Mazda Automatic Transaxle JA5A-EL. Manual - part 2





HOW TO USE THIS MANUAL

GI–3

GI

3. Procedure steps are numbered and the part that is the main point of the procedure is shown in the illustration

with the corresponding number. Occasionally, there are important points or additional information concerning a

procedure. Refer to this information when servicing the related part.

End Of Sie

XME2010010

GI–4

HOW TO USE THIS MANUAL

SYMBOLS

AME201000001A03

• There are eight symbols indicating oil, grease, fluids, sealant, and the use of SST or equivalent. These symbols

show application points or use of these materials during service.

End Of Sie

ADVISORY MESSAGES

AME201000001A04

• You will find several Warnings, Cautions, Notes, Specifications and Upper and Lower Limits in this

manual.

Warning

• A Warning indicates a situation in which serious injury or death could result if the warning is ignored.

Caution

• A Caution indicates a situation in which damage to the vehicle or parts could result if the caution is

ignored.

Note

• A Note provides added information that will help you to complete a particular procedure.

Specifications

• The values indicate the allowable range when performing inspections or adjustments.

Upper and Lower Limits

• The values indicate the upper and lower limits that must not be exceeded when performing inspections or

adjustments.

End Of Sie

Symbol

Meaning

Kind

Apply oil

New appropriate engine oil or gear oil

Apply brake fluid

New appropriate brake fluid

Apply automatic transaxle/transmission fluid New appropriate automatic transaxle/transmission

fluid

Apply grease

Appropriate grease

Apply sealant

Appropriate sealant

Apply petroleum jelly

Appropriate petroleum jelly

Replace part

O-ring, gasket, etc.

Use SST or equivalent

Appropriate tools

UNITS

GI–5

GI

UNITS TABLE

AME201200002A01

Conversion to SI Units (Système International d'Unités)

• All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted

from these values.

Rounding Off

• Converted values are rounded off to the same number of places as the SI unit value. For example, if the SI unit

value is 17.2 and the value after conversion is 37.84, the converted value will be rounded off to 37.8.

Upper and Lower Limits

• When the data indicates upper and lower limits, the converted values are rounded down if the SI unit value is

an upper limit and rounded up if the SI unit value is a lower limit. Therefore, converted values for the same SI

unit value may differ after conversion. For example, consider 2.7 kgf/cm

2

 in the following specifications:

210—260 kPa {2.1—2.7 kgf/cm

2

, 30—38 psi}

270—310 kPa {2.7—3.2 kgf/cm

2

, 39—45 psi}

• The actual converted values for 2.7 kgf/cm

2

 are 265 kPa and 38.4 psi. In the first specification, 2.7 is used as

an upper limit, so the converted values are rounded down to 260 and 38. In the second specification, 2.7 is

used as a lower limit, so the converted values are rounded up to 270 and 39.

End Of Sie

UNITS

Electrical current

A (ampere)

Electric power

W (watt)

Electric resistance

ohm

Electric voltage

V (volt)

Length

mm (millimeter)
in (inch)

Negative pressure

kPa (kilo pascal)
mmHg (millimeters of mercury)
inHg (inches of mercury)

Number of

revolutions

rpm (revolutions per minute)

Positive pressure

kPa (kilo pascal)
kgf/cm

2

 (kilogram force per square

centimeter)
psi (pounds per square inch)

Torque

N·m (Newton meter)
kgf·m (kilogram force meter)
kgf·cm (kilogram force centimeter)
ft·lbf (foot pound force)
in·lbf (inch pound force)

Volume

L (liter)
US qt (U.S. quart)
imp qt (Imperial quart)
ml (milliliter)
cc (cubic centimeter)
cu in (cubic inch)
fl oz (fluid ounce)

Weight

N (Newton)
g (gram)
oz (ounce)

GI–6

FUNDAMENTAL PROCEDURES

PREPARATION OF TOOLS AND MEASURING EQUIPMENT

AME201400004A01

• Be sure that all necessary tools and measuring

equipment are available before starting any work.

End Of Sie

SPECIAL SERVICE TOOLS

AME201400004A02

• Use special service tools or equivalent when they

are required.

End Of Sie

DISASSEMBLY

AME201400004A03

• If the disassembly procedure is complex,

requiring many parts to be disassembled, all parts

should be marked in a place that will not affect

their performance or external appearance and

identified so that reassembly can be performed

easily and efficiently.

End Of Sie

INSPECTION DURING REMOVAL, DISASSEMBLY

AME201400004A04

• When removed, each part should be carefully

inspected for malfunction, deformation, damage,

and other problems.

End Of Sie

FUNDAMENTAL PROCEDURES

WGIWXX0023E

WGIWXX0024E

WGIWXX0027E

WGIWXX0028E
