Mazda engine L8, LF, L3. Manual - part 2





HOW TO USE THIS MANUAL

GI–3

GI

4.

End Of Sie

SYMBOLS

A6E201000001E03

There are eight symbols indicating oil, grease, fluids, sealant, and SST or equivalent use. These symbols show
application points or use of these materials during service.

XME2010010

Symbol

Meaning

Kind

Apply oil

New appropriate
engine oil or gear
oil

Apply brake fluid

New appropriate
brake fluid

GI–4

HOW TO USE THIS MANUAL

End Of Sie

ADVISORY MESSAGES

A6E201000001E04

You'll find several WarningsCautionsNotesSpecifications and Upper and Lower Limits in this manual.

Warning

A Warning indicates a situation in which serious injury or death could result if the warning is ignored.

Caution

A Caution indicates a situation in which damage to the vehicle or parts could result if the caution is ignored.

Note

A Note provides added information that will help you to complete a particular procedure.

Specification

The values indicate the allowable range when performing inspections or adjustments.

Upper and lower limits

The values indicate the upper and lower limits that must not be exceeded when performing inspections or
adjustments.

End Of Sie

Apply automatic
transaxle/
transmission fluid

New appropriate
automatic
transaxle/
transmission fluid

Apply grease

Appropriate
grease

Apply sealant

Appropriate
sealant

Apply petroleum
jelly

Appropriate
petroleum jelly

Replace part

O-ring, gasket,
etc.

Use SST or
equivalent

Appropriate tools

Symbol

Meaning

Kind

UNITS

GI–5

GI

UNITS

A6E201200002E01

Conversion to SI Units (Système International d'Unités)

All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted
from these values.

Rounding Off

Converted values are rounded off to the same number of places as the SI unit value. For example, if the SI unit
value is 17.2 and the value after conversion is 37.84, the converted value will be rounded off to 37.8.

Upper and Lower Limits

When the data indicates upper and lower limits, the converted values are rounded down if the SI unit value is
an upper limit and rounded up if the SI unit value is a lower limit. Therefore, converted values for the same SI
unit value may differ after conversion. For example, consider 2.7 kgf/cm

2

 in the following specifications:

210—260 kPa {2.1—2.7 kgf/cm

2

, 30—38 psi}

270—310 kPa {2.7—3.2 kgf/cm

2

, 39—45 psi}

The actual converted values for 2.7 kgf/cm

2

 are 264 kPa and 38.4 psi. In the first specification, 2.7 is used as

an upper limit, so the converted values are rounded down to 260 and 38. In the second specification, 2.7 is
used as a lower limit, so the converted values are rounded up to 270 and 39.

End Of Sie

UNITS

Electrical current

A (ampere)

Electric power

W (watt)

Electric resistance

ohm

Electric voltage

V (volt)

Length

mm (millimeter)

in (inch)

Negative pressure

kPa (kilo pascal)

mmHg (millimeters of mercury)

inHg (inches of mercury)

Positive pressure

kPa (kilo pascal)

kgf/cm

2

 (kilogram force per square

centimeter)

psi (pounds per square inch)

Torque

N·m (Newton meter)

kgf·m (kilogram force meter)

kgf·cm (kilogram force centimeter)

ft·lbf (foot pound force)

in·lbf (inch pound force)

Volume

L (liter)

US qt (U.S. quart)

Imp qt (Imperial quart)

ml (milliliter)

cc (cubic centimeter)

cu in (cubic inch)

fl oz (fluid ounce)

Weight

g (gram)

oz (ounce)

GI–6

FUNDAMENTAL PROCEDURES

PREPARATION OF TOOLS AND MEASURING EQUIPMENT

A6E201400004E02

Be sure that all necessary tools and measuring
equipment are available before starting any work.

End Of Sie

SPECIAL SERVICE TOOLS

A6E201400004E03

Use special service tools or equivalent when they
are required.

End Of Sie

DISASSEMBLY

A6E201400004E07

If the disassembly procedure is complex,
requiring many parts to be disassembled, all parts
should be marked in a place that will not affect
their performance or external appearance and
identified so that reassembly can be performed
easily and efficiently.

End Of Sie

FUNDAMENTAL PROCEDURES

X3U000WAH

X3U000WAJ

X3U000WAL
