Mazda CX-9 Grand Touring. Manual - part 236

2



Verify related Service Bulletins and/or
on-line repair information availability.



Is any related Service Bulletins
available?

Yes



If the vehicle is not repaired, go to the
next step.

No

Go to the next step.

3

INSPECT TP SENSOR CONNECTOR
FOR POOR CONNECTION



Turn the ignition switch off.



Disconnect the throttle body connector.



Inspect for poor connection (such as
damaged/pulled-out pins, corrosion).



Are there any malfunction?

Yes

Repair or replace suspected part, then go to
Step 9.

No

Go to the next step.

4

INSPECT TP SENSOR CIRCUIT FOR
SHORT TO GROUND



Turn the ignition switch to the ON
position (Engine off).



Inspect for continuity between TP sensor
terminal F (wiring harness-side) and
body ground



Is there continuity?

Yes

Repair or replace suspected part, then go to
Step 9.

No

Go to the next step.

5

INSPECT PCM CONNECTOR FOR POOR
CONNECTION



Turn the ignition switch off.



Disconnect the PCM connector.



Inspect for poor connection (such as
damaged/pulled-out pins, corrosion).



Are there any malfunction?

Yes

Repair or replace suspected part, then go to
Step 9.

No

Go to the next step.

6

INSPECT TP SIGNAL CIRCUIT FOR
OPEN CIRCUIT



Inspect for continuity between throttle
body connector terminal F (wiring
harness-side) and PCM terminal 2Z
(wiring harness-side).



Is there continuity?

Yes Go to the next step.

No

Repair or replace suspected part, then go to

Step 9.

7

INSPECT TP GROUND CIRCUIT FOR
OPEN CIRCUIT



Turn the ignition switch off.



Verify the continuity between TP sensor
terminal E (wiring harness-side) and

Yes Go to the next step.

Repair or replace suspected part, then go to



2008 Mazda CX-9 Grand Touring

2008 ENGINE PERFORMANCE On-Board Diagnostic (MZI-3.7) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:08:35 AM

Page 77

© 2005 Mitchell Repair Information Company, LLC.

DTC P0123 [MZI-3.7]

DTC P0123 (MZI-3.7) DETECTION CONDITIONS AND POSSIBLE CAUSES

PCM terminal 2AH (wiring harness-
side).



Is the continuity?

No

Step 9.

8

INSPECT TP SENSOR NO.1



Inspect the TP sensor No.1. (See
THROTTLE POSITION (TP)
SENSOR INSPECTION [MZI-3.7] .)



Is there any malfunction?

Yes

Replace the throttle body, then go to the next
step.

No

Go to the next step.

9

VERIFY TROUBLESHOOTING OF DTC
P0122 HAS BEEN COMPLETED



Make sure to reconnect all disconnected
connectors.



Clear the DTC from the PCM memory
using the M-MDS.



Start the engine.



Perform the "KOEO/KOER self-test".
(See KOEO/KOER SELF TEST [MZI-
3.7].)



Is same DTC present?

Yes

Replace the PCM, then go to the next step.
(See PCM REMOVAL/INSTALLATION
[MZI-3.7] .)

No

Go to the next step.

10

VERIFY AFTER REPAIR PROCEDURE



Perform the "AFTER REPAIR
PROCEDURE". (See AFTER REPAIR
PROCEDURE [MZI-3.7].)



Are any DTCs present?

Yes

Go to the applicable DTC inspection. (See
DTC TABLE [MZI-3.7].)

No

Troubleshooting completed.

DTC P0123

TP sensor No.1 circuit high input

DETECTION

CONDITION



The TP sensor No.1 circuit was flagged as a concern by the PCM indicating a
high voltage.

POSSIBLE CAUSE



TP sensor No.1 malfunction



Connector or terminal malfunction



Short to constant voltage supply circuit between throttle body terminal F and
PCM terminal 2Z



TP sensor signal circuits are shorted each other
