Mazda CX-9 Grand Touring. Manual - part 429





Fig. 55: Refrigerant Pressure Switch Terminals Continuity Chart (3 Of 3)
Courtesy of MAZDA MOTORS CORP.

FRONT CLIMATE CONTROL UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.

2. Remove the following parts:

1. Decoration panel (See DECORATION PANEL REMOVAL/INSTALLATION .)

2. Front console box mat (See FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION .)

3. Indicator panel (See INDICATOR PANEL REMOVAL/INSTALLATION .)

4. Front console box (See FRONT CONSOLE BOX REMOVAL/INSTALLATION .)

5. Center panel (See CENTER PANEL REMOVAL/INSTALLATION .)

3. Remove the screws.

4. Remove the front climate control unit.

5. Install in the reverse order of removal.

Fig. 56: Identifying Front Climate Control Unit & Screws
Courtesy of MAZDA MOTORS CORP.

FRONT CLIMATE CONTROL UNIT INSPECTION



2008 Mazda CX-9 Grand Touring

2008 HVAC Control System (HVAC) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:12:36 AM

Page 34

© 2005 Mitchell Repair Information Company, LLC.

1. Connect the front climate control unit connector.

2. Turn the ignition switch to the ON position.

3. Connect the negative (-) lead of the tester to body ground.

4. By inserting the positive (+) lead of the tester into each front climate control unit terminal, measure the

voltage according to the terminal voltage table.

If there is any malfunction, inspect the parts under "Inspection item (s)".

If the parts under "Inspection item (s)" are found to be normal, replace the front climate
control unit.

TERMINAL VOLTAGE TABLE (REFERENCE)

Fig. 57: Identifying Front Climate Control Unit Terminal
Courtesy of MAZDA MOTORS CORP.

TERMINAL VOLTAGE REFERENCE

Terminal Signal name

Connected to

Measurement
condition

Voltage

(V)

Inspection item (s)

1A

Motor
operation

Driver-side front
air mix actuator

Temperature control
dial (driver side):
Moving towards
COLD

1.0 or

less

Wiring harness:
continuity, short circuit
(Front climate control
unit-driver-side front
air mix actuator: 1A-G,
1F-F)

Driver-side front air
mix actuator

Temperature control
dial (driver side):
Moving towards
HOT

B+

1B

B+

BCM

Under any
condition

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-BCM: 1B-5H)

BCM

1C

Motor
operation

Passenger-side
front air mix
actuator

Temperature control
dial (passenger
side): Moving
towards COLD

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-passenger-side
front air mix actuator:

Temperature control



2008 Mazda CX-9 Grand Touring

2008 HVAC Control System (HVAC) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:12:36 AM

Page 35

© 2005 Mitchell Repair Information Company, LLC.

dial (passenger
side): Moving
towards HOT

1.0 or
less

1C-G, 1E-F)

Passenger-side front
air mix actuator

1D

Seat warmer
(LH) on/off

Seat warmer relay

Seat warmer switch
off

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-seat warmer (LH)
relay (relay block):
1D-A)

Seat warmer (LH)
relay

Seat warmer switch
on

1.0 or
less

1E

Motor
operation

Passenger-side
front air mix
actuator

Temperature control
dial (passenger
side): Moving
towards COLD

1.0 or

less

Wiring harness:
continuity, short circuit
(Front climate control
unit-passenger-side
front air mix actuator:
1C-G, 1E-F)

Passenger-side front
air mix actuator

Temperature control
dial (passenger
side): Moving
towards HOT

B+

1F

Motor
operation

Driver-side front
air mix actuator

Temperature control
dial (driver side):
Moving towards
COLD

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-driver-side front
air mix actuator: 1A-G,
1F-F)

Driver-side front air
mix actuator

Temperature control
dial (driver-side):
Moving towards
HOT

1.0 or
less

1G

Motor
operation

Rear air mix
actuator

Temperature control
dial (rear side):
Moving towards
COLD

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-Rear air mix
actuator: 1G-F, 1I-G)

Rear air mix actuator

Temperature control
dial (rear side):
Moving towards
HOT

1.0 or
less

1H

Motor
operation

Front airflow
mode actuator

Defroster switch on

1.0 or

less

Wiring harness:
continuity, short circuit
(Front climate control
unit-front airflow
mode actuator: 1H-G,
1J-F)

Front airflow mode
actuator

Mode switch:
Moving towards
VENT

B+

Temperature control



2008 Mazda CX-9 Grand Touring

2008 HVAC Control System (HVAC) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:12:36 AM

Page 36

© 2005 Mitchell Repair Information Company, LLC.

1I

Motor
operation

Rear air mix
actuator

dial (rear side):
Moving towards
COLD

1.0 or

less

Wiring harness:
continuity, short circuit
(Front climate control
unit-Rear air mix
actuator: 1G-F, 1I-G)

Rear air mix actuator

Temperature control
dial (rear side):
Moving towards
HOT

B+

1J

Motor
operation

Front airflow
mode actuator

Defroster switch on

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-front airflow
mode actuator: 1H-G,
U-F)

Front airflow mode
actuator

Mode switch:
Moving towards
VENT

1.0 or
less

1K

Seat warmer
(RH) on/off

Seat warmer relay

Seat warmer switch
off

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-seat warmer (RH)
relay (main fuse
block): 1K-A)

Seat warmer (RH)
relay

Seat warmer switch
on

1.0 or
less

1L

Motor
operation

Rear airflow mode
actuator

Temperature control
dial (rear side):
Moving towards
HOT

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-Rear airflow mode
actuator: 1L-G, 1N-F)

Rear airflow mode
actuator

Temperature control
dial (rear side):
Moving towards
COLD

1.0 or
less

1M

Motor
operation

Air intake actuator

REC switch:
Switched to
RECIRCULATE

B+

Wiring harness:
continuity, short circuit
(Front climate control
unit-air intake actuator:
1M-A, 10-C)

Air intake actuator

REC switch:
Switched to FRESH

1.0 or
less

1N

Motor
operation

Rear airflow mode
actuator

Temperature control
dial (rear side):
Moving towards
HOT

1.0 or

less

Wiring harness:
continuity, short circuit
(Front climate control
unit-Rear airflow mode
actuator: 1L-G, 1N-F)

Rear airflow mode
actuator

Temperature control
dial (rear side):
Moving towards

B+



2008 Mazda CX-9 Grand Touring

2008 HVAC Control System (HVAC) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:12:36 AM

Page 37

© 2005 Mitchell Repair Information Company, LLC.
