TC001-18-01H

INTRODUCTION TO M-MDS
14 - PATS Key programming







Activity 14- Page 13

Activity 14
(Continued)




Click the X in the upper right to close IDS





Click the tick in the popup to close these screens



Instructor Sign Off: ________________________


TC001-18-01H

INTRODUCTION TO M-MDS
15 - Updating IDS







Activity 15- Page 1

Activity 15:  Updating IDS

Upon completing this activity you will be able to download from the Internet:


•   Manual Calibration Updates–

•   Load all DIF (*), Patches (*)

•   Tech Tips

•   Calibration file updates through Internet.



*

DIF: Small software to update diagnostic database for IDS

*Patch: Small software to modify or add functions to the IDS



(Note: This is only for updates between the bi-monthly DVD updates.)



What you need to complete this activity:


•

Mazda-approved laptop or PC with PDS / PFM installed

•

High-speed internet access



Procedure:

1.  Click the IDS icon on the desktop.





2. Click the

 System Page tab in the upper left corner.
























TC001-18-01H

INTRODUCTION TO M-MDS
15 - Updating IDS







Activity 15- Page 2

Activity 15
(Continued)

3. Click the

 information icon at the bottom.




















4.  Click the plus sign by Dealer Information to expand this item.  The plus sign turns

into a minus sign when you click on it again.  Verify your dealer information is
correct.  If it is not correct, you can correct it from the tool box page.



TC001-18-01H

INTRODUCTION TO M-MDS
15 - Updating IDS







Activity 15- Page 3

Activity 15
(Continued)


5. Click the

 Swiss army knife icon at the bottom, then select Network

Options and click tick.























6. Click the Reset LAN button at the bottom.
