Mazda CX-9 Grand Touring. Manual - part 182

Fig. 36: Identifying Brake Pipe & Torque Specifications
Courtesy of MAZDA MOTORS CORP.

TCS OFF SWITCH REMOVAL/INSTALLATION

1. Remove the dashboard under cover (LH). (See DASHBOARD REMOVAL/INSTALLATION .)

2. Remove the hood release lever. (See HOOD LATCH AND RELEASE LEVER

REMOVAL/INSTALLATION .)

3. Remove in the order indicated in the table.

Fig. 37: Identifying TCS OFF Switch & TCS OFF Switch Connector
Courtesy of MAZDA MOTORS CORP.

4. Install in the reverse order of removal.

TCS OFF SWITCH REMOVAL NOTE

1. Access the TCS OFF switch from behind of the dashboard, and squeeze the tabs of the switch.

2. Remove the TCS OFF switch from the dashboard.

TCS OFF SWITCH INSPECTION

1. Remove the TCS OFF switch. (See TCS OFF SWITCH REMOVAL/INSTALLATION.)

2. Verify that the continuity is as indicated in the table.

2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9

Microsoft

Sunday, November 15, 2009 9:40:24 AM

Page 32



If not as indicated in the table, replace the TCS OFF switch.

Fig. 38: Connector Terminal Reference
Courtesy of MAZDA MOTORS CORP.

Fig. 39: Identifying TCS OFF Switch Connector Terminal
Courtesy of MAZDA MOTORS CORP.

2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9

Microsoft

Sunday, November 15, 2009 9:40:24 AM

Page 33

2008 MAZDA

CX-9

BUZZERS, RELAYS & TIMERS

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

CONTROL UNITS LOCATION

Component

Location

A/C Relay

In main fuse block.

BACK-UP LIGHT Relay

In main fuse block.

COOLING FAN Relay No. 1

In main fuse block.

COOLING FAN Relay No. 2

In main fuse block.

FAN Relay

In main fuse block.

FRONT BLOWER Relay

In main fuse block.

FRONT FOG LIGHT Relay (2)

In main fuse block.

FUEL PUMP Relay

In main fuse block.

H/L HI Relay

In main fuse block.

H/L LOW Relay

In main fuse block.

HORN Relay

In main fuse block.

Keyless Beeper

Left rear of engine compartment.

MAIN Relay No. 1

In main fuse block.

MAIN Relay No. 2

In main fuse block.

PLG Buzzer

Right side of tailgate.

REAR BLOWER Relay

In main fuse block.

REAR WINDOW DEFROSTER Relay

In main fuse block.

SEAT WARMER LH Relay

In main fuse block.

SEAT WARMER RH Relay

In main fuse block.

STARTER Relay

In main fuse block.

TNS Relay

In main fuse block.

Component

Location

Fuse Block

Behind right side of dash. See Fig. 14.

Fuse & Relay Box

Center front of engine compartment. See Fig. 8.

Main Fuse Block

Left rear of engine compartment. See Fig. 4.

2008 Mazda CX-9 Grand Touring

2008 MAZDA CX-9

2008 Mazda CX-9 Grand Touring

2008 MAZDA CX-9

Microsoft

Sunday, November 15, 2009 9:55:42 AM

Page 1

Microsoft

Sunday, November 15, 2009 9:55:46 AM

Page 1

MOTORS

MOTORS LOCATION

Component

Location

Auto Light-Off Control Module

Behind left side of dash. See Fig. 27.

Auto Light/Wiper Control Module

Behind left side of dash. See Fig. 27.

AWD Control Module

Behind left end of dash. See Fig. 37.

BCM

Behind left kick panel. See Fig. 40.

Car-Navigation Unit

Right rear of luggage compartment. See Fig. 51.

DSC/RSC HU/CM

Left rear corner of engine compartment. See Fig. 5.

Fan Control Module No. 1

Behind left cooling fan assembly.

Fan Control Module No. 2

Behind right cooling fan assembly.

Hands-Free Telephone Unit

Behind right side of dash. See Fig. 16.

Keyless Control Module

Behind left side of dash. See Fig. 28.

Keyless Receiver

Behind left side of dash. See Fig. 25.

PCM

Left rear corner of engine compartment. See Fig. 7.

PLG Control Module

Left side of luggage compartment. See Fig. 64.

Position Memory Control Module

Under driver's seat. See Fig. 44.

PVC Valve Heater Control

Center rear of engine compartment.

RES Unit

Center of roof. See Fig. 53.

SAS Control Module

Under front of center console. See Fig. 20.

Seat Weight Sensor Control Module

Under front passenger's seat. See Fig. 46.

TCM

Left front of engine compartment. See Fig. 2.

Component

Location

Air Intake Actuator

Behind right side of dash.

Closer Motor

Lower center of liftgate.

Cooling Fan Motor No. 1

Left front of engine compartment.

Cooling Fan Motor No. 2

Right front of engine compartment.

Door Lock Actuator (Left/Right Front)

At rear of respective front door.

Door Lock Actuator (Left/Right Rear)

At rear of respective rear door.

Driver Side Front Air Mix Actuator

Left side of HVAC unit.

Front Airflow Mode Actuator

Top left side of HVAC unit.

Front Blower Motor

Under right side of dash.

Fuel Pump Unit

Under rear seat, on fuel tank.

Headlight Leveling Actuator (Left/Right)

In respective headlight assembly.

Liftgate Latch & Lock Actuator

Lower center of liftgate.

Passenger Side Front Air Mix Actuator

Right side of HVAC unit.

PLG Drive Unit

Left side of luggage compartment.

Power Window Motor (Left/Right Front)

In respective front door.

Power Window Motor (Left/Right Rear)

In respective rear door.

2008 Mazda CX-9 Grand Touring

2008 MAZDA CX-9

Microsoft

Sunday, November 15, 2009 9:55:42 AM

Page 2
