070-15-01H


Instructor Sign-Off:
Now that you have completed this activity, you should be able to:



Perform checks for A/C components

This skill will help you evaluate protection devices for correct operation.

Instructor’s initials:
