1. Remove the rear tire (RH). 2. Remove the spare tire. 3. Remove the main silencer (LH). (See EXHAUST SYSTEM REMOVAL/INSTALLATION [MZI- 3.7] .) 4. Remove the main silencer insulator (LH). 5. To lower the rear crossmember, perform the following procedure: 1. Set the rear ABS wheel-speed sensor out of the way. (See REAR ABS WHEEL-SPEED SENSOR REMOVAL/INSTALLATION [2WD] .) 2. Rear coil spring (See REAR COIL SPRING REMOVAL/INSTALLATION .) 3. Lowered the rear crossmember. (See REAR CROSSMEMBER REMOVAL/INSTALLATION [2WD] .) 6. Remove the fuel-filler pipe. AWD 1. Level the vehicle. 2. Complete the "BEFORE SERVICE PRECAUTION". (See BEFORE SERVICE PRECAUTION [MZI- 3.7].) 3. Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [MZI-3.7] .) 4. Remove the engine cover. (See ENGINE COVER REMOVAL/INSTALLATION [MZI-3.7] .) 5. Remove the fuel line schrader valve cap. 6. Connect a long hose to the disconnected schrader valve cap and drain the fuel into a container used for collecting gasoline. 7. Start the fuel pump using the following procedure. Fig. 16: Identifying Schrader Valve Cap & Fuel Distributor Using M-MDS
2008 Mazda CX-9 Grand Touring 2008 ENGINE Fuel System (MZI-3.7) - Mazda CX-9
