4. Remove the rear scuff plate inner. (See REAR SCUFF PLATE REMOVAL/INSTALLATION .)

5. Remove the third-row seat belt lower anchor installation bolt. (See THIRD-ROW SEAT BELT

REMOVAL/INSTALLATION .)

6. Remove the trunk side trim. (See TRUNK SIDE TRIM REMOVAL/INSTALLATION .)

7. Remove in the order indicated in the table.

8. Install in the reverse order of removal.

Fig. 19: Identifying Rear ABS Wheel Speed Sensor Connector, Rear ABS Wheel Speed Sensor, Bolt
& Torque Specifications
Courtesy of MAZDA MOTORS CORP.

REAR ABS WHEEL-SPEED SENSOR REMOVAL/INSTALLATION [AWD]

1. Remove the trunk box. (See TRUNK BOX REMOVAL/INSTALLATION .)

2. Remove the seat side box. (See SEAT SIDE BOX REMOVAL/INSTALLATION .)

3. Remove the third-row seat. (See THIRD-ROW SEAT REMOVAL/INSTALLATION .)

4. Remove the rear scuff plate inner. (See REAR SCUFF PLATE REMOVAL/INSTALLATION .)

5. Remove the third-row seat belt lower anchor installation bolt. (See THIRD-ROW SEAT BELT

REMOVAL/INSTALLATION .)

6. Remove the trunk side trim. (See TRUNK SIDE TRIM REMOVAL/INSTALLATION .)

7. Remove in the order indicated in the table.



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 20

© 2005 Mitchell Repair Information Company, LLC.

Fig. 20: Identifying Rear ABS Wheel Speed Sensor Connector, Rear ABS Wheel Speed Sensor, Bolt
& Torque Specifications
Courtesy of MAZDA MOTORS CORP.

8. Install in the reverse order of removal.

REAR ABS WHEEL-SPEED SENSOR INSPECTION [2WD]

INSTALLATION VISUAL INSPECTION

1. Inspect the following items:



If there is any malfunction, replace the applicable part.

1. Excessive play of the ABS wheel-speed sensor

2. Deformation of the ABS wheel-speed sensor

CLEARANCE INSPECTION

1. Remove the rear ABS wheel-speed sensor.

2. Measure the distance between the rear ABS wheel-speed sensor installation surface and the ABS sensor

rotor. This is dimension A.

3. Calculate the clearance between the front ABS wheel-speed sensor and the ABS sensor rotor using the

following formula:

Clearance (mm {in}) = A-15.0 {0.60 in}

4. Verify that the clearance between the ABS sensor rotor and the rear ABS wheel-speed sensor is as

indicated below.



If there is any malfunction, replace it.

Clearance



0.3-1.1 mm {0.012-0.043 in}

Fig. 21: Identifying Distance Between Rear ABS Wheel-Speed Sensor & ABS Sensor Rotor



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 21

© 2005 Mitchell Repair Information Company, LLC.

Courtesy of MAZDA MOTORS CORP.

SENSOR OUTPUT VALUE INSPECTION

1. Turn the ignition switch off.

2. Connect the M-MDS to the DLC-2.

3. After the vehicle is identified, select the following items from the initialization screen of the M-MDS.



When using the IDS (laptop PC)

1. Select "DataLogger".

2. Select "Modules".

3. Select "ABS".



When using the PDS (Pocket PC)

1. Select "Module Tests".

2. Select "ABS".

3. Select "DataLogger".

Fig. 22: Connecting M-MDS To DLC-2
Courtesy of MAZDA MOTORS CORP.

4. Select the following PIDs using the M-MDS:



WSPD_LR

(LR ABS wheel-speed sensor)



WSPD_RR

(RR ABS wheel-speed sensor)

5. Start the engine and drive the vehicle.

6. Verify that the display of the M-MDS shows the same value as the speedometer.



If there is any malfunction, replace the rear ABS wheel-speed sensor.

REAR ABS WHEEL-SPEED SENSOR INSPECTION [AWD]



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 22

© 2005 Mitchell Repair Information Company, LLC.

INSTALLATION VISUAL INSPECTION

1. Inspect the following items:



If there is any malfunction, replace the applicable part.

1. Excessive play of the ABS wheel-speed sensor

2. Deformation of the ABS wheel-speed sensor

3. Deformation or damage of the ABS sensor rotor

CLEARANCE INSPECTION

1. Verify the clearance between the ABS sensor rotor and the ABS wheel-speed sensor.



If there is any malfunction, check for improper installation, and replace if necessary.

Clearance



0.95-1.75 mm {0.038-0.068 in}

Fig. 23: Identifying Clearance Between ABS Sensor Rotor & ABS Wheel-Speed Sensor
Courtesy of MAZDA MOTORS CORP.

SENSOR OUTPUT VALUE INSPECTION

1. Turn the ignition switch off.

2. Connect the M-MDS to the DLC-2.

3. After the vehicle is identified, select the following items from the initialization screen of the M-MDS.



When using the IDS (laptop PC)

1. Select "DataLogger".

2. Select "Modules".

3. Select "ABS".



When using the PDS (Pocket PC)

1. Select "Module Tests".

2. Select "ABS".
